Summary of Contents for MAKINEX GEN-9P
- Page 1 Makinex 9kW Generator GEN-9P USA SPEC 3-PHASE GENERATOR OPERATOR’S MANUAL REV1117 Page 1 of 23...
-
Page 2: Table Of Contents
ELECTRICITY RELATED SAFETY PRECAUTIONS ....................7 EARTHING OF GENERATOR ..........................8 SAFETY DECAL ..............................10 PRODUCT SPECIFICATIONS ..........................11 GEN-9P-US WITH 2X30A, 2X20A OUTLETS WITH GFCI PROTECTION ............... 11 FEATURES................................11 OVERALL MACHINE DIMENSIONS ........................12 ALTERNATOR SPECIFICATIONS ......................... 12 OPERATION .............................. -
Page 3: Disclaimer
Thank you for purchasing a MAKINEX product. This manual provides information and procedures to safely operate and maintain the GEN-9P-US Generator. For your own safety and protection from injury, carefully read, understand, and observe the safety instructions described in this manual. -
Page 4: About This Manual
MAKINEX SUPPORT 1-855-Makinex (855-625-4639) MODEL NO. GEN-9P-US SERIAL NO. DATE OF PURCHASE PURCHASE LOCATION ABOUT THIS MANUAL This manual uses the following symbols to help differentiate between different kinds of information. The safety symbol is used with a key word to alert you to potential hazards in operating and owning power equipment. -
Page 5: Product Information
Read this manual thoroughly before operating your generator. Failure to follow instructions could result in WARNING serious injury or death MAKINEX GEN-9P-US Generator designed for professional operators only, instruct operators in care WARNING and use of the machine before use! GENERAL SAFETY PRECAUTIONS •... - Page 6 • NEVER allow the generator to run out of fuel when a load is connected. • NEVER alter or tamper with the internal wiring of the generator. • NEVER climb or stand on the generator as dents may cause overheating of the acoustic lining.
-
Page 7: Electricity Related Safety Precautions
ELECTRICITY RELATED SAFETY PRECAUTIONS RISK OF ELECTRICAL SHOCK • Risk of electrocution. WARNING • ALWAYS test the GFCI’s before use. • ALWAYS store the generator undercover when not in use and away from damp or wet conditions. • NEVER use the generator outdoor when it is raining or snowing or in wet or damp conditions. -
Page 8: Earthing Of Generator
EARTHING OF GENERATOR Earthing of generators helps protect the user from electric shock or electrocution which may be caused due to malfunction or breakdown. This threat to the user is prevented by creating a path of least resistance for the electrical current to travel to the ground which inherently absorbs the over-current or short circuit. - Page 9 • All electrical tools and appliances powered by the generator, must be properly earthed by either a third wire or “double insulated”. Recommendations: 1. Use electrical devices with 3-prong power cords 2. Use extension cords with a 3-hole receptacle and a 3-prong plug on opposite ends to maintain earth protection from the generator to the appliance.
-
Page 10: Safety Decal
SAFETY DECAL *May vary by model Page 10 of 23... -
Page 11: Product Specifications
PRODUCT SPECIFICATIONS GEN-9P-US WITH 2X30A, 2X20A OUTLETS WITH GFCI PROTECTION (may vary by model) GENERATOR: MAX OUTPUT 8,700W FREQUENCY 60Hz VOLTAGE 120/208V, OR 120/240V CONTINUOUS OUTPUT 8,000W SOCKETS 2x30A, 2x20A outlets with GFCI protection (240V) WEIGHT 100 kg (220 lbs) -
Page 12: Overall Machine Dimensions
OVERALL MACHINE DIMENSIONS ALTERNATOR SPECIFICATIONS *Figures vary by model, 240V model shown Page 12 of 23... -
Page 13: Operation
OPERATION BEFORE USE 1. Add Engine Oil (New machines will be pre-oiled from MAKINEX) 1.1 Place generator on a flat, level surface. 1.2 Clean area around oil fill and remove oil fill cap. 1.3 Using oil funnel (optional), slowly pour contents into oil fill opening. - Page 14 WHEN ADDING FUEL TO GENERATOR, OBSERVE THE FOLLOWING STEPS: 2.0 Always ensure that fuel tanks are filled outdoors. 2.1 Turn generator OFF and let it cool for at least two minutes before removing fuel cap. 2.2 Loosen fuel cap slowly to release pressure. 2.2 Slowly add unleaded gasoline to fuel tank.
-
Page 15: Operating Generator
OPERATING GENERATOR STARTING THE ENGINE 1. Remove all connections from the AC sockets. 2. If the fuel tank is equipped with a valve, be sure the fuel valve is in the OPEN or ON position before attempting to start the engine. 3. -
Page 16: Maintenance
MAINTENANCE GENERAL RECOMMENDATIONS: Regular maintenance will improve the performance and extend the life of the GENERATOR. The generator’s warranty does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, the operator must maintain the generator as instructed in this manual and in the engine manual, including proper storage. -
Page 17: Storage
STORAGE Long term storage instructions (fuel in tank) Gasoline fuel can become stale when stored over 30 days. Stale fuel causes acid and gum deposits to form in the fuel system or crucial carburettor parts. To keep fuel fresh, add a fuel stabiliser liquid additive to fuel. The fuel stabiliser is available at most auto parts stores. -
Page 18: Limited Warranty
This warranty applies only to new MAKINEX generator distributed by us and by our authorised MAKINEX dealers. -
Page 19: Installation, Use, And Maintenance
Failures due to acts of God and other force majeure events beyond the manufacturer’s control. Problems cause by parts that are not original MAKINEX parts. Responsibility of the consumer under this Limited Warranty: Strict adherence to the maintenance checks and schedule with proof of scheduled maintenance service required by an authorised agent or qualified mechanic. - Page 20 All warranties will be carried out by MAKINEX authorised staff or appointed agents at a premises to be determined by the Manufacturer. It is the responsibility (and cost) of MAKINEX or our appointed agent to return the machine to be repaired or replaced under warranty to the consumer- this is valid for domestic territories only (e.g.
-
Page 21: Contact Information
EMAIL ADDRESS Suzhou Industrial Park Xinghai Street on the 16th Jinying Pioneering Park, 2nd Floor, Area C Or your nearest MAKINEX distributor We have very knowledgeable, experienced staff to assist you with help and advice. Page 21 of 23... -
Page 22: Appendix A- Risk Assessment
APPENDIX A- RISK ASSESSMENT Page 22 of 23... -
Page 23: Appendix B- Wiring Diagrams
APPENDIX B- WIRING DIAGRAMS GEN-9P-US 208V/240V WIRING DIAGRAM Page 23 of 23...
