RanServe Fiberglass Electric Heated Well
model
RANFG HTD-2
RANFG HTD-3S
RANFG HTD-4B
Description:
Randell's RANFG HTD Series Electric Heated Well Units designed
for virtually any hot food serving application, the RANFG HTD
series is enclosed in a brilliant one-piece fiberglass body and 16
gauge stainless steel top.
Specifications:
CABINET CONSTRUCTION: One-piece molded fiberglass body for
smooth exterior finish. All corners and areas where accessories
are mounted are reinforced internally with metal backers. Unit
to be provided with integral toe-kick.
TOP CONSTRUCTION: Exterior top is standard in reinforced 16
gauge 300 series stainless steel with #4 finish. Optional 14 gauge
tops available at a minimal upgrade.
HOT WELL CONSTRUCTION: The hot wells are constructed of die
stamped and annealed stainless steel and are provided with indi-
vidual drains manifolded to a common gate valve. The gate valve
is accessed through an enclosed housing with louvered access
door. Two types of fittings are provided to offer flexibility in type
of drain hose the operator wishes to attach (hose not included).
Only available in single phase.
Standard Features:
• Easy access to drain and controls
• Unique integral toe-kick provides neater finish
• Easy access to service electrical components
• Concealed locking mechanism with easy to use
spring-activated catch
Additional Available Configurations:
•RANFG HTD "S" Series
Same basic construction of standard enclosed base
series with an optional open shelf storage compartment.
Available in the 3, 4, 5 & 6 well models to offer most
efficient space capacity.
•RANFG HTD "B" Series
Same basic construction of standard enclosed base
series with an optional heated storage compartment.
Available in the 4 & 6 well models due to space constraints.
RANFG HTD-3
RANFG HTD-4S
RANFG HTD-6B
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, fax 888-266-5244
Specifications subject to change without notice.
For the most current specs, visit unifiedbrands.net.
models HTD
RANFG HTD-4
RANFG HTD-5
RANFG HTD-5S
RANFG HTD-6S
model RANFG HTD-4S shown
Available Fiberglass Colors:
Pitch Black
Dark-Bark Brown
Cabernet Wine
British Racing Green
Tin Man Gray
True Blue
Light Sky Blue
Candy Apple Red
Tiger Lilly Orange
Canary Yellow
White
Options & Accessories:
Canopy
Overshelves
Trayslides
Corian top
Granite top
No kick-plate
Graphics
Sneeze Guards
Elementary School Height
Electrical Distribution System
RANFG HTD-6
Randell RanServe, Page 25
Revised 09/04
