REVELL Ultima Gem Unpacking Instructions

Thank you for purchasing the Ultima Gem
Follow the instructions below to unpack the pedestal.
UNPACKING
Step 1: Place the packing carton down so that the long side of the carton that's marked "Open this Side"
is facing up.
Step 2: Open both the outer box and inner box so that one side of the packaged pedestal is exposed.
Step 3: Without allowing the flaps to close, invert the carton so that the open flaps of both boxes are on
the bottom.
Step 4: Lift the cartons up and off the stand.
Step 5: Remove the Top End Pad from the top of the pedestal and the Base End Pad from the bottom of
the pedestal.
Step 6: Remove the Cardboard Sleeve and the Middle Pads.
Step 7: Remove the cloth bag. Handle carefully to ensure that the pedestal isn't scuffed or bumped.
You are now ready to start the installation procedure. Turn this sheet over to proceed.
NOTE: Save all original packaging materials.
Cardboard Sleeve
Base End Pad
Cloth Bag
Harman Specialty Group
3 Oak Park Drive
Bedford, MA 01730-1413
USA
Revel Part No. 363812-001 | Rev 0 | 03/07
®
Revel Ultima Gem

Unpacking Instructions

® 2 Pedestal for your Revel
Tel 781-280-0300 Customer Service
Fax 781-280-0490 Tel 781-280-0300
Fax 781-280-0495 (Sales)
www.revelspeakers.com
Fax 781-280-0499 (Service)
®
2 Pedestal
® Ultima Gem
Accessory Bag
Top End Pad
Pedestal
Middle Pads
® 2 Loudspeaker.
