INTRODUCTION

Thank you for purchasing the Radial JR•1 footswitch. Please take a few moments
to read this short manual and familiarize yourself with the various functions. This
will help you get the most out of the JR•1 as you explore its uses. Should you
have a question that is not covered in this manual, we invite you to send us an
email at info@radialeng.com and we will do our very best to reply in short order.

OVERVIEW

The Radial JR•1 is a remote footswitch equipped with either a latching footswitch
(JR•1L) or momentary footswitch (JR•1M) depending which model you have
purchased. The JR•1 controls various Radial devices, such as the Relay Xo
stereo switcher, and derives its power from the device under control, thus
eliminating the need for a local power supply or batteries.
LATCHING: The JR•1L is equipped with a latching footswitch that
will change states each time it is pressed. Press the switch once
to toggle from A to B and press again to change back to A. The
latching footswitch is a good option when switching effects that
stay on for the duration of a song.
EFFECTS
JR•1L
RELAY
Xo
VOCAL MIC MIXER
MOMENTARY: The JR•1M is equipped with a momentary
footswitch that will change states only when held down. Press
and hold the switch to toggle from A to B and release the switch
to change back to A. The momentary footswitch is well suited for
'push-to-talk' uses like toggling to an intercom system to speak
with stage technicians.
INTERCOM
JR•1M
RELAY
Xo
VOCAL MIC PA SYSTEM
