Rectifying faults

All products are subject to rigorous production checks and final checks. If, despite this, something fails to
work at any time, please check the product using the following flowchart. If none of the fault rectification
procedures described leads to the correct functioning of the product, please inform your authorised dea-
ler.
6.1

Error messages (power source)

Depending on the options of the machine display, a fault is shown as follows:
Display type - machine control
Graphic display
two 7-segment displays
one 7-segment display
The possible cause of the fault is signalled by a corresponding fault number (see table). In the case of an
error, the power unit shuts down.
The display of possible error numbers depends on the machine version (interfaces/functions).
• Document machine errors and inform service staff as necessary.
Error message
E 1
E 2
E 3
E 4
E 5
E 6
E 7
E 8
E 9
E10
E11
E12
099-00T407-EW501
14.07.2020
Possible cause
Water fault
Only occurs if a water cooling
unit is connected.
Temperature error
Electronics error
see "E 3"
see "E 3"
Balancing error in voltage record-
ing.
Balancing error in current record-
ing.
Error in one of the electronics
supply voltages or excess tempe-
rature of the welding transformer.
Low voltage
Secondary overvoltage
Overvoltage
VRD (open circuit voltage reduc-
tion error)
Display
Remedy
Ensure that sufficient water pressure can be built
up. (e.g. top up water)
Allow machine to cool down.
Switch machine off and on again.
If the fault persists, inform the service depart-
ment.
see "E 3"
see "E 3"
Switch machine off, place the torch on an insula-
ted surface and switch on again.
If the fault persists, inform the service depart-
ment.
Switch machine off, place the torch on an insula-
ted surface and switch on again.
If the fault persists, inform the service depart-
ment.
Allow machine to cool down. If the error message
persists, switch the machine off and back on
again.
If the fault persists, inform the service depart-
ment.
Switch off the machine and check the mains vol-
tage.
Switch machine off and on again.
If the fault persists, inform the service depart-
ment.
Switch off the machine and check the mains vol-
tage.
Inform Service
