Thank you for purchasing our tractor. We are confident it will give you many years of reliable Service.
The introduction in this manual sets out the correct manner of operating, maintaining and checking the tractor
to ensure long-term durability.
Please ensure correct operation of the tractor as incorrect operation can cause substantial mechanical damage
as well as cause accidents with the associated injuries.
Please note that in some cases differences can exist between this manual and your tractor due to the manu-
facture's policy of constant product improvement.
In the event that you encounter a problem not covered by this manual please contact your nearest dealer
who will assist you in resolving your problem.
WARNING
T394NC,ST-영문-01A(안).indd 1
FOREWORD
CALIFORNIA Proposition 65 Warning
The Engine Exhaust from this product contains chemicals known to
the state of California to cause cancer, birth defects or other repro-
ductive harm.
FOREWORD
