COMMERCIAL TOW FLAP
INSTALLATION INSTRUCTIONS
Thank you for purchasing ROCKSTAR
Commercial Tow Flap. Agri-Cover, Inc.
TM
proudly manufactured this tow flap using superior quality materials and workmanship.
With proper care, your tow flap will provide years of service and enjoyment.
NOTICE TO INSTALLER: Even if familiar with product, read instructions prior to
installation as improvements may be made without notice. Always handle components
with care. If you have questions or problems, call customer service. When done, these
instructions must be given to the consumer.
NOTICE TO CONSUMER: Before using this product, read safety and maintenance
section of these instructions. Save these instructions for future reference.
FOR YOUR RECORDS
DATE PURCHASED:
WHERE PURCHASED:
Questions? 888-568-3709
agricover.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AGRI-COVER ROCKSTAR
Summary of Contents for AGRI-COVER ROCKSTAR
- Page 1 COMMERCIAL TOW FLAP INSTALLATION INSTRUCTIONS Thank you for purchasing ROCKSTAR Commercial Tow Flap. Agri-Cover, Inc. proudly manufactured this tow flap using superior quality materials and workmanship. With proper care, your tow flap will provide years of service and enjoyment. NOTICE TO INSTALLER: Even if familiar with product, read instructions prior to installation as improvements may be made without notice.
- Page 2 PREPARATION For additional installation assistance, go to rockstarmudflaps.com for install video. TOOLS NEEDED • In.-lbs. Torque wrench with 3/16" Allen head socket • Ratchet with 9/16" socket • Protective eyewear IMPORTANT: Always remove tow flap when driving off-road. Contact with obstacles may cause damage.
- Page 3 1: ASSEMBLING TOW FLAP NOTE: Always check ground clearance of flaps. Suggested clearance with a load is 3” minimum to prevent dragging. Install on vehicles with suspension modifications or oversized tires may exceed suggested clearance. Mud flaps still function, though performance may be affected.
- Page 4 1: ASSEMBLING TOW FLAP (Continued) D. Slide stabilizing bar over weld nuts ensuring stabilizing bar and inside of tow flap half are flush. Inside edge Stabilizing bar of tow flap Stabilizing bar Tow flap half Tow flap half E. Insert Allen button head bolt through tow flap half into end cap assembly in stabilizing bar.
- Page 5 1: ASSEMBLING TOW FLAP (Continued) H. Insert splice into stabilizing bar on one Splice Allen button tow flap half. Align bolt hole in splice with bolt head bolt hole in tow flap half, secure with Allen button head bolt. I. Torque bolt to 85 in.-lbs. Bolt hole J.
- Page 6 2: INSTALLING MOUNTING BRACKETS A. Refer to special instructions for mounting bracket attachment. 3: INSTALLING TOW FLAP A. On one side, insert hanger through back of mounting bracket. B. Repeat on opposite side. Mounting bracket Hanger C. Secure tow flap to mounting bracket with linch pin at both bracket locations.
- Page 7 SAFETY AND MAINTENANCE The operator can perform most of inspection and maintenance. It may be necessary to review the installation instructions. • Periodically check all bolts and nuts, retighten if needed. • Always remove tow flap before entering automatic car wash systems. •...
- Page 8 Agri-Cover, Inc. extends the following (1) year Limited Warranty for the Commercial Tow Flap: Agri-Cover, Inc. warrants a period of one (1) year from the date of manufacture that its ROCKSTAR Commercial Tow Flap is free from defects in workmanship, under normal use for the truck model it was intended for.
