Thank you very much for purchasing our tractor. We are confident it will give you many years of reliable service.
Read this manual carefully before using the tractor. The instruction in this manual set out the correct which manner of operating,
maintaining and checking the tractor to ensure long-term durability.
Please ensure correct operation of the tractor as incorrect operation can cause substantial mechanical damage as well as cause
accidents with the associated injuries.
Please note that in some cases differences can exist between this manual and your tractor due to the manufacture's policy of
constant product improvement.
In the event that you strike a problem not covered by this manual, please contact your nearest dealer who will assist you in
resolving your problem.
WARNING
FOREWORD
CALIFORNIA Proposition 65 Warning
The Engine Exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects
or other reproductive harm.
FOREWORD
