Summary of Contents for TecTecTec KLYR
- Page 1 KLYR KEY FEATURES MAGNET SLOPE COMPACT TARGET LOCK VIBRATION BELT CLIP...
- Page 2 WE HOPE YOU ENJOY YOUR EXPERIENCE WITH OUR BRAND. FEEL FREE TO GIVE YOUR INSIGHTS AND FEEDBACK THROUGH THE FOLLOWING OUTLETS. BE WELL AND WE APPRECIATE YOU. Renan Lore FOUNDER EMAIL: US@TECTECTEC.COM INSTAGRAM: TECTECTECUSA WEB: US.TECTECTEC.COM FACEBOOK: TECTECTECUSA PHONE: (833) 383-2669...
-
Page 3: Warranty Registration
WARRANTY REGISTRATION PLEASE REGISTER AT US.TECTECTEC.COM/WARRANTY TO VALIDATE AND SUBSCRIBE TO THIS ALREADY INCLUDED FREE SERVICE. THE FOLLOWING IS INCLUDED: + 30 DAY MONEY BACK GUARANTEE + 2-YEAR LIMITED WARRANTY (ONLINE REGISTRATION REQUIRED) + ENROLLED AS A TECTECTEC! MEMBER + RECEIVE EXCLUSIVE DISCOUNTS... -
Page 4: What's In The Box
WHAT’S IN THE BOX + RANGEFINDER + BALL MARKER + STEEL BELT CLIP + CR2-3V BATTERY + MANUAL + CASE FEATURES + MAGNET + STEEL BELT CLIP + VISIBLE SLOPE SWITCH + ACCURATE WITHIN +/- 1 YARD + FAST AND EASY TO USE + COMPACT AND LIGHTWEIGHT + ERGONOMIC DESIGN + AUTOMATIC SHUT-OFF... - Page 5 SPECS + OBJECTIVE LENS 20MM + MAGNIFICATION + FIELD OF VIEW 7° + EXIT PUPIL DIAMETER 3.5MM + DIOPTER ADJUST RANGE ±5 + WORKING TEMPERATURE -20 TO 50°C + ACCURACY ±1 M (Y) + BATTERY TYPE CR2-3V + BATTERY METER + VIBRATION + FLAG-LOCK + WEIGHT (W/O BATTERY)
-
Page 6: Operational Components
OPERATIONAL COMPONENTS MODE POWER BUTTON BUTTON EYEPIECE BATTERY COVER TARGET SEEKER SLOPE SWITCH MAGNET... - Page 7 UNITS POWER BATTERY POWER CHANGE UNIT MEASUREMENTS TURN ON - PRESS BUTTON PRESS AND HOLD FOR (3 SECONDS) TURN OFF - AUTO (30 SECONDS) (YARDS OR METERS) BATTERY 1. TURN FLAP COUNTER 2. INSERT 3. TURN FLAP CLOCKWISE CLOCKWISE TO OPEN BATTERY TO CLOSE...
- Page 8 SLOPE FOCUS SLOPE TURN ON - SLIDE BUTTON RIGHT (EXPOSE YELLOW INDICATOR) TURN OFF - SLIDE BUTTON LEFT (NO YELLOW - TOURNAMENT MODE) FOCUS 1. LOOK THROUGH THE 2. TURN THE EYEPIECE/DIOPTER TO THE LEFT OR RIGHT UNTIL THE IMAGE IS CLEAR RUBBER EYEPIECE...
-
Page 9: Lcd Display Features
ACTUAL H. SLOPE - CORRECTED DISTANCE THE KLYR RANGEFINDER USES EYE-SAFE BEAMS TO MEASURE DISTANCE TO OBJECTS UP TO 800 YARDS AWAY, BY MEASURING THE TIME IT TAKES FOR THE LASER PULSE TO REFLECT OFF OF THE TARGET AND RETURN. -
Page 10: Mode: Normal
MODE: NORMAL 1. AIM AT THE OBJECT WHOSE DISTANCE YOU WANT TO CALCULATE. SCAN 2. PRESS THE POWER BUTTON ONCE BRIEFLY WHILE AIMING AT A TARGET, SUCH AS A BUNKER. THE DISPLAY SCREEN WILL SHOW THE DISTANCE. AFTER TAKING A MEASUREMENT, SCAN PRESS THE POWER BUTTON AGAIN TO FIND THE DISTANCE TO A NEW TARGET. - Page 11 MODE: SCAN 1. HOLD THE POWER BUTTON FOR 8 SECONDS. AT THE SAME TIME, SWEEP THE RANGEFINDER FROM SCAN OBJECT TO OBJECT. 2. THE DISPLAY SCREEN WILL SHOW CONTINUOUS DISTANCE MEASURE- MENT. PRESS THE POWER BUTTON SCAN TO FIND THE DISTANCE TO A NEW TARGET.
- Page 12 MODE: PIN SEEK VIBRATION 1. PRESS THE MODE BUTTON BRIEFLY TO SEE A FLAG ICON ON THE DISPLAY WHICH INDICATES THAT YOU ARE IN PIN SEEKER MODE. 2. TARGET AN OBJECT BEHIND THE FLAG. PRESS AND HOLD THE LOCK SCAN POWER BUTTON WHILE SLOWLY SWEEPING OVER THE FLAG..
- Page 13 MODE: SLOPE VIBRATION 1. SLIDE THE SLOPE SWITCH ON AND YOU WILL SEE THE ANGLE SYMBOL AND THE FLAG SYMBOL ON THE SCREEN AS AN INDICATOR. 2. PRESS THE POWER BUTTON AND AIM AT THE TARGET WHOSE DIS- LOCK TANCE YOU WANT TO CALCULATE. 3.
- Page 14 MODE: SLOPE PIN SEEKER A) THE DISTANCE SHOWN IN THE LARGE FONT SIZE WILL BE THE FULL DISTANCE. C) THE DISTANCE SHOWN, LOWER LEFT CORNER, IS THE UP/DOWN (+/-) SLOPE CORRECTED DISTANCE. LOCK D) THE DISTANCE SHOWN, LOWER RIGHT CORNER, IS THE CALCU- LATED ACTUAL DISTANCE.
-
Page 15: Maintenance
MAINTENANCE 1. REMOVE DUST OR DIRT ON THE LENS SURFACE USING A SOFT, OIL FREE CLOTH BEFORE STORING THE RANGEFINDER. 2. REMOVE SMUDGES OR FINGERPRINTS BY GENTLY RUBBING WITH A SOFT GLASS CLEANING CLOTH OR A HIGH-QUALITY, OIL-FREE TISSUE. 3. IF WATER VAPOR ENTERS THE UNIT PLACE IT IN DIRECT SUNLIGHT FOR TWO TO THREE HOURS. -
Page 16: Troubleshoot
TROUBLESHOOT NO DISPLAY 1. REINSERT THE BATTERY AND DOUBLE CHECK THE POLARITY (+/-) 2. CLEAN THE BATTERY CONTACTS 3. MAKE SURE THE BATTERY IS NOT DRAINED 4. PRESS THE POWER BUTTON FIRMLY 5. TRY ANOTHER BATTERY FADING DISPLAY 1. BE SURE THE RANGEFINDER AND ITS CASE ARE COMPLETELY DRY 2. - Page 17 SAFETY TO AVOID INJURY, FOLLOW THESE GUIDELINES 1. KEEP AWAY FROM CHILDREN AND EXTREME TEMPERATURES 2. DO NOT POWER ON THE RANGEFINDER WHILE LOOKING INTO THE THE OBJECTIVE LENS OR LIGHT-RECEIVING APERTURE 3. DO NOT AIM AT THE EYES OF PEOPLE, ANIMALS OR THE SUN 4.
- Page 34 ONLY WHAT YOU NEED REDUCE REUSE RECYCLE DESIGNED WITH LOVE...
