SIMP
I
HOME
I
L I F E B Y D E S I G N
BURLINGTON / PORTLAND / BERKSHIRE
CONSOLE TABLE
MODEL #
AXCRBUR06-MAH
1/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WyndenHall brooklyn+max AXCRBUR06-MAH and is the answer not in the manual?

Questions and answers

Related Manuals for SIMPLIHOME WyndenHall brooklyn+max AXCRBUR06-MAH

Summary of Contents for SIMPLIHOME WyndenHall brooklyn+max AXCRBUR06-MAH

  • Page 1 SIMP HOME L I F E B Y D E S I G N BURLINGTON / PORTLAND / BERKSHIRE CONSOLE TABLE MODEL # AXCRBUR06-MAH 1/17...
  • Page 2 SIMP HOME L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...

  • Page 3: Safety Information

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts.

  • Page 4: Care And Maintenance

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks.

  • Page 5: Pre-Assembly Information

    PRE-ASSEMBLY INFORMATION MODEL # AXCRBUR06-MAH PARTS DESCRIPTION SIDE (L&R Same) BOTTOM SHELF QTY 2 QTY 1 QTY 1 CENTRE SHELF LEFT DIVIDER RIGHT DIVIDER QTY 1 QTY 1 QTY 1 LEFT DRAWER SIDE DRAWER FRONT DRAWER FRONT QTY 1 QTY 2 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
  • Page 6 PRE-ASSEMBLY INFORMATION MODEL # AXCRBUR06-MAH PARTS DESCRIPTION LEFT DRAWER SIDE RIGHT DRAWER SIDE RIGHT DRAWER SIDE QTY 2 QTY 2 QTY 1 DRAWER BACK DRAWER BACK DRAWER BOTTOM QTY 1 QTY 2 QTY 3 BACK PANEL QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.

  • Page 7: Hardware Description

    PRE-ASSEMBLY INFORMATION MODEL # AXCRBUR06-MAH HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN M6 X 30 mm CAM LOCK ALLEN KEY QTY 36 QTY 24 SETS QTY 1 PHILLIPS SCREW Required - ROUND HEAD Flathead screwdriver M4 X 15 mm HANDLE Phillips screwdriver QTY 12...
  • Page 8 COMPONENTS – KEY DIAGRAM MODEL # AXCRBUR06-MAH 8/17...
  • Page 9 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 1 1. Attach four Cam Lock Pins 2 to back of Drawer Front E1 . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides F1L , F1R . 3. Insert two Cam Locks 2 into guide holes on each Drawer Side F1L , F1R . 4.
  • Page 10 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 3 1. Align Drawer Back G1 with Drawer Bottom H and press firmly into slot . 2. Attach back using two Allen Key Screws 1 through guide holes on each side. 3. Use Allen Key 3 to tighten. Do not over tighten. STEP 4 NOTE: The screwdriver is not included in the hardware pack.
  • Page 11 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 5 1. Attach four Cam Lock Pins 2 to back of Drawer Front E . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides FL , FR . 3. Insert two Cam Locks 2 into guide holes on each Drawer Side FL , FR . 4.
  • Page 12 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 7 1. Align Drawer Back G with Drawer Bottom H and press firmly into slot . 2. Attach back using two Allen Key Screws 1 through guide holes on each side. 3. Use Allen Key 3 to tighten. Do not over tighten. STEP 8 NOTE: The screwdriver is not included in the hardware pack.
  • Page 13 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 9 1. Insert six Allen Key Screws 1 through guide holes on centre of two Dividers DL , DR into Centre Shelf C1 (three Screws / each Divider). 2. Use Allen Key 3 to tighten. Do not over-tighten. STEP 10 1.
  • Page 14 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 11 NOTE: The screwdriver is not included in the hardware pack. 1. Attach six Cam Lock Pins 2 to each Side A using pre-drilled holes . 2. Align Cam Lock Pins with guide holes on Centre Shelf C1 and Bottom Shelf C . 3.
  • Page 15 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 12 1. Insert twelve Allen Key Screws 1 into guide holes on two Sides A and two Dividers DL , DR into Top B ( three Screws / each Side and Divider ). 2. Use Allen Key 3 to tighten. Do not over-tighten . STEP 13 NOTE: The screwdriver is not included in the hardware pack.
  • Page 16 ASSEMBLY MODEL # AXCRBUR06-MAH STEP 14 1. Insert assembled drawers into glides on assembled table. 16/17...

  • Page 17: Warranty

    SIMP HOME L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
