TexFinish™
For Water-Based Materials Only
Models:
246185, 246186, 249175, 249176
55 psi (3.8 bar) Maximum Fluid Working Pressure
Read warnings and instructions.
Related Manuals
309584
309797
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
Interior Texture Sprayers
US
Conforms to ANSI/UL
standard 1450
309796 rev.F
C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco MAGNUM TexFinish 249175
Summary of Contents for Graco MAGNUM TexFinish 249175
- Page 1 55 psi (3.8 bar) Maximum Fluid Working Pressure Read warnings and instructions. Related Manuals 309584 309797 Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001 Conforms to ANSI/UL standard 1450...
-
Page 2: Fire And Explosion Hazard
Route hoses away from traffic areas, sharp edges, moving parts and hot surfaces. • Do not expose Graco hoses to temperatures above 130°F (55°C) or below -35°F (-37°C).Store haz- ardous fluid in an approved container. Dispose of hazardous fluid according to all local, state and national guidelines. -
Page 3: Electric Shock Hazard
WARNINGS Electric Shock Hazard To reduce the risk of electric shock: • Be sure sprayer is adequately grounded through electrical outlet. • Use only 3-wire, extension cords. • Make sure ground prongs are intact on sprayer and extension cords. Improper installation of ground- ing plug will result in a risk of electrical shock, fire or explosion that could cause serious injury or death. -
Page 4: Component Identification
Gun air valve Material/air hose Burp guard Texture spray gun (manual 309584) Mesh nozzle holding bag Material Hopper Hopper fitting (fluid inlet) Graco RotoFlex™ pump (inside) Hopper clamp Hose rack/cord wrap Hose clip Touch-up hopper (3/4 gallon) Gun plug clip Nozzle storage... -
Page 5: Pressure Relief Procedure
Preparation Preparation Pressure Relief Procedure WARNING To reduce risk of injury, follow this procedure page 2 and 3 whenever you see this symbol throughout this manual, Also, perform this procedure whenever you: 120V AC Systems • stop spraying. • This equipment grounded outlets requires a 120V AC,... -
Page 6: Texture Spraying
Setup Setup Important • If you are going to stop spraying for more than 5 minutes, turn sprayer off to prevent shortened pump hose life. • Do not allow material to dry inside pump, hoses, gun or spray system. 3. Open air valve. WARNING page 2 and 3 ti2448a... - Page 7 Setup 8. Turn power switch ON. Touch Up Hopper Attachment ti2446a • The Hose Plug must be securely fastened to bottom of gun when using the Touch Up 9. Close gun air valve. Hopper. Gun Plug must be removed from top of gun. ti2453 10.
- Page 8 Setup 7. Turn hopper 8. Open gun air valve. gun/spray gun selector switch to HOPPER GUN. ti2448a ti2592a 9. Turn power switch ON. CAUTION ti2446a Failure to change selector switch to Hopper Gun when using hopper gun will damage pump hose. 10.
-
Page 9: Mixing Material
Mixing Material Mixing Material 5. Observe the ball on the Correct material mixture is essential. The pump READY ADD WATER material. When the mate- will not operate if the mixture is too thick. rial is thin enough to spray the ball will sink com- Mix the material in a separate container before pletely into the mixture. -
Page 10: Spray Techniques
Spray Techniques Spray Techniques Recommended Nozzle Selection Chart To Get Less Material Application Try one or a combination of these methods: Nozzle Size Air Volume Simulated 6 mm, white medium to high • Open air valve. Acoustic (fine to medium) 8 mm, gray •... -
Page 11: Shut Down And Clean-Up
Shutdown and Cleanup Shutdown and Cleanup Keep pump and hose clean when switching between simulated acoustic, knockdown and orange peel applications. A dirty pump can release particles of texture into the finish. CAUTION • Turn off sprayer if you are going to stop spraying for 5 minutes or longer. •... -
Page 12: Transporting The Sprayer
Shutdown and Cleanup Removing Material Hopper from Sprayer 3. Fill hopper with clean water. Remove nozzle The material hopper can be removed for cleaning. To from gun and allow water remove material hopper: to flow through and out of gun. 1. -
Page 13: Troubleshooting
Refer to Grounding and Electrical Requirements, page 5. Gun needle plugged Clean needle and retry. Worn compressor Replace compressor. Contact a qual- ified Graco Service Center. Lines not connected Check all quick disconnect connec- tions to gun and hoses Damaged hose Replace hose... - Page 14 Troubleshooting Problem Cause Solution Speed of application slow or slower Material too thick Thin material. Nozzle too small Change nozzles to a larger size. See Recommended Nozzle Selection Chart, page 10. Too much air being used. Partially close gun air valve to reduce air flow.
-
Page 15: Technical Data
Technical Data Technical Data Main unit power requirements 120 Vac, 60 Hz, 15A, 1 phase Maximum fluid working pressure 55 psi, (3.8 bar) Maximum air working pressure 38 psi (2.6 bar) Compressor specifications Universal motor thermally protected, oil-less Compressor air displacement 4.5 displacement scfm at 30 psi Generator required 3500 W minimum... -
Page 16: Limited Warranty
This warranty does not cover and Graco shall not be liable for general wear and tear, or any malfunction, damage, or wear caused by improper use, accidents, user negligence, use of non-Graco component parts or service or repair performed by anyone other than a Graco authorized service center.
