RESIDENTIAL GAS FIRED WATER HEATERS
Customer service department : 1-800-363-9354
OWNER'S MANUAL
INSTALLATION AND OPERATING INSTRUCTIONS
WARNING :
If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or death.
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliances.
• Do not touch any electrical switches, do not
use any telephone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
Installation Instructions
IMPORTANT
Read these instructions carefully before beginning the installa-
tion. Proper installation will provide safe & efficient service,
and avoid needless expense not covered by the warranty.
Should you have any questions please contact your local dealer
or call the customer service department of the manufacturer
listed on the warranty card.
SAVE THIS MANUAL FOR FUTURE REFERENCES AND
PLEASE READ THE MANUFACTURER'S PRODUCT
WARRANTY CONTAINED IN THIS MANUAL
Gas Dom. Ins. 07/99
