OPERATOR'S MANUAL
FOR
TRACTORS
T354
DaeYong B/D, 7, Eonju-ro 133-gil, Gangnam-gu, Seoul, Korea ■ TEL: 82-2-3014-2800, FAX:82-2-3014-2852 ■
www.tym.co.kr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T354 and is the answer not in the manual?

Questions and answers

Related Manuals for TYM T354

Summary of Contents for TYM T354

  • Page 1 OPERATOR’S MANUAL TRACTORS T354 DaeYong B/D, 7, Eonju-ro 133-gil, Gangnam-gu, Seoul, Korea ■ TEL: 82-2-3014-2800, FAX:82-2-3014-2852 ■ www.tym.co.kr...
  • Page 3 YANMAR WARRANTIES YANMAR LIMITED WARRANTY What is Covered by this Warranty? YANMAR warrants to the original retail purchaser that a new YANMAR TNV common rail series industrial engine will be free from defects in material and/or workmanship for the duration of the warranty period. Note: YANMAR engines may be equipped with external components including, but not limited to: wiring harnesses, electrical devices, control panels, radiator, air filters, fuel/or exhaust systems that are supplied and/or installed by manufacturers other than YANMAR.
  • Page 4 YANMAR limited warranty- continued What the Engine Owner must Do: If you believe your YANMAR engine has experienced a failure due to a defect in material and/or workmanship, your must contact an authorized YANMAR industrial engine dealer or distributor within Thirty (30) Days of discovering the failure, You must provide proof of ownership of the engine, proof of the date of the engine purchase and delivery, and documentation of the engine operation hours.
  • Page 5 YANMAR limited warranty- continued What is no Covered by this Warranty? This warranty does not cover parts affected by or damaged by ant reason other than defective materials or workmanship, including, bur not limited to, accident, misuse, abuse, “Acts of God,” neglect, improper installation, improper maintenance, improper storage, the use of unsuitable attachments or parts, the use of contaminated fuels, the use of fuels, oils, lubricants, or fluids other than those recommended in your YANMAR Operation Manual, unauthorized alterations or modifications, ordinary wear and tear, and rust or...
  • Page 6 EMISSION SYSTEM WARRANTY YANMAR CO., LTD. LIMITED EMISSION CONTROL SYSTEM WARRANTY – USA ONLY Your Warranty Rights and Obligations: ■ California The California Air Resources Board (CARB), the Environmental Protection Agency (EPA) and YANMAR Co,. Ltd. hereafter referred to as YANMAR, are pleased to explain the emission control system warranty on your industrial compression-ignition engine.
  • Page 7 Limited emission control system warranty – USA only – continued Warranty Coverage: This warranty is transferable to each subsequent purchaser for the duration of the warranty period. Repair or replacement of any warranted part will be performed at an authorized YANMAR industrial engine dealer or distributor.
  • Page 8 Limited emission control system warranty – USA only – continued Exclusions: Failures other than those arising from defects in material and/or workmanship are not covered by this warranty. The warranty does not extend to the following: malfunctions caused by abuse, misuse, improper Adjustment, modification, alteration, tampering, disconnection, improper or inadequate maintenance or use Of non-recommended fuels and lubricating oils;...
  • Page 9 FOREWARD Thank you very much for purchasing our tractor, which, we feel sure, will give you many years of troubling the service. The introduction in this manual set out the correct manner of operating, maintaining and checking the tractor to ensure long-term durability. Please ensure correct operation of the tractor as incorrect operation can cause substantial mechanical damage as well as cause accidents with the associated injuries.

  • Page 10: Table Of Contents

    CONTENTS Sr. No. Description Page No. Tractor Identification About this manual Introduction & description 11~12 Owner assistance ROPS (Roll over protection structures) 14~16 Safety instructions, Do’s & Don’ts 17~29 Safety signs 30~32 Universal symbols Section A Controls, Instruments & Operations 34~59 Section B Lubrication &...

  • Page 11: Tractor Identification

    The manufacturer warrants this product and full details of the warranty are provided on a separate warranty schedule. SERVICE. Service is available from any TYM dealer in the country. PARTS. To obtain spare parts please contact your nearest dealer and give him the details listed below.

  • Page 12: About This Manual

    Your Tractor has been designed and built to give maximum performance, with good fuel economy and ease of operation under a wide variety of operating conditions. Prior to delivery, The tractor was carefully inspected, both at the factory and by your TYM Dealer/Distributor, to ensure that it reaches you in optimum conditions .

  • Page 13: Introduction & Description 11~12

    A Tractor can also be used as a prime mover as it has a power outlet source which is also called Power Take or PTO shaft. In this book the operating, maintenance and storage instructions for all models of TYM Diesel Tractors has been complied.
  • Page 14 The rim & Disc fitted with Rear tires are bolted to the outer flange of Rear Axle. ■ Hydraulic system & Linkages. TYM Tractors are fitted with Live (i.e. system is in operation even when clutch is disengaged.) independent, very touch of hydraulic System. Three point Linkages can be used for category 1 type of implements.

  • Page 15: Owner Assistance

    • Nature of problem Before contacting TYM CO.,LTD office, be aware that your problem will likely to be resolved in the Dealership using the Dealer’s/Distributor’s facilities, equipment and personnel. So it is important that your initial contact be with the Dealer/Distributor.

  • Page 16: Rops (Roll Over Protection Structures) 14~16

    The objective of the frame or cab structure is to protect the operator in the event of a roll over and they are designed to support the entire weight of the tractor in that event. Each TYM ROPS frame or cab structure is designed and has been tested to meet industry and or Government standards.
  • Page 17 ► DAMAGE OF THE ROPS If the tractor has rolled over or the ROPS has damaged (such as striking an overhead object during transport), It must be replaced to provide the original protection. After an accident, check for damages to the 1.ROPS.2.Seat 3.seat belt & seat mountings. Before you operate a Tractor, replace all damaged parts.
  • Page 18 How to adjust the Seat * Damping type NOTE: Do not use solvents to clean the seat. Use warm water with a little detergent added. Before operating a Tractor it is important to adjust the seat to the most comfortable position &...

  • Page 19: Safety Instructions, Do's & Don

    SAFETY INSTRUCTIONS RECOGNIZE SAFETY INFORMATION This symbol means ATTENTION! YOUR SAFETY IS INVOLVED. The message that follows the symbol contains important information about safety. Carefully read the message SIGNAL WORDS. DANGER A signal word―DANGER, WARNING OR CAUTION―is used with safety alert symbol. DANGER identifies the most serious hazards.
  • Page 20 USE OF ROPS AND SEAT BELT The Roll Over Protective Structure(ROPS) has been certified to industry and/or government standards. Any damage or alternation to the ROPS, mounting hard-ware, or seat belt voids the certification and will reduce or eliminate protection for the operator in the event of a roll-over.
  • Page 21 HANDLE FUEL SAFELY-AVOID FIRES Handle fuel with care; it is highly flammable. Do not refuel the Tractor while smoking or near open flame or sparks. Always stop engine before refueling Tractors. Always keep your tractor clean of accumulated grease, and debris. Always clean up spilled fuel.
  • Page 22 AVOID HIGH-PRESSURE FLUIDS Escaping fluid under pressure can penetrate the skin causing serious injury. Keep hands and body away from pinholes and nozzles, which eject fluids under high pressure. If ANY fluid is injected into the skin. Consult your doctor immediately. PREVENT BATTERY EXPLOSIONS Keep sparks, lighted matches, and open flame away from the top of battery.
  • Page 23 WORK IN VENTILATED AREA Do not start the Tractor in an enclosed building unless the doors & windows are open for proper ventilation, as tractor fumes can cause sickness or death. If it is necessary to run an engine in an enclosed area remove the exhaust fumes by connecting exhaust pipe extension.
  • Page 24 SAFE OPERATION OF YOUR TRACTOR The manufacturer of your tractor has made every effort to make it as safe as is humanly possible. Beyond this point it is the responsibility of the operator to avoid accidents and we ask that you read and implement our suggestions for your safety.
  • Page 25 SAFETY TIPS DURING MAINTENANCE 1. At least on a daily basis check all oil levels. Water level in the radiator and electrolyte level in the battery and perform services according to the service schedule. 2. Ensure tire pressure are even and the correct pressure for the job being done is maintained. 3.
  • Page 26 ► MOUNTING AND DEMOUNTING IMPLEMENTS (1) Ensure that all mounting and removal of implements is done on safe flat ground. Ensure no one is between the Tractor and implement and do not get under the implement to avoid accidental injuries. (2) After mounting the implement, ensure that all sway chains are correctly adjusted and, where PTO shafts are used that the shaft is fitted and secured correctly.
  • Page 27 ► THE FOLLOWING PRECAUTIONS ARE SUGGESTED TO HELP PREVENT ACCIDENTS. A careful operator is the best operator. Most accidents can be avoided by observing certain precautions . Read and take the following precautions before operating the Tractor to prevent accidents. Tractor should be operated only by those who are responsible and properly trained to do so.
  • Page 28 Do not bypass the safety starter switch. Consult your TYM Tractor Dealer/Distributor if safety- starting switch malfunctions. 4. Avoid accidental contact with the gear shifter lever while the engine is running. Unexpected Tractor movement can result from such contact.
  • Page 29 Driving the tractor ■ 1. Watch where you are going especially at row ends, on roads, around trees and low hanging obstacles. 2. To avoid upsets, drive the tractor with care and at speeds compatible with safety, especially when operating over rough ground, crossing ditches or slopes, and when turning at corners. 3.
  • Page 30 DO’S AND DON’T’S ► DO’S-For Better performance DO-Ensure that safety shields are in place and in good condition. DO-Read all operating instructions before commencing to operate Tractor. DO-Carry out all maintenance tasks without fail. DO-Keep the air cleaner clean. DO -Ensure that the correct grade of lubricating oils is used and that they are replenished and changed at the recommended intervals.
  • Page 31 DON’T-Use the independent brakes for making turns on the highway or at high speeds. DON’T-Refuel the tractor with the engine running. DON’T-Mount or dismount from the right side of the tractor. DON’T-Temper the hydraulic control levers’ upper limit stops. DON’T-Use draft control lever for lifting of implements. DON’T-Start the engine with the PTO engaged.

  • Page 32: Safety Signs

    SAFETY SIGNS ► GENERAL SAFETY INFORMATION IMPORTANT: This “General safety Information” should be kept with the machine at all times as reference data. This symbol means ATTENTION! YOUR SAFETY IS INVOLVED. The message that follows the symbol contains important information about safety. Follow recommended precautions and safe operating practice.
  • Page 33 DECALS ON THE CHASSIS...
  • Page 34 DECALS AROUND THE SEAT...

  • Page 35: Universal Symbols

    UNIVERSAL SYMBOLS Some of the universal symbols have been shown below with an indication of their meaning Engine speed Pressured- Corrosive rev/minX100) open slowly substance ”Tortoise” Hours, Continuous Slow or recorded variable minimum Setting Engine ”Hare” fast or coolant Warning maximum temperature setting...

  • Page 36: Section A

    Section - A Controls, Instruments Operations The following pages in this section detail the location and function of various instruments, switches and controls on your Tractor. Even if you operate other Tractors, you should read through this section of the manual and ensure that you are thoroughly familiar with the location and function of all the features of your New Tractor.
  • Page 37 DESCRIPTION OF TRACTOR CONTROLS ► INSTRUMENT AND SWITCHES Tachometer Left turn Signal lamp Right turn Signal lamp Hazard Warning Fuel Gauge Signal S/W Throttle Lever Regen Disable Lamp PTO On/Off Button and Regen Disable S/W Key S/W Regen ACK Lamp PTO Control S/W and RegenDisable S/W Parking Brake Lever...
  • Page 38 ► HOUR METER The hour meter consists of five digits where the last digit indicates 1/10th of an hour ► TACHOMETER This meter shows the revolutions of the engine and the PTO shafts as well as the travel speed in top gear. ►...
  • Page 39 ►WARNING LIGHTS Charge lamp This light will go off as soon as the engine starts to run to indicate that the alternator is changing. (Please note, as broken fan belt can cause the light to come on, please stop the engine as overheating can occur if not rectified immediately) Oil pressure lamp Will go out as soon as the engine starts if the oil pressure is correct.
  • Page 40 Cruise Control Lamp is operated on when cruise control is engaged. Air cleaner filter contamination indicator This comes on when the air cleaner is clogged by foreign materials. When this comes on, open the cover and clean the inside of the cleaner. Also, blow air through the filter in the direction of intake air to clean it or replace the filter with a new one.
  • Page 41 ► PTO MONITOR LAMP ■ THE PTO MONITOR LAMP on the dash panel indicates the state of the PTO shaft. 1. If the monitor glows: The PTO is rotating 2. If the monitor is off: The PTO is off 3. If the monitor blinks: The PTO is presently stationary but will instantly start rotating of the clutch pedal is released or the implements lowered.
  • Page 42 HYDRAULIC PTO MONITOR CLUTCH POSITION ON/OFFS CONTROL LAMP ON THE PEDAL CONTROL SHAFT WITCH SWITCH DASH PANEL LEVER. Manual Either raised Either pressed or Glows Rotates released Mode or lowered Auto Either raised Pressed Blinks Stationary Mode or lowered Auto Either pressed or Raised Blinks...
  • Page 43 ■ Regeneration operation and cautions ▶ Lamp functions RegenReqLamp ExhaustTempLamp Engine Warning Lamp RegenAck Lamp RegenDisable Lamp & RegenReqSW & RegenDisableSW ▶ Automatic regeneration The regeneration process is automatically being performed when the exhaust temperature lamp comes on during work. ▶...
  • Page 44 Never move the vehicle to another place during regeneration process. Sudden movement can result in an accident. Caution 2. Before starting regeneration, apply the parking brake and idle the engine. Then, the ACK lamp blinks. However, the regeneration process is not performed if the regeneration activation conditions are not satisfied.
  • Page 45 ► TRACTOR CONTROLS ► THROTTLE LEVER (HAND THROTTLE) The hand operated throttle lever is located on the RHS of the Dash cover. To increase the engine speed, Pull the lever downward. To decrease the engine speed, Push the lever upward. The Lever can be left in any position between idle and maximum as required.
  • Page 46 ► CLUTCH CUT-OFF ARM For long term storage of the Tractor it is possible to latch the clutch in the disengaged position. Push the clutch down and engage the latch to hold it there. Do not attempt to start engine when this arm is being used. warning ►...
  • Page 47 ► SHUTTLE SHIFT LEVER This control allows shifting from forward to reverse & reverse to forward. When stationary set the lever to N for neutral. ① Push the lever away from the driver engages forward. ② Pulling the lever towards the driver engages reverse. 1.Press clutch pedal fully before operating shuttle shift lever.
  • Page 48 ► FRONT WHEEL DRIVE LEVER (4WD) The Differential Lock Pedal is located below the LHS of the Operator. In the ON position the front wheels are engaged and in the OFF position they are disengaged. Engage & disengage the front wheel drive with the front wheels in the straight position and at low Engine RPM.
  • Page 49 Your tractor is equipped with 2 Speed PTO to suit range of applications and conditions. POSITION 1 st 2 nd MODEL 1000 T354 REAR PTO 540 rpm * Rear PTO Lever is located on the LHS of Operator. Always use the clutch when engaging or disengaging the PTO or changing PTO speed.
  • Page 50 ► OPERATING THE HYDRAULICS The hydraulics are powered with an engine driven hydraulic pump and controlled with a position control lever mounted beside the driver. ► HYDRAULIC POSITION CONTROL LEVER Hydraulic Position Control Lever is located on the RHS of operator. Implements can be raised and lowered with the hydraulic position control lever and can be stopped at any position by stopping the lever.
  • Page 51 Always set the knob to lock when 1.Traveling on the road 2.Replacing tires or blades on an implement. 3.Making adjustments to an implement. Sudden dropping of an implement due to Caution hydraulic problems can cause serious injury or death. ► HYDRAULIC REMOTE CONTROL VALVE LEVER The Hydraulic Remote Control Valve Lever is located on the RHS of Operator.
  • Page 52 ► JOY STICK LEVER (IF EQUIPPED) The Joy Stick Lever is located on the RHS of the Operator. This simple joystick lever can control the use of a front-end loader. And lift-retract, dump-rollback smoothly and act as one handle lever. To raise the Boon of Front end loader .
  • Page 53 ► OPERATING THE 3 POINT LINKAGE (TPL)
  • Page 54 ► ADJUSTMENT OF THE CHECK CHAIN There should be no clearance (Position A) during implement transport and when working with grades, rollers mowers, seeders, drills and similar implements. However, a slight play is necessary (Position B) when working with ploughs, harrows, ditchers, cultivators.
  • Page 55 ► ADJUSTMENT OF THE YOKE ROD ON THE LOWER LINK For different applications change the position of the Yoke rod on the lower link holes as shown and insert the pin in the direction of the arrow. Only use drawbar to tow and keep the 3 point linkage in raised position when toeing with the drawbar.
  • Page 56 DRIVING THE TRACTOR ► STARTING THE ENGINE Before starting the engine carry out the pre-operational checks as set out on page 26. (1) Sit on the driver seat (2) Apply the footbrake. (3) Put the hydraulic lever in the down position. (4) Push down the clutch to activate the safety-starting switch.
  • Page 57 ► WARMING UP When starting the engine allow it to warm up to operating temperature by allowing it to idle 5-10 minutes to ensure full lubrication and operating temperature. Failure to do so can shorten engine life substantially. ► WARMING UP IN COLD WEATHER Cold weather will change the viscosity of the oil, resulting in a reduced oil pumping capacity, which can cause damage to the engine if it is not warmed up correctly.
  • Page 58 Do not ”ride” the clutch to control speed, use a lower gear. Do not travel with your foot on the clutch pedal. Caution Always connect the brake pedals when traveling on the road. Never tow anything except with the drawbar. Do not tow loads which are too large for the tractor’s capacity to brake effectively especially in hilly terrain.
  • Page 59 ► UPHILL STARTS ON A STEEP SLOPE With the pedals connected together push down on the brake pedals and push down the clutch. Set all gear levers to low and the throttle to medium engine speed. Release the clutch and as it engages release the brake pedals. Adjust the throttle to the required speed.
  • Page 60 ► FUEL GAUGE. To avoid excessive condensation in the fuel tank refill at the end of each day’s work and ensure during the day that it does not drop to a low level where the fuel system will require bleeding to expel air in the system after refilling the tank.
  • Page 61 ► TRACK ADJUSTMENT As some models of TYM are front wheel assist the front track can be set in 2 position. The rear track can be set in 5 positions as illustrated.

  • Page 62: Section B

    Section-B Lubrication & Maintenance This section gives full details of the service procedures necessary to maintain your Tractor at peak efficiency while the lubrication and maintenance chart provides a ready reference to these requirements.
  • Page 63 CHECKS AND SERVICE ► PRE-START CHECKS To avoid problems it is recommended that a range of checks be carried out daily before starting the tractor. For full details of the items and frequency please refer to the tables on page 64,65and 66. ►...
  • Page 64 ► TRANSMISSION OIL Check the level with the dipstick on top of the transmission in rear of the seat. If the level is low add oil through the filler hole. Always ensure that you use the correct oil for topping up or oil changes Caution ►...
  • Page 65 ► STEERING Ensure that the steering wheel does not have excessive free play. ► BRAKE Ensure that the left and right brakes are adjusted correctly so they operate simultaneously. The correct free play on the brake is 1.18-1.57 in (30~40 mm). ►...
  • Page 66 MAINTENANCE AND ADJUSTMENT SCHEDULE ► Periodical check and service table ○ Check, Top-up or adjust ● Replace △ Clean or wash ★ Consult the service Dealer Service interval(hour meter,mark) Item Comment Every 250Hours Engine oil ● ● ● ○ and cartridge After first 50hours ●...
  • Page 67 Service interval(hour meter,mark) Item Comment Trans Change every 300hours ○ ● ● mission oil After First 50hours Free play of ○ (0.78-1.18in) clutch pedal Free play of ○ (1.18-1.57) brake pedal Adjust so that both State of both operate simultaneously ○...
  • Page 68 0.235 Mpa (34.08 PSI) 8-16, 4PR 0.157 Mpa (22.80 PSI) Front R1 (Ag) 12.4-24, 6PR 0.157 Mpa (22.80 PSI) Rear T354 27X10, 50-15, 8PR 0.414 Mpa (60.04 PSI) Front R4 (Ind) 12.5-20 R4, 12PR 0.310 Mpa (45.00 PSI) Rear 27X10, 50LL-15, 6PR 0.220 Mpa (31.91 PSI)
  • Page 69 ► FILLING DIAGRAM & CAPACITY TABLE Filling point Fillings Quantity Liter (gal.) MODEL T354 50/50 : Ethylene Glycol/Water (L.L.C) 4.8ℓ( 1.27US gal) RADIATOR ASTM D4985 / D6210 API : CF-4 grades CJ-4 Above:25°C(77°F)… SAE30 or 15W/40 3.2ℓ (0.85 US gal) ENGINE 0°C to 25°C(32°F to 77°F)…...
  • Page 70 ► RECOMMENDED TRANSMISSION OIL ① RPM Tractor Hydraulic Fluid or Textron TDH Premium (CALTEX) ② TDH Oil or TDH Oil special (TEXACO) ③ Chevron 1000THF (CHEVRON) ► OPENING METHOD OF EACH COVER ► OPENING METHOD OF FAN COVER With the hood up ,the Hook release lever can be removed by pulling downward, having first detached the hood lamp wiring harness.
  • Page 71 BLEEDING THE FUEL SYSTEM 5. Fuel injection pump 4. Fuel filter 1. Fuel Tank 3. Fuel feed pump 2. Water separator 1) Fill the tank with fuel and turn the ignition key to on. 2) Loosen the air breather screw of the fuel filter two or three turns.
  • Page 72 ► CHANGING THE OILS IN THE TRACTOR Always use quality oils as engine or transmission oil Refer to the table on page 61and 62 for the change frequency. ► CHANGING ENGINE OIL Park tractor on level surface, shut-off engine. Remove sump plug & drain oil. Replace and check the sump plug and refill he engine with oil to the correct level on the dipstick (approx.
  • Page 73 ► CHANGING OIL IN THE FRONT AXLE 1. Drain the oil from the center diff plug and the drain plug in each drive. 2. Replace and tighten all drain plugs. 3. Remove the Fill/Lever Plugs from each final drive to vent air from final drives. 4.
  • Page 74 ► HYDRAULIC OIL FILTER AND ENGINE OIL FILTER CARTRIDGE Remove the filter with a filter wrench. To replace, apply oil or grease on the seal, fit by hand until seal contacts bare, then turn it 2/3 turn further to tighten it check for leaks. ►...
  • Page 75 ► ANTI FREEZE Frozen cooling water can damage the engine. Before replacing the anti freeze solution flush the radiator. Mix the anti freeze solution in accordance with the instructions applicable to the brand of anti freeze and the locals climate. Replace the solution in the radiator.
  • Page 76 ► GAP ADJUSTMENT ► ADJUSTING THE CLUTCH Using the clutch over a period of time will increase the free play. The correct free play of the pedal is 0.78~1.18 in To adjust, loosen the locknut on the turnbuckle and adjust. Check the adjustment and tighten the locknut if the free play is correct.
  • Page 77 ► CHECKING THE BATTERY Indicator condition Check the Indicator condition Green color – Good condition Black color – Charging necessary White color – Replace battery Low electrolyte levels can cause premature battery failure and corrosion. important Electrolyte contains acid and can cause serious burns. Any spillage on skin should be washed off by running water immediately.
  • Page 78 Always disconnect the negative terminal first when removing the battery and always connect the positive terminal first when fitting the battery. When connecting the battery leads make sure not to reverse the polarity. Quick charging will reduce battery life. Caution Disconnect the terminals prior to charging the battery to avoid damage to the circuit and electrical instruments.
  • Page 79 ► CHECKING HOSES AND LINES The fuel lines, radiator hoses, hydraulic and rubber hoses are consumables, which deteriorate by age and use. Check them regularly and replace if faulty. Damaged fuel lines leak and cause fires. Damaged radiator hoses can cause hot water burns and in severe cases seize the engine. Caution ►...
  • Page 80 Always check the reason for a blown fuse otherwise the new fuse is also likely to blow. NEVER EVER USE WIRE in place of correct grade fuse. important ► SERVICE PRIOR TO DAILY AND SHORT TERMS STORAGE. Wash the tractor and keep it clean. Fill the tank to avoid condensation and rust.
  • Page 81 MAINTENANCE For daily or short term storage Clean the tractor and remove all dirt from field work. Fill the fuel tank to avoid condensation and rust. Lower the implement to the ground.. Keep it in a machinery shed or, if not available cover the unit if left outside. In very cold conditions it is advisable to remove the battery and keep it inside in a warm environment.

  • Page 82: Section C

    For further information concerning your Tractor and equipment, consult your Authorized TYM Dealer/Distributor. TYM policy is one of continuous improvement and the right to change prices, specifications or equipment at any time without notice is reserved. All date given in this book is subject to production variations.
  • Page 83 Model: T354 CLUTCH ENGINE Type : Dry single plate 4-stroke, 4-cylinders, naturally aspirated, Outer dia. X Inner dia. : 8.86 X 5.9″ indirect injection Model (YANMAR): T354 TRANSMISSION No. of cylinders Type : synchro mesh Displacement : 1,642 Bore : 88mm (3.46 in) No.
  • Page 84 Type Water cooled 4 cycle 4 cylinder diesel T354 – 25.5 / 2800rpm Out put (Kw/rpm) Number of Cylinder 1,642 Displacement (cc) T354 - 88 mm X 90mm Bore and Stroke Engine T354 – 19.1 Compression ratio Firing order 1-3-2-1...
  • Page 85 T354 MODEL Main Dry single disc, mechanic Clutch Multiple wet disk Dimensions Overall length(mm) 3350 (131.9”) Overall width (mm) 1645 (64.76”) Overall Height (mm) 2420 (95.26”) Wheel base (mm) 1137 (44.76”) (Distance between shafts) Min. Ground Clearance (mm) 243 (9.57”)
  • Page 86 Traveling Speed : Km/hour (mile/hour) MODEL T354 Range shift Main shift Forward Reverse 0.89 0.80 1.22 1.10 1.57 1.42 2.16 1.96 2.80 2.54 3.85 3.49 4.95 4.49 6.83 6.19 8.95 8.12 12.29 11.14 15.80 14.32 21.81 19.78 *The specifications are subject to change for improvement without notice.

  • Page 87: Fuel Saving Tips 85~86

    FUEL SAVING TIPS To save fuel & oil in your tractor, following things should always be kept in mind. A) Air cleaning system 1) Clean the air cleaner regularly so that dust does not settle down. 2) For every 50 hours & everyday in sandy/dusty conditions. (a) Clean the air cleaner filter element with compressed air.
  • Page 88 E) Engine system 1) Always use recommended grade of oil. 2) Everyday before starting the engine, check the oil level with a dipstick & refill between the minimum & maximum level. 3) Charge the engine oil, Replace filter & “O” ring, as & when required. F) Cooling system 1) Check the fan belt tension regularly.

  • Page 89: Fault Tracing

    FAULT TRACING SYMPTOM CAUSE REMEDY Turning the main switch Clutch not pushed in Push the clutch in will not operate the starter Battery flat Charge or replace the battery Dealer to repair or replace Switch faulty Contact dealer for repair or replace Starter operates but not Low battery...
  • Page 90 SYMPTOM CAUSE REMEDY White smoking from the Oil level too high Reduce to correct quantity exhaust Shortage of or faulty fuel Contact dealer for repair Reduced performance of The injectors are clogged, Contact dealer for repair the engine carbon coated and sticking Low compression Leaking valve seat Contact dealer for repair...
  • Page 91 SYMPTOM CAUSE REMEDY The clutch slips Incorrect adjustment Adjust to correct free play Worm or burnt lining Contact dealer for repair The clutch does not Incorrect adjustment Adjust to correct free play Contact disengage Rusty clutch lining dealer for repair Brake not working Incorrect free play Worm Adjust to correct free play Contact...
  • Page 92 SYMPTOM CAUSE REMEDY Steering wheel shaking Wrong toe-in Adjust toe-in Unequal tire pressure Inflate both to correct pressure Loose component Tighten or replace if worn Excessive play in the Worn steering shaft Contact dealer for repair steering Worn components Contact dealer for repair Flat battery Faulty wiring Repair,reconnect or tighten as...

  • Page 93: Wiring Diagram

    ► Drawing for fixing position of the fuse ► Wiring diagram of the electric instrument * Main Fuse Panel Light / Horn Head lamp 12V/55W/60W Turn Signal Lamp Meta panel Light 12V/3.4W (Instrument) Stop / Tail Lamp Turn Signal Lamp 12V/21W Turn Signal Lamp Tail Lamp)
