- Page 1 AG 600-A36 English Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
- Page 2 Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
-
Page 3: Information About The Documentation
Information about the documentation About this documentation • Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free handling and use of the product. • Observe the safety instructions and warnings in this documentation and on the product. •... - Page 4 The type designation and serial number are printed on the rating plate. ▶ Write down the serial number in the table below. You will be required to state the product details when contacting Hilti Service or your local Hilti organization to inquire about the product. Safety...
- Page 5 ▶ Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. ▶ If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 6 cracked wires. If power tool or accessory is dropped, inspect for damage or install an undamaged accessory. After inspecting and installing an accessory, position yourself and bystanders away from the plane of the rotating accessory and run the power tool at maximum no-load speed for one minute.
- Page 7 ▶ The guard must be securely attached to the power tool and positioned for maximum safety, so the least amount of wheel is exposed towards the operator. The guard helps to protect the operator from broken wheel fragments, accidental contact with wheel and sparks that could ignite clothing. ▶...
- Page 8 ▶ Do not use or charge batteries that have suffered mechanical impact, have been dropped from a height or show signs of damage. In this case, always contact your Hilti Service. ▶ If the battery is too hot to touch it may be defective. In this case, place the product in a non-flammable location, well away from flammable materials, where it can be kept under observation and allowed to cool down.
- Page 9 English Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
- Page 10 English Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
- Page 11 Description Overview of the product English Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
- Page 12 It is recommended that a dust removal system consisting of matched components, i.e. dust removal hood and a suitable Hilti vacuum cleaner, are used for working on mineral materials such as concrete or stone. These protect the operator and increase the life of the tool and accessory tools used.
- Page 13 Dust hood for cutting: DC-EX 125/5" C compact hood (accessory) When cutting mineral materials with diamond cutting discs, use the DC-EX 125/5" C compact hood. CAUTION Use of this hood for working on metal is prohibited. DG-EX 125/5" dust hood for grinding (accessory) The grinding system is suitable only for occasional use with diamond cup wheels for grinding mineral materials.
-
Page 14: Technical Data
Application Designation Material Wire brushes Wire brushes 3CS, 4CS, 3SS, Metal Suitability of discs for the equipment used Item Equipment ACD AG-D AF-D AN-D DC-TP, 3CS, AG-D DC-D 4CS, type 27 (SPX, (SPX, 3SS, SP, P) SP, P) Guard — Front cover (in —... -
Page 15: Before Use
Before use Inserting the battery CAUTION Risk of injury. Due to the angle grinder starting unintentionally. ▶ Before fitting the battery, check that the angle grinder is switched off and that the safety lock is activated. CAUTION Electrical hazard. Dirty contacts may cause a short circuit. ▶... - Page 16 Fitting or removing the guard CAUTION Risk of injury. The accessory tool may be hot or have sharp edges. ▶ Wear protective gloves when fitting, removing or adjusting the accessory tool or other parts and when troubleshooting. ▶ Observe the instructions for fitting the applicable guard. 5.4.1 Fitting the guard The guard is equipped with locating lugs that ensure only guards of a type suitable for use with the...
- Page 17 1. Position the front cover with the closed side on the standard guard and push it on until it engages. 2. To remove it, release the catch for the front cover and then lift the front cover away from the standard guard.
- Page 18 Diamond discs must be replaced when their cutting or grinding performance drops significantly. This generally is the case when the segments reach a height of less than 1/16". Other discs must be replaced when their cutting performance drops significantly or other parts of the angle grinder (not the disc) come into contact with the material you are working on.
- Page 19 1. Remove the battery. → page 13 2. Clean the clamping flange and the quick-release clamping nut. 3. Fit the clamping flange onto the drive spindle. 4. Fit the accessory tool. 5. Screw on the Kwik lock nut until it is seated against the accessory tool. ◁...
-
Page 20: Operation
Operation Grinding CAUTION Risk of injury. The accessory tool may suddenly stick or stall. ▶ Use the power tool with the side handle (or optional hoop grip) fitted and always hold the power tool securely with both hands. Cutting ▶ When cutting, apply moderate feed pressure and do not tilt the power tool or the cutting disc (when working, hold at approx. - Page 21 Take your individual workplace risk assessment into account. To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare parts, consumables and accessories approved by us for use with the product can be found at your local Hilti Center or online at: www.hilti.com...
-
Page 22: Troubleshooting
▶ Cover the terminals with a non-conductive material (such as electrical tape) to prevent short circuiting. ▶ Dispose of your battery out of the reach of children. ▶ Dispose of the battery at your Hilti Store, or consult your local governmental garbage disposal or public health and safety resources for disposal instructions. -
Page 23: Manufacturer's Warranty
Manufacturer’s warranty ▶ Please contact your local Hilti representative if you have questions about the warranty conditions. English Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01... - Page 24 Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
- Page 25 Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
- Page 26 Hilti = registered trademark of Hilti Corp., Schaan 20180306 Printed: 07.03.2018 | Doc-Nr: PUB / 5246615 / 000 / 01...
