INVENTOR LV6DI-12WiFiR User & Installation Manual
  1. Manuals
  2. Brands
  3. INVENTOR Manuals
  4. Controller
  5. LV6DI-12WiFiR
  6. User & installation manual

INVENTOR LV6DI-12WiFiR User & Installation Manual

Air conditioning systems wired controller
Hide thumbs Also See for LV6DI-12WiFiR:
Table of Contents

  • English

  • Ελληνικά
    • Οδηγίες Ασφαλείας
    • Εξαρτήματα Εγκατάστασης
    • Μεθοδολογία Εγκατάστασης
    • Τεχνικά Χαρακτηριστικά
    • Ιδιότητες Και Λειτουργίες Του Χειριστηρίου
    • Ονοματολογία Ενδείξεων Οθόνης LCD Χειριστηρίου
    • Περιγραφή Των Πλήκτρων Του Χειριστηρίου
    • Προετοιμασία Λειτουργίας
    • Λειτουργία
    • Λειτουργίες Χρονοδιακόπτη
    • Εβδομαδιαίος Προγραμματισμός 1
    • Εβδομαδιαίος Προγραμματισμός 2
    • Κωδικοί Σφαλμάτων
    • Τεχνικές Προδιαγραφές
    • Ερωτήματα Και Ρυθμίσεις

  • Română
    • Siguranta si Precautii
    • Instalare Accesorii
    • Metoda de Instalare
    • Specificatii
    • Caracteristici si Functii
    • Denumirile de Pe Ecranul LCD al Telecomenzii
    • Denumirile Butoanelor
    • Operatiuni Pregatitoare
    • Operatiuni
    • Functii Temporizator
    • Temporizator Saptamanal 1
    • Temporizator Saptamanal 2
    • Mesaje de Eroare
    • Interogari si Setari

  • Deutsch
    • Installationsmethode
    • Technische Daten
    • Eigenschaften und Funktionen der Fernbedienung
    • Nomenklatur der Anzeigen auf dem Lcd-Display der Fernbedienung
    • Beschreibung der Tasten der Kabelgebundenen Bedienung
    • Betrieb
    • Timer-Funktionen

Advertisement

Quick Links

AIR CONDITIONING SYSTEMS
• USER'S & INSTALLATION MANUAL
• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ & ΕΓΚΕΤΑΣΤΑΣΗΣ
• ΜANUAL UTILIZATORULUI & INSTALLARE
• INSTALLATIONSHANDBUCH BENUTZERHANDBUCH
ENGLISH | ΕΛΛΗΝΙΚΑ | ROMANA | DEUTSCH
WIRED CONTROLLER
MODELS:
V7DI-12WiFiR/U7RS-12, V7DI-18WiFiR/U7RS-18
V7DI-24WiFiR/U7RS-24, V7DI-36WiFiR/U7RS-36
V7DI-42WiFiR/U7RS-42, V7DI-50WiFiR/U7RT-50
V7DI-60WiFiR/U7RT-60
V7CRI-12WiFiR/U7RS-12, V7CRI-18WiFiR/U7RS-18
V7CI-24WiFiR/U7RS-24, V7CI-36WiFiR/U7RS-36
V7CI-42WiFiR/U7RS-42, V7CI-50WiFiR/U7RT-50
V7CI-60WiFiR/U7RT-60
V7KI-18WiFiR/U7RS-18, V7KI-24WiFiR/U7RS-24
V7KI-36WiFiR/U7RS-36, V7KI-50WiFiR/U7RT-50
V7KI-60WiFiR/U7RT-60
LV6DI-12WiFiR, LV6DI-18WiFiR, LV6CI-12WiFiR,
LV6CI-18WiFiR
1
