Randell RANFG FTA-2 Specifications

RanServe Fiberglass Frost Top
model
RANFG FTA-2
RANFG FTA-4S
Description:
Randell's RANFG FTA Self-Contained Mechanically Cooled Frost
Top Units designed for virtually any cold food serving application,
the RANFG FTA series is enclosed in brilliant one-piece fiberglass
body and 16 gauge stainless steel top.
Specifications:
CABINET CONSTRUCTION: One-piece molded fiberglass body for
smooth exterior finish. All corners and areas where accessories
are mounted are reinforced internally with metal backers. Unit
to be provided with integral toe-kick.
TOP CONSTRUCTION: Exterior top is standard in reinforced 16
gauge 300 series stainless steel with #4 finish. Optional 14 gauge
tops available at a minimal upgrade.
FROST TOP CONSTRUCTION: The Frost Tops are constructed of die
formed stainless steel and are provided with a perimeter trough
and drain. Mechanical (compressor) housing with louvered ac-
cess door.
Standard Features:
• Unique integral toe-kick provides neater finish
• Easy access to service the condensing coil through the
hinged louver
• Concealed locking mechanism with easy to use
spring-activated catch
• Hinged access to drain gate valve
• Easy access to thermostat through the hinged louver panel
• Single-Sided louver designed to efficiently cool system
without need for auxiliary louvers on the opposite side
Additional Available Configurations:
•RANFG FTA "S" Series
Same basic construction of standard enclosed base series with
an optional open shelf storage compartment. Available in the
60.25", 72" and 86" models to offer most efficient space
capacity.
RANFG FTA-3
RANFG FTA-5S
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
models FTA
RANFG FTA-4 RANFG FTA-5
RANFG FTA-6S
model RANFG FTA-4S shown
Available Fiberglass Colors:
Pitch Black
Dark-Bark Brown
Cabernet Wine
British Racing Green
Tin Man Gray
True Blue
Light Sky Blue
Candy Apple Red
Tiger Lilly Orange
Canary Yellow
White
Options & Accessories:
Canopy
Overshelves
Trayslides
Corian top
Granite top
No kick-plate
Graphics
Sneeze Guards
Elementary School Height
Electrical Distribution System
RANFG FTA-6
Randell RanServe, Page 28
Revised 2/07
