CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN THE AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD INSERT. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
Owner's Manual
OPERATION REQUIREMENTS
CW2100
INSERT
(CB00027 Model)
Wood Insert
Part 2 of 2
INSTALLATION AND
Safety tested according to ULC
S628, UL 1482 and UL 737 by an
accredited laboratory.
US Environmental Protection
Agency phase II certified
wood insert compliant with
2020 cord wood standard.
EPA
< ≤
2.5
g/h
46294_IA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB00027 and is the answer not in the manual?

Questions and answers

Related Manuals for Century Heating CB00027

Summary of Contents for Century Heating CB00027

  • Page 1 Owner's Manual Part 2 of 2 INSTALLATION AND OPERATION REQUIREMENTS CW2100 INSERT (CB00027 Model) Safety tested according to ULC S628, UL 1482 and UL 737 by an accredited laboratory. US Environmental Protection Agency phase II certified wood insert compliant with 2020 cord wood standard.
  • Page 2 ONLINE WARRANTY REGISTRATION If the unit requires repairs during the warranty period, proof of purchase must be provided. The purchase invoice must be kept. The date indicated on it establishes the warranty period. If it can not be provided, the warranty period will be determined by the date of manufacture of the product. It is also highly recommended to register the warranty online at https://www.century-heating.com/ca/en/warranty/warranty-registration Registering the warranty will help to quickly find the information needed on the unit.
  • Page 3 CERTIFICATION PLATE...
  • Page 4 Page 4 Product Specification Manual - CW2100...

  • Page 5: Table Of Contents

    TABLE OF CONTENT 1. General Information ........................ 6 Performances ......................6 Specifications ......................7 Dimensions ........................ 8 EPA Loading ......................10 2. Clearances to Combustible Material ..................11 Minimum Masonry Opening and Clearances to Combustibles ........11 Floor Protection ......................12 R Value ........................13 3.

  • Page 6: General Information

    1. General Information Performances Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output. CW2100 (CB00027) Models Type of combustion Non-catalytic Fuel Type Dry Cordwood 250 to 1,200 ft (23 to 111 m Recommended heating area (sq.

  • Page 7: Specifications

    Specifications Maximum log length 17 in (432 mm) east-west Flue outlet diameter 6 in (150 mm) Recommended connector pipe diameter 6 in (150 mm) Type of chimney ULC S635, CAN/ULC-S640, UL 1777 Baffle material C-Cast or equivalent Approved for alcove installation Approved for mobile home installation Type of door Simple, glazed, with cast iron frame...

  • Page 8: Dimensions

    Dimensions Page 8 Product Specification Manual - CW2100...
  • Page 9 8 3/4" 224mm Product Specification Manual - CW2100 Page 9...

  • Page 10: Epa Loading

    EPA Loading The charging methods shown below are those that were used during emissions certification. 1.4.1 Air control The air control is located above the door. To open the air control, insert the removable handle onto the air control and push the air control handle completely to the right (High).

  • Page 11: Clearances To Combustible Material

    2. Clearances to Combustible Material When the insert is installed so that its surfaces are at or beyond the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions. NO PART OF THE INSERT MAY BE LOCATED CLOSER TO THE COMBUSTIBLE THAN THE MINIMUM CLEARANCE FIGURES GIVEN.

  • Page 12: Floor Protection

    Floor Protection It is necessary to have a floor protection made of non-combustible materials that meets the measurements specified below. Table 1 : Floor Protection FLOOR PROTECTION Canada 18" (457 mm) 16" (406 mm) 8" (203 mm) 8" (203 mm) DOOR Figure 2 : Floor Protection To determine the need to add floor protection (D) beyond the hearth extension (A), the following...

  • Page 13: R Value

    If the value (D) is negative or zero, additional floor protection in front of the unit is not needed because the masonry fireplace hearth extension is long enough. If the value (D) is positive, an additional floor protection in front of the hearth extension at least equivalent to the result (D) must be added.
  • Page 14 Four inches of brick (R = 4 x 0,2 = 0,8) plus 1 inch of Durock® (R = 1 x 0.52 = 0.52). 0.8 + 0.52 = 1.32. This R value is larger than the required 1.00 and is therefore acceptable. In the case of a known K and thickness of alternative materials to be used in combination, convert all K values to R by dividing the thickness of each material by its K value.

  • Page 15: Installing Options On Your Product And Replacing Parts

    3. Installing Options on Your Product and Replacing Parts Replacement and Adjustment 3.1.1 Door Note: The images shown are for guidance only and may be different from your product, but the assembly remains the same. In order for the insert to burn at its best efficiency, the door must provide a perfect seal with the firebox.
  • Page 16 3.1.3 Door Alignment To align, open the door and loosen the pressures screws located on the lower and upper hinges of the door using a 3/32” Allen key to free the adjustable hinge rods. 3/32" Using a flat screwdriver, turn the adjustable hinge rods in the direction shown to adjust the doors.

  • Page 17: Mandatory Installation

    Mandatory Installation • Empty the combustion chamber (Figure 5) and unscrew the two screws (B) of the side refractory bricks supports (A). The bricks can then be removed in the order shown in Figure 6. 3/8" 3/8" Figure 5 : Empty the combustion chamber Figure 6 : Remove brick supports Connecting the Blower With a BX Wire CAUTION RISK OF ELECTROCUTION.
  • Page 18 4. Strip a section of ½" of the black and white wires (F) that are in the box attached to the insert. 1/2" 13mm 1/2" 13mm 5. Remove the piece of metal (G) from the plate (B) obstructing the hole to the left of the power cord (H) using pliers or a screwdriver.
  • Page 19 6. Install the connector (I) supplied with the manual kit in the hole formed in the plate (B) in step 5. 7. Pass the new wires through the connector (I) and install the sleeve (J) supplied with the manual kit on the BX wire. 8.

  • Page 20: Changing The Side Of The Blower Power Cord

    Changing the Side of the Blower Power Cord enlever les annotations soous les détail et les lettre des détails 1. Unscrew both screws (A) to remove the grille (B) in front of the blower. Unscrew both screws (K) to remove the ash tray (L). Then unscrew the three plastic grommets (C) located on the base of the fan.
  • Page 21 3. Unscrew the plate (H) on the other side of the insert. Keep the plate (H) and screws (I). 4. Pass the white (D) and black (E) wires through the hole formed in the previous step by pulling them towards the front of the insert. Then pass the wires through the grommet (J) located on the side at the front of the device.
  • Page 22 6. Install the plate (H) with the screws (I) kept in step 3 to the initial location of the connection box (G). 7. Pull the excess black and white wires into the insert to be able to connect them to their respective locations (the black wire is connected to the rheostat and the white wire is connected to the blower).

  • Page 23: Blower Removal

    Blower Removal s les détail et les lettre des détails Remove the two screws (A) on each side of 2. Unscrew the two wing nuts (C) on each the grille (B) to be able to remove it. side of the fan. s détail et les lettre des détails 3.

  • Page 24: Removable Air Control Handle

    Removable Air Control Handle This insert comes with a removable handle for the primary air control. A holder for the handle is supplied with the manual. Here is an example of the holder installation. CAUTION: Do not leave the handle on the air control after use, as it will get very hot. Page 24 Product Specification Manual - CW2100...

  • Page 25: Faceplate Installation

    Faceplate Installation Lay the panels on a flat and non abrasive surface. Align the top panel holes (A) with the left and right panels (B) and (C). Secure together using the bolts (D) and nuts (E) provided. Install the grille on the assembled faceplate and bend the tabs using pliers. Hang the assembled faceplate on the insert.

  • Page 26: Faceplate Decorative Panel Installation/Removal

    Faceplate Decorative Panel Installation/Removal It is possible to install the insert with or without the faceplate decorative panel. The latter is included with the insert and is already partially installed with two screws at each end. Here are the steps to remove or keep it : Faceplate decorative panel removal •...

  • Page 27: Optional Fresh Air Intake Kit Installation

    Optional Fresh Air Intake Kit Installation The fresh air intake kit may be installed on the right or left end side of the unit. The unused side must be covered by the plate provided in the user manual kit. • Install the fresh air intake adapter (E) with four screws (F) then secure the flexible pipe (H) (not included) to the adapter using one of the pipe clamps (G).

  • Page 28: Optional Fire Screen Installation

    3.10 Optional Fire Screen Installation In the United States or in provinces with a particulate emissions limit (e.g.: US EPA), the use of open-door wood stoves with a rigid firescreen is prohibited. Open the door. Hold the fire screen by the two handles and bring it close to the door opening. Page 28 Product Specification Manual - CW2100...

  • Page 29: Air Tubes And Baffle Installation

    Lean the upper part of the fire screen against the top door opening making sure to insert the top fire screen brackets in front of the primary air deflector. Lift the fire screen upwards and push the bottom part towards the insert then let the fire screen rest on the bottom of the door opening.
  • Page 30 Align the notch in the left end of the tube with the key of the left air channel hole. Using a « Wise grip » hold the tube and lock it in place by turning the tube as shown. Make sure the notch reaches the end of the key way.

  • Page 32: Removal Instructions

    3.12 Removal Instructions For inspecting purposes, the insert may need to be removed. To remove the insert, follow these instructions: • Remove the blower grille (E) and faceplate (D) by lifting it and then pulling on it. • Remove the blower (C). •...

  • Page 33: Exploded Diagram And Parts List

    3.13 Exploded Diagram and Parts List Product Specification Manual - CW2100 Page 33...
  • Page 34 PL74849 RIGHT FACEPLATE PL74847 TOP FACEPLATE PL74848 LEFT FACEPLATE SE46294 CB00027 INSTRUCTION MANUAL KIT AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL SE74798 GLASS, GASKET AND MOULDING KIT SE74775 GLASS WITH GASKET 15 3/4'' X 10 1/8'' PL74798...
  • Page 35 CENTURY LIMITED LIFETIME WARRANTY CENTURY HEATING LIMITED WARRANTY The warranty of the manufacturer extends only to the original retail purchaser and is not transferable. This warranty covers brand new products only, which have not been altered, modified nor repaired since shipment from factory.
  • Page 36 This document is available for free download on the Stove Builder International inc. manufacturer’s website. It is a copyrighted document. 250, rue de Copenhague, Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 1-877-356-6663...
