Worktops/Undercounters Side Mount Worktop
model
9215-32-7
Description:
Self-contained stainless steel worktop refrigerator or freezer
unit with 3" high backsplash. Randell mullion blower coil,
with thermostatic control, cools pans and/or base, and allows
for use of optional pans in the full depth interiors. R-134a
expansion valve refrigeration system in refrigerators, (R-404a in
freezers) both are CFC free. Units with lift-off louver, condensate
evaporator, "CFC free" foamed in place insulation and 6" high
adjustable legs. Cordset for 115V operation.
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal. The
top, front, and louver panel are stainless steel. Bottom & back of
unit are corrosion resistant steel. Sides are stainless steel. Worktop
refrigerators and freezers with 1 1/2" square nosing and 3" high
backsplash. Door opening frames are ABS and contain magnetic
strip for positive seal of door gaskets. Work surface to be at 36" work
height with unit on (4) 6" high legs with adjustable bullet feet.
CABINET INTERIOR: Interior of cabinet is fully coved to meet
N.S.F. standard #7. The Interior bottom, back, and top are
anodized aluminum with coved corners for easy clean-up. The
interior ends are ABS. Durable shelf supports molded into sides.
Unit insulated with a minimum of 2.5" of CFC free, foamed in
place polyurethane.
DOORS: Stainless steel front with easy to grasp recessed handles,
mounted on heavy duty concealed hinges. Hinges are all stainless
steel with bronze pivot pin in nylon bushing,. Doors with foamed
in place insulation, press fit magnetic gaskets - (designed for
installation & removal without tools), and deep draw ABS interior
liner for maximum insulation value.
REFRIGERATION: Refrigerators utilize a CFC free, R-134a Expansion
Valve refrigeration system that includes condensing unit, and
thermostatic control for operator adjustability. Compressor
housing to allow maximum airflow and permit mounting of
standard hot gas condensate evaporator. Mullion coil, is coated
to resist corrosion, and offers maximum air flow. Freezers utilizes
R-404a refrigerant with an automatic, self-defrosting system
for blower coil. Freezer models equipped with door frame heater
element to prevent gasket freezing. Units totally prewired and to
be supplied with 8' cordset (NEMA 5-15P) for 115V operation.
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
9215-32-7F
9205-32-7
model 9215-32-7
shown
Standard Features:
• Side mounted compressor with mullion "Turbo" coil
• R-134a refrigerant in refrigerators and R-404a in
• Exterior stainless steel top & front
• Foamed in place "CFC free" urethane insulation
• Self-closing doors with exclusive press-fit magnetic
• Expansion Valve
• Condensate evaporator
• Cord and plug for 115 volt operation
• 6" high adjustable legs
• One piece stainless steel worktop and a 3" high
Options & Accessories:
9205-32-7F
provides proper pan cooling, and "full depth" usable
interior space
freezers both are "CFC free"
gaskets
stainless steel, integral backsplash
Stainless steel back panel
Tray racks for 24" or 27" openings only
Refrigerated drawers
Overshelves
Casters
Export voltages available
Randell Worktops/Undercounters, Page 1
models 9200-32-7
9235-32-7
9225-32-7
PP SPEC0010 Rev. A
Revised 07/06
33°F to 40°F
33°F to 41°F
