SATA Product Manual
Standard 512E model
ST14000VN0008
ST12000VN0008
ST10000VN0008
100835908, Rev. C
Gen 2 - June 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRONWOLF NAS ST14000VN0008 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seagate IRONWOLF NAS ST14000VN0008

Summary of Contents for Seagate IRONWOLF NAS ST14000VN0008

  • Page 1 SATA Product Manual Standard 512E model ST14000VN0008 ST12000VN0008 ST10000VN0008 100835908, Rev. C Gen 2 - June 2018...
  • Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. IronWolf, PowerChoice and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.

  • Page 3: Table Of Contents

    Seagate® Technology Support Services ........
  • Page 4 S.M.A.R.T. commands............. . 45 Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 5: Seagate® Technology Support Services

    For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 6: Introduction

    Top Cover Attached motor for excellent vibration tolerance  Worldwide Name (WWN) capability uniquely identifies the drive.  Seagate recommends validating the configuration with the selected HBA/RAID NOTE controller manufacturer to ensure use of full capacity is supported. Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 7: About The Serial Ata Interface

    Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be downloaded from www.serialata.org. Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 8: Drive Specifications

    1.8A Voltage tolerance (including noise) 5V ± 5% 12V ± 10% 5° to 70°C (Drive Reported Temperature) Operating drive temperature Non-Operating temperature –40° to 70°C (Ambient Temperature, see sections 1.2.6.0.1 and 1.2.15) Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 9 Load-unload cycles 600,000 Supports Hotplug operation per Serial ATA Revision 3.3 specification *See for rated MTBF device operating condition requirements. Section 1.2.10, "Reliability" Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 10: Formatted Capacity

    Sustained data transfer rate (MiB/s max) I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) 1.2.4 Start/stop times Power-on to Ready (sec) (typ/max) 23/30 Standby to Ready (sec) (typ/max) 23/30 Ready to spindle stop (sec) (max) Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 11: Power Specifications

    Maximum DC 0.756 0.324 Maximum DC (peak) 0.89 1.824 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 12 Drive specifications 1.2.5.1.1 Typical current profiles Figure 1. Typical 5V and 12V startup and operation current profiles Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 13: Conducted Noise

    Idle Immediate also provide a method to directly transition the drive into supported power conditions. PowerChoice exits power saving states under the following conditions Any command which requires the drive to enter the PM0: Active state (media access)  Power on reset  Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 14 PowerChoice Supported Extended Power Condition Feature Subcommands EPC Subcommand Description Restore Power Condition Settings Go to Power Condition Set Power Condition Timer Set Power Condition State Enable EPC Feature Set Disable EPC Feature Set Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 15: Environmental Limits

    Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. 1.2.6.1 Humidity The values below assume that no condensation on the drive occurs.

  • Page 16: Shock

    The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 2–500 Hz 2.27 Grms ref Linear Random Freq (Hz) .001 .001 Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 17: Acoustics

    Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.

  • Page 18: Reliability

    The drives are recognized in accordance with UL/cUL 62368 -1 and EN 62368 -1. 1.2.11.2 Regulatory Models The following regulatory model number represent all features and configurations within the series: Regulatory Model Numbers: STL006 Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 19: European Union (Eu) Ce Marking Requirements

    Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user.

  • Page 20: Taiwanese Bsmi

    As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.

  • Page 21: Environmental Protection

    The European Union REACH (Registration, Evaluation, Authorization and Restriction of Chemicals) Regulation (EC) 1907/2006 regulates chemicals shipped into and used in Europe. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of REACH substances in these articles and materials.

  • Page 22: Taiwan Requirements - Taiwan Rohs

    CNS 15663, Guidance to reduction of the restricted chemical substances in electrical and electronic equipment. Seagate products must comply with the “Marking of presence” requirements in Section 5 of CNS 15663, effective January 1, 2018. This product is Taiwan RoHS compliant.

  • Page 23: Reference Documents

    Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. Seagate will pay for transporting the repair or replacement item to the customer.

  • Page 24: Configuring And Mounting The Drive

    For installations which require cables, users can connect the drive as illustrated in Figure Figure 2. Attaching SATA cabling Each cable is keyed to ensure correct orientation. IronWolf Serial ATA drives support latching SATA connectors. Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 25: Drive Mounting

    MAX TORQUE 6 IN/LBS 1.028 26.11MM .138 ±.015 2.000 C L OF DRIVE Figure 3. Mounting configuration dimensions The image is for mechanical dimension reference only and may not represent the actual drive. NOTE Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 26: Serial Ata (Sata) Interface

    5V power, pre-charge, 2nd mate 5V power 5V power Ground 2nd mate Ground or LED signal If grounded, drive does not use deferred spin Ground 1st mate. 12V power, pre-charge, 2nd mate 12V power 12V power Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 27: Supported Ata Commands

    Flush Cache Flush Cache Extended Get Physical Element Status Identify Device Idle Idle Immediate Read Buffer Read DMA Read DMA Extended Read FPDMA Queued Read Log DMA Ext Read Log Ext Read Multiple Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 28 S.M.A.R.T. Read Attribute Thresholds / D1 S.M.A.R.T. Read Data / D0 S.M.A.R.T. Read Log Sector / D5 S.M.A.R.T. Return Status / DA S.M.A.R.T. Save Attribute Values / D3 S.M.A.R.T. Write Log Sector / D6 Standby Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 29 Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Extended Write Stream DMA Extended Write Uncorrectable Extended Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 30: Identify Device Data Log

    Page number of the next supported ID data log page Page number of the last supported ID data log page 18..511 Reserved Copy of IDENTIFY DEVICE data 0..511 Copy of IDENTIFY DEVICE command data Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 31 Shall be set to 1 0..7 62:24 Reserved 23:16 Page number 8..15 Supported Capabilities (QWord) Shall be set to 1 62:55 Reserved advanced background operation supported persistent sense data reporting sff-8447 reporting Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 32 Reserved read look-ahead supported volatile write cache supported smart supported flush cache ext supported Reserved 48-bit supported Reserved spin-up supported puis supported apm supported Reserved for CFA Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 33 Contents of the QWord are valid 32..39 62:4 Reserved nominal form factor 3.5” Write-Read-Verify Sector Count Mode 3 (QWord) Contents of the QWord are valid 40..47 62:32 Reserved 31:0 wrm mode 3 count Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 34 Contents of the QWord are valid 62:24 Reserved setting rate basis supported 22:9 Reserved 96..103 since power on rate basis supported Reserved power on hours rate basis supported Reserved date/time rate basis supported Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 35 Contents of the QWord are valid 128..135 62:32 Reserved 31:16 device maintenance polling time 15:0 abo recommended abo start interval Queue Depth (QWord) Contents of the QWord are valid 136..143 62:5 Reserved queue depth Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 36 Vendor Specific Supported Capabilities (QWord) 504..511 Contents of the QWord are valid 62:0 Vendor specific Current Settings Current Settings page information header (QWord) Shall be set to 1 0..7 62:24 Reserved 23:16 Page number Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 37 Contents of the QWord are valid 24..31 62:16 Reserved 15:0 dma sector time PIO Host Interface Sector Times (QWord) Contents of the QWord are valid 32..39 62:16 Reserved 15:0 pio sector time Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 38 47:32 time scheduled for device maintenance 31:16 time to performance degradation 15:0 minimum inactive time Advanced Background Operations Settings (QWord) Contents of the QWord are valid 80..87 62:8 Reserved abo_status 88..511 Reserved Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 39 FFFE Security Status (QWord) Contents of the QWord are valid 62:7 Reserved security supported master password capability 16..23 enhanced security erase supported security count expired security frozen security locked security enabled Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 40 (1, SED and ISE drives only) sanitize supported encrypt all supported 56..511 Reserved Parallel ATA 000..511 (Not supported for SATA drives) all zeros Serial ATA Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 41 Reserved sata gen3 signaling speed supported sata gen2 signaling speed supported sata gen1 signaling speed supported Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 42 SUPPORTED HARDWARE FEATURE CONTROL IDENTIFIER 44..47 Reserved Device Sleep Timing Variables (QWord) devslp timing variables supported 62:16 Reserved 48..55 15:8 devsleep exit timeout (deto) Reserved minimum devslp assertion time (mdat) 56..511 Reserved Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 43: Device Statistics Log

    Number of Reallocation Candidate Logical Sectors Number of High Priority Unload Events General Errors Statistics Number of Reported Uncorrectable Errors Number of Resets Between Command Acceptance and Command Completion Physical Element Status Changed Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 44 Maximum Implicitly Open Zones Minimum Empty Zones Maximum Non Sequential Zones Zones Emptied Suboptimal Write Commands Commands Exceeding Optimal Limit Failed Explicit Opens Read Rule Violations Write Rule Violations 09..FE Reserved Vendor Specific Statistics Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 45: Set Features Command

    Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the NOTE features are as indicated above. Seagate IronWolf Serial ATA Product Manual, Rev. C...

  • Page 46: S.m.a.r.t. Commands

    S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the command is NOTE aborted and 0x 04 (abort) is written to the Error register. Seagate IronWolf Serial ATA Product Manual, Rev. C...
  • Page 47 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100835908, Rev. C...
