RESIDENTIAL POWER DIRECT VENT GAS-FIRED WATER HEATERS
INSTALLATION AND OPERATING INSTRUCTIONS
PDV 2" Model only
with generation II
Intellivent
gas control
READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING THE INSTALLATION. PROPER INSTALLATION WILL PROVIDE SAFE
& EFFICIENT SERVICE, AND AVOID NEEDLESS EXPENSES NOT COVERED BY THE WARRANTY. READ THE PRODUCT WARRANTY
IN THE OWNER'S MANUAL AND REMEMBER TO FILL OUT AND RETURN TO THE MANUFACTURER ALL RELEVANT WARRANTY
CARDS AND CERTIFICATES. SHOULD YOU HAVE ANY QUESTIONS, PLEASE CONTACT YOUR LOCAL DEALER OR REFER TO THE
GETTING SERVICE FOR YOUR WATER HEATER SECTION OF THE OWNER'S MANUAL.
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
For your records, write the model and serial number here:
Model # ________________________________
Serial # ________________________________
54000059
© 2014 Giant Factories Inc. Printed in Canada
(EQUIPPED WITH FVIR TECHNOLOGY)
OWNER'S MANUAL
IMPORTANT
WARNING
This water heater IS NOT design certified for installation
in a mobile home or for installation outdoors.
WARNING
If the information in these instructions is not
followed exactly, a fire or explosion may result causing
property damage, personal injury, or death.
DO NOT store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
• DO NOT try to light any appliance.
• DO NOT touch any electrical switch.
• DO NOT use any phone in your building.
• From a neighbour's phone, immediately call
your gas supplier. Follow the gas supplier's instruc-
tions.
• If you cannot reach your gas supplier, call the fire depart-
ment.
Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
R
GI-IM053En-1114
