  • Page 1 MEG Z790 GODLIKE Motherboard User Guide...

  • Page 2: Table Of Contents

    Contents Quick Start........................4 Specifications ......................16 Special Features ......................22 Package Contents ...................... 23 Back Panel Connectors ..................... 24 LAN Port LED Status Table .................. 26 Audio Jacks Connection ..................26 Installing Antennas ....................28 Connecting Thunderbolt Devices via Daisy-chain..........29 Overview of Components ...................
  • Page 3 LED_SW1: EZ LED Control ................... 64 Debug Code LED ....................65 Boot Phases ......................65 Debug Code LED Table ..................65 Installing OS, Drivers & MSI Center ................72 UEFI BIOS ........................73 BIOS Setup ......................74 Resetting BIOS ...................... 75 Updating BIOS .......................

  • Page 4: Quick Start

    Quick Start Thank you for purchasing a new motherboard from MSI®. This Quick Start section provides demonstration diagrams about how to install your computer. Some of the installations also provide video demonstrations. Please link to the URL to watch it with the web browser on your phone or tablet.
  • Page 5 Safety Information ∙ The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. ∙ Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start.
  • Page 6 Case stand-off notification To prevent damage to the motherboard, any unnecessary mounting stand-off between the motherboard circuits and the computer case is prohibited. The Case standoff keep out zone signs will be marked on the backside of motherboard (as shown below) to serve as a warning to user.
  • Page 7 Installing a Processor ⚽ ∙ https://youtu.be/KMf9oIDsGes...
  • Page 8 Installing DDR5 memory ⚽ ∙ https://youtu.be/XiNmkDNZcZk DIMMA1 DIMMA2 DIMMA2 DIMMA2 DIMMB1 DIMMB2 DIMMB2...
  • Page 9 Connecting the Front Panel Header ⚽ ∙ http://youtu.be/DPELIdVNZUI Power LED Power Switch JFP1 Reserved HDD LED Reset Switch JFP1 HDD LED - HDD LED HDD LED + POWER LED - POWER LED POWER LED +...
  • Page 10 Installing the Motherboard ⚽ ∙ https://youtu.be/wWI6Qt51Wnc Torque: 3 kgf·cm* *3 kgf·cm = 0.3 N·m = 2.6 lbf·in...
  • Page 11 Connecting the Power Connectors ⚽ ∙ http://youtu.be/gkDYyR_83I4 ATX_PWR1 PD_PWR1 CPU_PWR1~2...
  • Page 12 Installing SATA Drives ⚽ ∙ http://youtu.be/RZsMpqxythc...
  • Page 13 Installing a Graphics Card ⚽ ∙ http://youtu.be/mG0GZpr9w_A...
  • Page 14 Connecting Peripheral Devices...
  • Page 15 Power On...

  • Page 16: Specifications

    Specifications ∙ Supports 12th/ 13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors* ∙ Processor socket LGA1700 * Please go to www.msi.com to get the newest support status as new processors are released. Chipset Intel® Z790 Chipset ∙ 4x DDR5 memory slots, supporting up to 192GB* ∙...
  • Page 17 Continued from previous column Intel® JHL8540 Thunderbolt™ 4 Controller ∙ 2x Thunderbolt™ 4 USB-C ports with DisplayPort Alt mode/ USB4 20Gbps/ Power Delivery up to 15W on the back panel • Supports up to 40Gbps transfer rate with Thunderbolt devices •...
  • Page 18 Continued from previous column ∙ 7x M.2 slots (Key M) • M2_1 slot (From CPU) • Supports up to PCIe 4.0 x4 • Supports 2260/ 2280/ 22110 storage devices • M2_2 & M2_3 slots (From Z790 chipset) • M2_2 slot supports up to PCIe 4.0 x4 •...
  • Page 19 Continued from previous column Intel® Wi-Fi 6E ∙ The Wireless module is pre-installed in the M.2 (Key-E) slot ∙ Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (160MHz) up to 2.4Gbps Wi-Fi & Bluetooth® ∙ Supports 802.11 a/ b/ g/ n/ ac/ ax ∙...
  • Page 20 Continued from previous column ∙ 1x Power button ∙ 1x Reset button Buttons ∙ 1x Clear CMOS button on the back panel ∙ 1x Flash BIOS button on the back panel ∙ 1x Smart button on the back panel ∙ 1x Clear CMOS jumper ∙...
  • Page 21 ∙ UEFI AMI BIOS ∙ ACPI 6.4, SMBIOS 3.5 ∙ Multi-language ∙ Drivers ∙ MSI Center ∙ Intel Extreme Tuning Utility Software ∙ MSI APP Player (BlueStacks) ∙ CPU-Z MSI GAMING ∙ Norton 360 Deluxe ∙ AIDA64 Extreme - MSI Edition...

  • Page 22: Special Features

    • Super Charger • EZ M.2 Clips • Devices Speed Up • M-Vision Dashboard • Smart Image Finder • EZ DEBUG LED • MSI Companion • EZ LED Control • System Diagnosis • Smart Button Thermal Features • System Saver •...

  • Page 23: Package Contents

    Package Contents Please check the contents of your motherboard package. It should contain: Board • 1x Motherboard Documentation • 1x Quick installation guide • 1x European Union Regulatory Notices Application • 1x USB drive with drivers & utilities Cables • 3x SATA 6Gb/s cables •...

  • Page 24: Back Panel Connectors

    Back Panel Connectors Item Description Clear CMOS button - Power off your computer. Press and hold the Clear CMOS button for about 5-10 seconds to reset BIOS to default values. 2.5 Gbps LAN port USB 3.2 Gen 2 (10Gbps) Type-A port (From Z790 chipset) ∙...
  • Page 25 Item Description Smart button - We provide 4 functions for the smart button to achieve. Please refer to the BIOS manual for details about selecting the smart button function. ∙ Reset (default) - press the smart button to reset the system. ∙...

  • Page 26: Lan Port Led Status Table

    LAN Port LED Status Table Link/ Activity LED Speed LED Status Description 2.5Gb LAN 10Gb LAN Status Speed Speed No link 10 Mbps － Yellow (For Linked 2.5Gb LAN) 100 Mbps/ 100 Mbps/ Green 1 Gbps/ 1 Gbps Green (For 2.5 Gbps Linked 10Gb LAN)
  • Page 27 Audio jacks to 4-channel speakers diagram AUDIO INPUT Rear Front Audio jacks to 5.1-channel speakers diagram AUDIO INPUT Rear Front Center/ Subwoofer Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Rear Front Side Center/ Subwoofer...

  • Page 28: Installing Antennas

    Installing Antennas 1. Combine the antenna with the base. 2. Screw two antenna cables tight to the WiFi antenna connectors as shown. 3. Place the antenna as high as possible.

  • Page 29: Connecting Thunderbolt Devices Via Daisy-Chain

    Connecting Thunderbolt Devices via Daisy-chain Daisy-chain is a method of connecting multiple devices to a PC with only one output terminal. Daisy-chain allows you to connect multiple thunderbolt devices to a single thunderbolt port on the back panel. You can also daisy chain monitor by connecting graphics card to the Mini DisplayPort Input port on the back panel.

  • Page 30: Overview Of Components

    Overview of Components JARGB_V2_3 SYS_FAN1 SYS_FAN2 SYS_FAN3 ATX_PWR1 PD_PWR1 M2_7 JUSB6 M2_1 M2_6 JUSB5 PCI_E1 JUSB4 M2_2 M2_3 JUSB3 M2_5 PCI_E2 SATA▼5▲6 SATA▼7▲8 M2_4 SATA▼A1▲A2 JPWRLED1 JFP2 JARGB_V2_2 JSLOW1...

  • Page 31: Cpu Socket

    ∙ Always unplug the power cord from the power outlet before installing or removing the CPU. Please retain the CPU protective cap after installing the processor. MSI will deal ∙ with Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.

  • Page 32: Dimm Slots

    It is recommended to use a more efficient memory cooling system for full DIMMs ∙ installation or overclocking. The stability and compatibility of installed memory module depend on installed CPU ∙ and devices when overclocking. ∙ Please refer to www.msi.com for more information on compatible memory.

  • Page 33: Pci_E1~2: Pcie Expansion Slots

    Important ∙ If you install a large and heavy graphics card, you need to use a tool such as MSI Graphics Card Bolster to support its weight to prevent deformation of the slot. For a single PCIe x16 expansion card installation with optimum performance, using ∙...

  • Page 34: M2_1~7: M.2 Slots (Key M)

    M2_1~7: M.2 Slots (Key M) Watch the video to learn how to Install M.2 SSD with Screwless M2_6 M.2 Shield Frozr heatsink. M2_7 ⚽ M2_1 M2_2 M2_3 M2_5 ∙ https://youtu.be/J88vcXeLido M2_4 ⚠ Important ∙ Intel® RST only supports PCIe M.2 SSD with UEFI ROM. If your M.2 SSD equips its own heatsink, please remove the M.2 plate or rubber cube ∙...
  • Page 35 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink. 3. Remove the protective film includeing the rubber cube from the M.2 thermal pads on the M.2 plate. 4. Remove or exchange the screws according to your SSD length. Skip this step, if you install 2280 SSD.
  • Page 36 5. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 6. Rotate the EZ M.2 Clip to fix the M.2 SSD. 30º 30º 30º 30º 2280 SSD 2260 SSD 22110 SSD 7. Remove the protective films from the thermal pads under Screwless M.2 Shield Frozr heatsink.
  • Page 37 Installing M.2 module into M2_2/ M2_3 slot 1. Loosen the screws of M.2 Shield Frozr heatsink. 2. Lift the M.2 Shield Frozr heatsink up and remove it. 3. Remove the protective films from the M.2 thermal pads on the M.2 plate. 4.
  • Page 38 5. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 6. Rotate the EZ M.2 Clip to fix the M.2 SSD. 30º 30º 30º 30º 2260 SSD 2280 SSD 7. Remove the protective films from the thermal pads under the M.2 Shield Frozr heatsink.
  • Page 39 Installing M.2 module into M2_4/ M2_5 slot 1. Loosen the screws of M.2 Shield Frozr heatsink. 2. Lift the M.2 Shield Frozr heatsink up and remove it. 3. Remove the protective films from the M.2 thermal pads on the M.2 plate.
  • Page 40 4. If there is a plate screw installed on the M.2 plate, remove it first; otherwise, please skip this step. 5. Install the supplied EZ M.2 Clip kit on the M.2 plate according to your M.2 SSD length. 6. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 7.
  • Page 41 Ways to install M2_4 & M2_5 2260 SSD 22110 SSD 2280 SSD 2280 SSD...
  • Page 42 8. Remove the protective films from the thermal pads under the M.2 Shield Frozr heatsink. 9. Put the M.2 Shield Frozr heatsink back in place and secure it.
  • Page 43 Installing M.2 module into M2_6/ M2_7 slot 1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink. 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink. 3.
  • Page 44 4. If you install 2260 SSD, remove the plate screw from the M.2 plate and then install supplied EZ M.2 Clip kit on the M.2 plate. Skip this step if you install 2280 SSD. 2260 SSD 5. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 6.
  • Page 45 7. Remove the protective films from the thermal pads under Screwless M.2 Shield Frozr heatsink. 8. Align the tenons under Screwless M.2 Shield Frozr heatsink with the notches, and then put the heatsink back in place. 9. Press the end side of Screwless M.2 Shield Frozr heatsink to lock it completely.

  • Page 46: Sata_5~8 & Sata_A1~A2: Sata 6Gb/S Connectors

    SATA_5~8 & SATA_A1~A2: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA_6 SATA_5 SATA_8 SATA_7 SATA_A2 SATA_A1 ⚠ Important ∙ Please do not fold the SATA cable at a 90-degree angle. Data loss may result during transmission otherwise.

  • Page 47: Jfp1, Jfp2: Front Panel Connectors

    JFP1, JFP2: Front Panel Connectors The JFP1 connector controls the power on, power reset, and the LEDs on your PC case/chassis. Power Switch/ Reset Switch headers allow you to connect power button/ reset button. Power LED header connects to LED light on the PC case, and HDD LED header indicates the activity of the hard disk.

  • Page 48: W_Flow1: Water Flow Meter Connector

    W_FLOW1: Water Flow Meter Connector This connector allows you to connect a water flow meter to monitor the flow rate of your liquid cooling system. Signal Name Signal Name Ground WFLOW PWR WFLOW IN JDASH1 : Tuning Controller connector This connector is used to connect an optional Tuning Controller module. Signal Name Signal Name No Pin...

  • Page 49: Cpu_Pwr1~2, Atx_Pwr1, Pd_Pwr1: Power Connectors

    CPU_PWR1~2, ATX_PWR1, PD_PWR1: Power Connectors These connectors allow you to connect an ATX power supply. CPU_PWR1~2 Signal Name Signal Name Ground Ground Ground Ground +12V +12V +12V +12V ATX_PWR1 Signal Name Signal Name CPU_PWR1~2 +3.3V +3.3V Ground Ground Ground PWR OK ATX_PWR1 5VSB +12V...

  • Page 50: Jci1: Chassis Intrusion Connector

    JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis (default) intrusion event Using chassis intrusion detector 1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis. 2.

  • Page 51: Jusb5~6: Usb 3.2 Gen 2X2 Type-C Front Panel Connectors

    JUSB5~6: USB 3.2 Gen 2x2 Type-C Front Panel Connectors These connectors allow you to connect USB 3.2 Gen 2x2 20Gbps Type-C front panel connectors on the front panel. The connectors possess a foolproof design. When you connect the cable, be sure to connect it with the corresponding orientation. JUSB6 USB Type-C Cable JUSB5~6...

  • Page 52: Jusb1~2: Usb 2.0 Connectors

    ∙ In order to recharge your iPad, iPhone and iPod through USB ports, please install MSI Center utility. JTPM1: TPM Module Connector This connector is for TPM (Trusted Platform Module). Please refer to the TPM security platform manual for more details and usages.

  • Page 53: Jslow1: Slow Mode Booting Jumper

    JSLOW1: Slow Mode Booting Jumper This jumper is used for LN2 cooling solution, that provides the extreme overclocking conditions, to boot at a stable processor frequency and to prevent the system from crashing. Normal Enabled (Default) (Please enable this jumper during BIOS POST.) JLN1~2: Low Temperature Booting Jumper This jumper allows liquid nitrogen cooling system to boot at an extremely low...

  • Page 54: Joc_Fs1: Safe Boot Jumper

    JOC_FS1: Safe Boot Jumper This jumper is used for Safe Boot. When this jumper is enabled, the system will boot with default settings and lower PCIe (from CPU) mode. Normal (default) Enabled Boot with the saved Apply the BIOS default BIOS settings.

  • Page 55: T_Sen1~2: Thermal Sensor Connector

    BIOS B BIOS A (Default) ⚠ Important ∙ Do not use the Multi-BIOS switch when system is booting up. ∙ You can also use the MSI Center or Flash BIOS Button to flash BIOS. Please refer to BIOS section for details.

  • Page 56: Cpu_Fan1, Pump_Fan1~2, Sys_Fan1~7: Fan Connectors

    CPU_FAN1, PUMP_FAN1~2, SYS_FAN1~7: Fan Connectors Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode. PWM Mode fan connectors provide constant 12V output and adjust fan speed with speed control signal. DC Mode fan connectors control fan speed by changing voltage. The auto mode fan connectors can automatically detect PWM and DC mode.

  • Page 57: Jbat1: Clear Cmos (Reset Bios) Jumper

    JBAT1: Clear CMOS (Reset BIOS) Jumper There is CMOS memory onboard that is external powered from a battery located on the motherboard to save system configuration data. If you want to clear the system configuration, set the jumpers to clear the CMOS memory. Keep Data Clear CMOS/ (default)

  • Page 58: Bat1： Cmos Battery

    BAT1： CMOS Battery If the CMOS battery is out of charge, the time in the BIOS will be reset and the data of system configuration will be lost. In this case, you need to replace the CMOS battery. Replacing CMOS battery 1.

  • Page 59: M_Sw1: M-Vision Switch

    M-Vision Dashboard (Default) Features on M-Vision Dashboard ∙ 4.5 inch IPS LCD panel (resistive single touch) ∙ Full color display (480x 800) ∙ Touch control ∙ USB Type-C connection ∙ Speaker function ∙ Landscape/ portrait orientation ∙ Customizable with MSI Center...
  • Page 60 1. Use the supplied M-Vision cable to connect the M-Vision Dashboard and specified USB port (M-Vision Dashboard port) on the back panel. 2. Switch the M-Vision switch (M_SW1) to the M-Vision mode. M-Vision Dashboard port M-Vision cable ⚠ Important For more information on M-Vision Dashboard, please refer to https://download.msi.com/archive/mnu_exe/mb/M-VISIONDASHBOARD.pdf for more details.

  • Page 61: Jrgb1: Rgb Led Connector

    (12V/G/R/B) with the maximum power rating of 3A (12V). Always turn off the power supply and unplug the power cord from the power outlet ∙ before installing or removing the RGB LED strip. Please use MSI’s software to control the extended LED strip. ∙...

  • Page 62: Jargb_V2_1~3: A-Rainbow V2 (Argb Gen2) Led Connectors

    JARGB_V2_1~3: A-RAINBOW V2 (ARGB Gen2) LED connectors The JARGB_V2 connectors allow you to connect the ARGB Gen2 and the ARGB-based LED strips. The JARGB_V2 connector supports up to 240 individually addressable RGB LEDs with maximum power rating of 3A (5V). Signal Name Signal Name Data...
  • Page 63 It is recommended that you install LED strips with the same specification to achieve the best effects. Always turn off the power supply and unplug the power cord from the power outlet ∙ before installing or removing the addressable RGB LED strip. Please use MSI’s software to control the extended LED strip. ∙...

  • Page 64: Onboard Leds

    Onboard LEDs EZ Debug LED These LEDs indicate the debug status of the motherboard. CPU - indicates CPU is not detected or fail. DRAM - indicates DRAM is not detected or fail. VGA - indicates GPU is not detected or fail. BOOT - indicates the booting device is not detected or fail.

  • Page 65: Debug Code Led

    Debug Code LED The Debug Code LED displays progress and error codes during and after POST. Refer to the Debug Code LED table for details. Hexadecimal Character Table Hexadecimal LED display Hexadecimal LED display Boot Phases Security (SEC) – initial low-level initialization Pre-EFI Initialization (PEI) –...
  • Page 66 PEI Progress Codes PEI Core is started Pre-memory CPU initialization is started 12 - 14 Pre-memory CPU initialization (CPU module specific) Pre-memory System Agent initialization is started 16 - 18 Pre-Memory System Agent initialization (System Agent module specific) Pre-memory PCH initialization is started 1A - 1C Pre-memory PCH initialization (PCH module specific) Memory initialization.
  • Page 67 Memory initialization error. Invalid memory size or memory modules do not match Memory initialization error. No usable memory detected Unspecified memory initialization error Memory not installed Invalid CPU type or Speed CPU mismatch CPU self test failed or possible CPU cache error CPU micro-code is not found or micro-code update is failed Internal CPU error Reset PPI is not available...
  • Page 68 Boot Device Selection (BDS) phase is started Driver connecting is started PCI Bus initialization is started PCI Bus Hot Plug Controller Initialization PCI Bus Enumeration 32 PCI Bus Request Resources PCI Bus Assign Resources Console Output devices connect Console input devices connect Super IO Initialization USB initialization is started USB Reset...
  • Page 69 Runtime Set Virtual Address MAP Begin Runtime Set Virtual Address MAP End Legacy Option ROM Initialization System Reset USB hot plug PCI bus hot plug Clean-up of NVRAM Configuration Reset (reset of NVRAM settings) B8 - BF Reserved for future AMI codes DXE Error Codes CPU initialization error System Agent initialization error...
  • Page 70 E4 - E7 Reserved for future AMI progress codes S3 Resume Error Codes S3 Resume Failed S3 Resume PPI not Found S3 Resume Boot Script Error S3 OS Wake Error EC - EF Reserved for future AMI error codes Recovery Progress Codes Recovery condition triggered by firmware (Auto recovery) Recovery condition triggered by user (Forced recovery) Recovery process started...
  • Page 71 System is waking up from the S3 sleep state System is waking up from the S4 sleep state System has transitioned into ACPI mode. Interrupt controller is in PIC mode. System has transitioned into ACPI mode. Interrupt controller is in APIC mode.

  • Page 72: Installing Os, Drivers & Msi Center

    MSI Center is an application that helps you easily optimize game settings and smoothly use content creation softwares. It also allows you to control and synchronize LED light effects on PCs and other MSI products. With MSI Center, you can customize ideal modes, monitor system performance, and adjust fan speed.

  • Page 73: Uefi Bios

    UEFI has many new functions and advantages that traditional BIOS cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’s capabilities.

  • Page 74: Bios Setup

    * When you press F10, a confirmation window appears and it provides the modification information. Select between Yes or No to confirm your choice. BIOS User Guide If you’d like to know more instructions on setting up the BIOS, please refer to https://download.msi.com/archive/mnu_exe/mb/Intel700BIOS.pdf or scan the QR code to access. ⚠ Important...

  • Page 75: Resetting Bios

    Updating BIOS Updating BIOS with M-FLASH Before updating: Please download the latest BIOS file that matches your motherboard model from MSI website. And then save the BIOS file into the USB flash drive. Updating BIOS: 1. Switch to the target BIOS ROM by Multi-BIOS switch. Please skip this step if your motherboard doesn’t has this switch.
  • Page 76 1. Please download the latest BIOS file that matches your motherboard model from the MSI® website. 2. Rename the BIOS file to MSI.ROM, and save it to the root of the USB storage device. 3. Connect the power supply to CPU_PWR1 and ATX_PWR1. (No need to install CPU and memory.)

  • Page 77: Block Diagram

    Block Diagram MEG Z790 GODLIKE DDR5 PCIe 5.0x16 PCI_E1 DIMM A1/A2 PCIe 5.0 X8 DIMM B1/B2 PCIe 5.0 X8 PCIe 5.0 X8 GEN4 x4 M.2_1 (PCIe Only) PCIe 5.0 X8 PCIe 5.0x8 PCI_E2 GEN5 x4 M.2_4 (PCIe Only) DMI 4.0 Intel 2.5Gbps +...

  • Page 78: Regulatory Notices

    ∙ This device may not cause harmful interference. ∙ This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www.msi.com...
  • Page 79 ∙ ErP Directive 2009/125/EC Compliance with these directives is assessed using applicable European Harmonized Standards. The point of contact for regulatory matters is MSI-Europe: Eindhoven 5706 5692 ER Son. Products with Radio Functionality (EMF) This product incorporates a radio transmitting and receiving device. For computers in normal use, a separation distance of 20 cm ensures that radio frequency exposure levels comply with EU requirements.
  • Page 80 Wireless Radio Use This device is restricted to indoor use when operating in the 2.4GHz, 5GHz, 6GHz frequency band. Cet appareil doit être utilisé à l’intérieur. 당해 무선설비는 운용중 전파혼신 가능성이 있음. この製品は 、 周波数帯域 2.4GHz, 5GHz, 6GHz で動作しているときは 、 屋内においてのみ使 用可能です...
  • Page 81 KC인증서 상호: (주)엠에스아이코리아 제품명: 메인보드 모델명: 10-7D85 제조년월: 2022년 R-R-MSI-10-7D85 제조자 및 제조국가: MSI/중국 상호: (주)엠에스아이코리아 제품명: USB FLASH DRIVE 모델명: USB2VR09 제조년월: 2023년 R-R-MSI-USB2VR09 제조자 및 제조국가: MSI/중국 상호: (주)엠에스아이코리아 제품명: USB FLASH DRIVE 모델명: USB3VR09 제조년월: 2023년 R-R-MSI-USB3VR09 제조자...
  • Page 82 ∙ Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products. ∙ Visit the MSI website and locate a nearby distributor for further recycling information. ∙ Users may also reach us at gpcontdev@msi.com for information regarding proper Disposal, Take-back, Recycling, and Disassembly of MSI products.
  • Page 83 MSI will comply with the product take back requirements at the end of life of MSI- branded products that are sold into the EU. You can return these products to local collection points.
  • Page 84 MSI će poštovati zahtev o preuzimanju ovakvih proizvoda kojima je istekao vek trajanja, koji imaju MSI oznaku i koji su prodati u EU. Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.
  • Page 85 MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti all’interno dell’Unione Europea alla fine del loro ciclo di vita.
  • Page 86 Việt Nam RoHS Kể từ ngày 01/12/2012, tất cả các sản phẩm do công ty MSI sản xuất tuân thủ Thông tư số 30/2011/TT-BCT quy định tạm thời về giới hạn hàm lượng cho phép của một số hóa chất độc hại có trong các sản phẩm điện, điện tử”...
  • Page 87 限用物質含有情況標示聲明書 設備名稱 ： 電腦主機板 型號(型式) ： MS-7D85 限用物質及其化學符號 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (PBB) (PBDE) 電路板 ○ ○ ○ ○ ○ ○ 電子元件 ─ ○ ○ ○ ○ ○ 金屬機構件 ─ ○ ○ ○ ○ ○...
