5.2.Operation Screens

The display screen of the Power Monitor changes in the following manner, according to touch
panel operations and connection setting. Display details and operations of respective screen
are described in the "Display Functions" section.
One Point
・ The screens indicated by dotted arrow lines are displayed when a specific condition (such as
date/time not entered, connection setting and the like) is satisfied.
・ The screens surrounded by a frame of dotted line are not displayed when the Power Monitor
and the Inverter are unable to communicate with each other.
・ Screens indicated with solid lines are displayed for ordinary operations.
・ The screens in gray are displayed when operating in service mode.
■ List of Operation Screens
Power turned on (it takes about 10 seconds until the Startup screen is displayed )
Startup screen
Energy log
Today
Today (hour)
Month
Year
20 years
Calendar
Measurement
Plant
Inverter
Battery
Time Setting screen
Home screen
Information
Inverter
Error Events Log
Connection Log
De-rating Log
Connection Setting screen
Setting Inverter status
Connection
Page 59
Grid Setting
Page 65
Time
Page 66
Screen setting
Page 68
Operation Mode
Page 71
Maintenance
Page 81
Communication
Page 82
Power Suppression
Page 84
55
Description of the screen display
Slideshow
Page 52
