INSTALLATION INSTRUCTIONS
Thank you for purchasing SRT-2
Spool Roll Tarp. Agri-Cover, Inc. proudly
®
manufactured this tarp using superior quality materials and workmanship. With proper
care, your tarp will provide years of service.
NOTICE TO INSTALLER: Even if familiar with product, read instructions prior to
installation as improvements may be made without notice. Always handle components
with care. If you have questions or problems, have serial number ready and call
customer service. When done, these instructions must be given to the consumer.
NOTICE TO CONSUMER: Before using this product, read operating, maintenance and
safety sections. Save these instructions for future reference.
FOR YOUR RECORDS
DATE PURCHASED:
WHERE PURCHASED:
TARP SERIAL NUMBER:
(Located at rear of tarp on stationary tube side)
Questions? (800) 233-4655
agricover.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRT-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGRI-COVER SRT-2

Summary of Contents for AGRI-COVER SRT-2

  • Page 1 INSTALLATION INSTRUCTIONS Thank you for purchasing SRT-2 Spool Roll Tarp. Agri-Cover, Inc. proudly ® manufactured this tarp using superior quality materials and workmanship. With proper care, your tarp will provide years of service. NOTICE TO INSTALLER: Even if familiar with product, read instructions prior to installation as improvements may be made without notice.
  • Page 2 PREPARATION • Prior to tarp system assembly, park truck or trailer on level ground. • Box must be square and straight, center must not be pulled together or spread apart. • Before beginning, measure outer length and width of your box. Also measure length of tarp and width of the end caps to ensure you received the correct size.

  • Page 3: Safety Information

    SAFETY INFORMATION DANGER: Mounting replacement tarp to a structurally weak or damaged roll tube can result in serious injury or death. Before installing replacement tarp, inspect mounting surface of roll tube. Be aware several mounting holes in close proximity may compromise roll tube strength and integrity.
  • Page 4 1: INSTALLING AIR DAM NOTE: For stainless steel hardware, see Clamps page 2 for bolting procedures. A. Measure front width of box and air dam to ensure fit. NOTE: If two people are present, clamping is optional. 2” B. Position top of air dam 2” above box and clamp or hold in place.
  • Page 5 2: DETERMINING TARP STOP PLACEMENT NOTE: Tarp stops secure stationary side of tarp to box. • For normal roll applications, mount tarp stops on passenger side of box. • For reverse roll applications, mount tarp stops on driver side of box. A.
  • Page 6 3: MOUNTING TARP STOPS WITH WOOD EXTENSIONS Bolt, flat washer A. Measure 4” down from top of wood and nut 4” extension, place front and rear base brackets against wood extension and drill (4) 3/8” holes. Secure with (4) 3/8” x 2-1/2” bolts, flat washers and nuts.
  • Page 7 4: ATTACHING ROLL TUBE TO TARP A. On a clean floor, lay tarp out flat with rope in large pocket facing down and exterior side facing up (raw edge of hems and pockets are down). NOTE: Ensure holes in large pocket and roll tube are on same side of rope. B.
  • Page 8 5: ATTACHING STATIONARY TUBE TO TARP A. Tap end plug into each end of stationary tube. B. Slide stationary tube into small pocket. C. Align holes in tarp and stationary tube, then insert drive rivet. Ensure it is fully seated and set with hammer. D.
  • Page 9 6: ATTACHING SPOOLS NOTE: Spool marked R (right) use with red marked spring and cartridge. IMPORTANT: Do not use grease or lubricant on spools or tube. A. Slide spool onto end of roll tube according to (L) or (R) marking. •...
  • Page 10 7: INSTALLING TARP ASSEMBLY A. Roll tarp assembly by hand to open position, roll tube to stationary tube. Roll tube Upright B. Place stationary tube into base brackets. Bow-tie pin C. Center assembly from front to rear of box. Be careful not to let tarp roll off box. •...
  • Page 11 8: INSTALLING CABLES & RATCHETS NOTE: For stainless steel hardware, see page 2 for bolting procedures. A. Unroll tarp by hand to other side of box and let tarp hang down. Ensure tarp is still centered from front to back of box and make adjustments as needed. B.
  • Page 12 8: INSTALLING CABLES & RATCHETS (Continued) D. Determine location for diverter. The cable diverter should be positioned 1 to 2 degrees away from tarp while allowing the cable to angle, maintain tension and attach to rachet. E. Mark, then drill location with 3/8” bit. F.
  • Page 13 8: INSTALLING CABLES & RATCHETS (Continued) G. Route cable around diverter, attach ball end of cable to rachet to determine location for rachet. H. Pull down on ratchet while activating the release to extend ratchet to mark on strap, around 10-1/2” down. Mark (2) bolt locations on top of box. I.

  • Page 14: Cable Tension

    9: CABLE TENSION A. As tension is applied with ratchet, the spool will turn. Proper tension is achieved when the tension channel is level at bottom. TIP: Tighten ratchet an additional two clicks past level. Open and close tarp system approximately 5 times to pull tarp snug.
  • Page 15 10: MOUNTING LOWER PIVOT ARM NOTE: For manual installation proceed to Step 13. NOTE: For stainless steel see page 2 for Mounting bracket bolting procedures. A. At front of trailer, align center point of mounting bracket with center line of box. Self-threading bolts Using mounting bracket as a guide drill 5/16”...
  • Page 16 10: MOUNTING LOWER PIVOT ARM (Continued) C. Place flat washer on hex bolt, insert Flat washers through secondary bracket and secure with flat washer and nut. Bolt Secondary bracket D. Thread nylock nut on hex bolt and place Lower pivot arm flat washer on bolt.
  • Page 17 11: ATTACHING MOTOR A. Secure motor to upper pivot arm mount Bolt using (3) 5/16” x 3/4” bolts with lock washers. B. Slide upper pivot arm with motor over top of lower pivot arm. Lock washer Upper pivot arm mount Motor C.
  • Page 18 12: ELECTRICAL A. Locate and clean suitable locations to apply caution stickers. B. Refer to included instructions to complete wiring. 13: INSTALLING CRANK HANDLE ASSEMBLY A. Remove clevis and cotter pins securing PVC spacer at rear of box. B. Slide handle through PVC spacer and into cartridge protruding from spool. C.
  • Page 19 14: MOUNTING HANDLE HOLDER NOTE: For stainless steel hardware, see page 2 for bolting procedures. A. With tarp in closed position, snap handle holder onto crank handle and select best location on side or top rear corner. Mark hole. B. Roll tarp to open position and select best location on adjacent side or top corner. Mark hole.

  • Page 20: Troubleshooting

    Cable tension may be too loose. Check level of tension channels for proper tension. Holes or tears in tarp. Contact your local Agri-Cover dealer for replacement tarp or tarp repair kit. When new tarp or parts are needed replace with original Agri-Cover parts.

  • Page 21: Operation

    OPERATION TO CLOSE A. Use both hands to remove crank handle from holder. Extend crank handle to a comfortable operating position. B. Roll tarp to completely closed position. C. Push crank handle into holder and close. TO OPEN A. Use both hands to remove crank handle from holder. Extend crank handle to a comfortable operating position.

  • Page 22: Inspection And Maintenance

    • Check the tightness of mounting bolts and electrical connections, remove any dirt or corrosion that may have accumulated on the electrical connections. • Always use genuine Agri-Cover, Inc. replacement parts, use serial number to easily order replacement tarp. Serial number is located at rear...

  • Page 24: Manufacturer's Limited Warranty

    Goods to be returned must have a pre-authorized RA # (Return Authorization Number) – obtained by calling the number above. Mark the number on the package and ship it freight prepaid to address below. Agri-Cover will pay freight to return goods to sender.
