Machine control – Operating elements

Overview of control sections

4 Machine control – Operating elements
4.1 Overview of control sections
For description purposes, the machine control has been divided into two sections (A, B) to ensure
maximum clarity. The setting ranges for the parameter values are summarised in the parameter
overview section > see 7.1 chapter.
Item Symbol
1
2
8
Description 0
Control section A
> see 4.1.1 chapter
Control section B
> see 4.1.2 chapter
Figure 4-1
099-00T407-EW501
14.07.2020
