  • Page 1 Ενσύρματο Τηλεχειριστήριο XK60 Wired Controller XK60 English/Ελληνικά/ Româna Your-conditions...
  • Page 2 User Notice Please carefully read this manual before installation and use of this product Thanks for choosing Inventor duct type air conditioners. Please read this manual carefully before operating this product and keep it properly for future reference. In addition, please take notice of the symbols below.

  • Page 3: Table Of Contents

    Contents 1 Introduction to the Wired Controller ..............1 1.1 Appearance and LCD Icons ............... 1 1.2 Introduction to the LCD Icons ..............2 2 Press Buttons ....................4 2.1 Buttons ....................... 4 2.2 Instruction to the Function of Press Buttons ..........4 3 OPERATION INSTRUCTION .................
  • Page 4 3.15 E-HEATER Setting .................18 3.16 Blow Function Setting ................18 3.17 Filter Setting ...................19 3.18 Quiet Function Setting ...............21 3.19 Ultra-Dry Setting ..................22 3.20 Other Functions ..................22 4 Installation of the Wired Controller ...............23 4.1 Standard Parts ..................23 4.2 Installation Location and Installation Requirements ........23 4.3 How to Install the Wired Controller ............24 4.4 How to Remove the Wired Controller ............25 5 Error Display ....................25...

  • Page 5: Introduction To The Wired Controller

    Wired Controller XK60 1 Introduction to the Wired Controller Fig.1 Appearance of the Wired Controller 1.1 Appearance and LCD Icons Fig.2 Appearance of the LCD...

  • Page 6: Introduction To The Lcd Icons

    Wired Controller XK60 1.2 Introduction to the LCD Icons Table 1 Icons Introduction Left and right swing function Up and down swing function Air exchange function Sleep function Auto mode COOL mode DRY mode FAN mode HEAT mode Health function...
  • Page 7 Wired Controller XK60 Electric heater Blow function Defrosting function Filter cleaning Timer Setting Keycard control / Detected status sensed by human body Quiet function Lock function...

  • Page 8: Press Buttons

    Wired Controller XK60 2 Press Buttons 2.1 Buttons Fig.3 Press Buttons 2.2 Instruction to the Function of Press Buttons Table 2 Press Buttons Function Introduction Function selection and canceling; Enter/Cancel Press it for 5s to enquiry the outdoor and indoor ambient temperature.

  • Page 9: Operation Instruction

    Wired Controller XK60 3 OPERATION INSTRUCTION 3.1 On/off Press the On/Off button to turn on or off the unit. Notes: The state shown in Fig.4 indicates the OFF state of the unit after energization. The state shown in Fig.5 indicates the ON state of the unit after energization.

  • Page 10: Temperature Setting

    Wired Controller XK60 3.3 Temperature Setting press either of them continuously, temperature will be increased or decreased by 1°C every 0.5s. In Cooling, Dry, Fan and Heating mode, temperature setting range is 16°C~30°C. In Auto mode, the setting temperature is un-adjustable.

  • Page 11: Right And Left Swing

    Wired Controller XK60 3.5 Right and Left Swing Under the ON state of unit, press the Function button to select the “Right and Left Swing” function option and then press the Enter/Cancel button to activate it. When the Swing function is activated, press the Function button to select the "Right and Left Swing"...

  • Page 12: Up And Down Swing

    Wired Controller XK60 3.6 Up and Down Swing Under the ON state of unit, press the Function button to select the "Up and Down Swing" function option and then press the Enter/Cancel to activate it. When the Swing function is activated, press the Function button to select the "Up and Down Swing"...

  • Page 13: Air Exchange Setting

    Wired Controller XK60 Cancellation of Timer Setting: The timer setting can be canceled by press “Timer”. Then , xx. Hour won’t be displayed. Timer Setting under the ON state of the Unit is as shown in Fig.11: Unit On, no timer function Press “Timer”...
  • Page 14 Wired Controller XK60 How to deactivate the air exchange function: When the “Air” function is activated, it can be deactivated in the way by firstly pressing the the Enter/Cancel button with the “Air” symbol disappeared. Air Exchange setting is shown as in Fig.12: Unit On, no Air function Press “Function”...

  • Page 15: Sleep Setting

    Wired Controller XK60 3.9 Sleep Setting Sleep on: Press the Function button under the ON state of the unit to select the “Sleep” function option and then press the Enter/Cancel button to activate it. Sleep off: When the Sleep function is activated, press the Function button to select the Sleep function option and then press the Enter/Cancel button to deactivate this function.
  • Page 16 Wired Controller XK60 e.g. If the setting temperature is 25°C, the temperature will rise by 1°C in each hour until it reaches 27°C. 7 hours later, the temperature will drop to 26°C. After that, the unit will run at this temperature.

  • Page 17: Health Setting

    Wired Controller XK60 3.10 Health Setting Under unit on status, press “Function” button to select health function with “Health” icon press the “Enter/Cancel” button to cancel health function. How to set health function is shown in the Fig.16: Unit On, no Health function Press “Function”...

  • Page 18: Vacation Setting

    Wired Controller XK60 Unit On, no I-Demand function Press “Function” button to set Press “Enter/Cancel” button to I-Demand function activate I-Demand function Press “Enter/Cancel” button to Press “Function” button to set cancel I-Demand function I-Demand function Fig.17 I-Demand Setting Note: The I-Demand function can be cancelled by mode switch and unit ON/OFF.

  • Page 19: Turbo Function Setting

    Wired Controller XK60 Unit On, no Vacation function Press “Function” button to set Press “Enter/Cancel” button to vacation function activate vacation function Press “Enter/Cancel” button to Press “Function” button to set cancel vacation function vacation function Fig.18 Vacation Setting Note: The vacation function can be only set under heating mode.

  • Page 20: Save Function Setting

    Wired Controller XK60 button to select the "Turbo" option and then pressing the Enter/Cancel button. Turbo function setting is as shown in Fig.19: Unit On, no Turbo function Press “Function” button to set Press “Enter/Cancel” button to turbo function activate turbo function Press “Enter/Cancel”...
  • Page 21 Wired Controller XK60 Cancel button to activate this function. The activated SAVE function can be deactivated by firstly pressing the “Function” button to select the “SAVE” option and then pressing the “Enter/Cancel” button. The energy saving setting is as shown in the Fig.20: Unit On, no Save function Press “Function”...

  • Page 22: E-Heater Setting

    Wired Controller XK60 3.15 E-HEATER Setting E-HEATER: in the HEAT mode, “E-HEATER” function is allowed to be activated to improve the through any button operations . Activation of the “E-HEATER” Function: firstly press the Function button to select the to activate it. After the activation, the symbol “E-HEATER” will always be displayed.

  • Page 23: Filter Setting

    Wired Controller XK60 pressing the Function button to select the “Blow” option and then pressing the Enter/Cancel button. BLOW function setting is as shown in Fig.22: Unit On, no Blow function Press “Function” button to set Press “Enter/Cancel” button to...
  • Page 24 Wired Controller XK60 Unit On, no Filter function Press “Function” button to set filter function the pollution level Press “Function” button to set Press “Enter/Cancel” button “00” shown at the timer area filter function to activate filter function Press “Enter/Cancel” button to cancel filter function Fig.23 Filter Setting...

  • Page 25: Quiet Function Setting

    Wired Controller XK60 “0” shows up at the second place, the accumulated operating hour reaches 1400h. Every increase of the number means another 400h is accumulated. When “9” shows up, it means the operating hour reaches 5000h. “0” shows up at the second place, the accumulated operating hour reaches 100h. Every increase of the number means another 100h is accumulated.

  • Page 26: Ultra-Dry Setting

    Wired Controller XK60 Unit On, no Quiet function Press “Function” button to set Press “Enter/Cancel” button to quiet function activate quiet function Press “Enter/Cancel” button to Press “Function” button to set cancel quiet function quiet function Fig.24 Quiet function setting Notes: "QUIET"...

  • Page 27: Installation Of The Wired Controller

    Wired Controller XK60 3.20.2 Memory Function same time for 5s to switch memory modes. When setting the memory mode, “MEMORY” will be displayed. If this function is deactivated, the unit will go to the OFF state after power recovery. Memory recovery: If the memory function is On, the wired controller after power failure will resume its original running state upon power recovery.

  • Page 28: How To Install The Wired Controller

    Wired Controller XK60 wired controller is likely to suffer water spray. (3). Do not install the wired controller directly opposite to the window so as to avoid improper operation caused by the interference of the neighbor’s same model wired controller.

  • Page 29: How To Remove The Wired Controller

    Wired Controller XK60 hole located at the bottom of the wired controller. Use M4×25 screws to no short-circuit potential. Set the panel and the bottom together by clasps. 4.4 How to Remove the Wired Controller The wired controller can be easily removed as shown in Fig.27 Fig.27 Removal of the Wired Controller...
  • Page 30 Wired Controller XK60 Error codes and their meanings: Table 5 Number Error code Error Compressor high pressure protection Indoor anti-freeze protection Compressor low pressure protection, refrigerant lack protection and refrigerant colleting mode Compressor high discharge temperature protection Communication error Indoor fan motor error...
  • Page 31 Wired Controller XK60 Drive module over temperature protection Zero passage protection AC current protection Drive current error Sensor connecting protection Temperature drift protection Bus low voltage protection Bus high voltage protection Charge loop error Input voltage abnormality Drive memory chip error...
  • Page 33 1. Εισαγωγή στο ενσύρματο χειριστήριο .............31 1.1 Εμφάνιση των LCD συμβόλων ..............31 1.2 Εισαγωγή στα LCD σύμβολα ..............32 2. Πλήκτρα ....................34 2.1 Πλήκτρα ....................... 34 2.2 Λειτουργίες πλήκτρων ................34 3. Οδηγίες λειτουργίας ................35 3.1 ΟΝ/ΟFF ......................35 3.2 Ρύθμιση...
  • Page 34 3.15 Ρύθμιση E-Heater .................48 3.16 Ρύθμιση λειτουργιας Blow ...............48 ................49 3.18 Ρύθμιση λειτουργίας Quiet ..............51 3.19 Ρύθμιση Ultra-dry ..................52 3.20 Άλλες λειτουργίες ..................52 4. Εγκατάσταση του ενσύρματου τηλεχειριστηρίου ......... 53 4.1 Βασικά μέρη ....................53 4.2 Θέση και απαιτήσεις εγκατάστασης ..........
  • Page 38 Enter/Cancel Mode °F/°C...
  • Page 41 Όταν η μονάδα είναι ενεργοποιημένη, πιέστε το πλήκτρο function για να επιλέξετε την οριζόντια κίνηση περσίδων και έπειτα πιέστε το πλήκτρο enter/cancel για να τη ενεργοποιήσετε τη λειτουργία. Όταν έχετε επιλέξει τη λειτουργία swing, πιέστε το πλήκτρο function για να επιλέξετε την οριζόντια κίνηση...
  • Page 42 Όταν η μονάδα είναι ενεργοποιημένη πιέστε το πλήκτρο function για να επιλέξετε την κάθετη κίνηση περσίδων και πιέστε το πλήκτρο enter/cancel για να την ενεργοποιήσετε. Όταν η κάθετη κίνηση περσίδων έχει επιλεγέί, πιέστε το πλήκτρο function για να επιλέξετε τη λειτουργία...
  • Page 43 timer timer...
  • Page 49 vacation vacation vacation vacation vacation...
  • Page 50 turbo turbo turbo...
  • Page 51 save save...
  • Page 57 3.20.4 (1). (2).
  • Page 62 AVERTIZARE!
  • Page 63 Cuprins 1 Prezentarea telecomenzii cu fir ....................................... 2 Taste ......................2.1 Butoane ............................................. 3.1 On/off ..................................3.3 Selectarea temperaturii ................3.4 Selectarea vitezei ventilatorului ............................................3.7 Setarea temporizatorului ........................................................................................
  • Page 64 ........................................................................................................................................................................

  • Page 65: Prezentarea Telecomenzii Cu Fir

    Telecomanda cu fir XK60 1 Prezentarea telecomenzii cu fir Fig. 1 Aspectul telecomenzii cu fir...
  • Page 66 Telecomanda cu fir XK60 1.2 Prezentarea imaginilor de pe ecran Tabelul 1 Imagine Prezentare Mod auto...
  • Page 67 Telecomanda cu fir XK60...

  • Page 68: Taste

    Telecomanda cu fir XK60 2 Taste 2.1 Butoane Fig.3 Taste Tabelul 2 Enter/Cancel (4). Setarea modului economic Mode Function Timer On/Off 4 mode Memory Lock 4 mode °F/°C...

  • Page 69: On/Off

    Telecomanda cu fir XK60 3.1 On/off...

  • Page 70: Selectarea Temperaturii

    Telecomanda cu fir XK60 3.3 Selectarea temperaturii Fig. 7 Selectarea temperaturii 3.4 Selectarea vitezei ventilatorului Mid-low Middle Mid-high High Super-high Auto...
  • Page 71 Telecomanda cu fir XK60...
  • Page 72 Telecomanda cu fir XK60 3.6 Up and Down Swing (Oscilare sus...
  • Page 73 Telecomanda cu fir XK60 porni programarea Timer Of Timer Timer Of Timer Of...
  • Page 74 Telecomanda cu fir XK60...
  • Page 75 Telecomanda cu fir XK60...
  • Page 76 Telecomanda cu fir XK60...
  • Page 77 Telecomanda cu fir XK60 ate) Canc Unitat Func ntru ntru a acti a func rita tate tate Function ntru Canc ntru a anula func tate tate...
  • Page 78 Telecomanda cu fir XK60 Auto. acation. acation.
  • Page 79 Telecomanda cu fir XK60 (5). (6). Auto.
  • Page 80 Telecomanda cu fir XK60 button to select the "Turbo" option and then pressing the Enter/Cancel button. Turbo function setting is as shown in Fig.19: turbo nu este activata seta functia turbo RY, F (3). Butonul FAN poate fi de asemenea utilizat pentr Turbo.
  • Page 81 Telecomanda cu fir XK60 de energie economie...
  • Page 82 Telecomanda cu fir XK60 en ie unc ia te fi act n modul de func ionare OOL, nu este af unc ia ce unitatea este torul unit ii de interior n mod automat tru a func iei n modul de func ionare...
  • Page 83 Telecomanda cu fir XK60 FAN. Filter.
  • Page 84 Telecomanda cu fir XK60 filtrare filtrare r. Primul (2). Atunci (3). Atunci...
  • Page 85 Telecomanda cu fir XK60 Tabelul 3 Nivel de Nivel de Nivel de poluare acumulat (h) poluare acumulat (h) poluare acumulat (h) 5500 1400 6000 1800 6500 2200 7000 2600 7500 3000 8000 3400 8500 3800 9000 4200 9500 4600 10000...
  • Page 86 Telecomanda cu fir XK60 onare...
  • Page 87 Telecomanda cu fir XK60 Under he OFF s a e of he uni ons a he same ime for 5s 3.20.4 Descriere...
  • Page 88 Telecomanda cu fir XK60 electricitate. Fig. 26 Montarea telecomenzii cu fir...
  • Page 89 Telecomanda cu fir XK60...
  • Page 90 Telecomanda cu fir XK60 Tabelul 5 Num r Cod de Eroare eroare Protec ie pre iune înalt a compre orului Protec ie anti-înghe pentru interior Protec ie pre iune joa a compre orului, protec ie lip de agent de refrigerare i mod de fixare a agentului de...
  • Page 91 Telecomanda cu fir XK60 Num r Cod de Eroare eroare Eroare curent motor Protec ie conectare senzor Protec ie varia ie de temperatur Protec ie tensiune joas magistral Protec ie tensiune înalt magistral Eroare bucl de înc rcare Tensiune la intrare anormal...
