- Page 1 4 - i n - 1 C a m e ra Sta b i l i ze r User Manual V1.1 Scan the QR code to access the tutorial...
- Page 2 Warning & Disclaimer Thank you for purchasing the Hohem product. By using this product, you hereby signify that you have read this disclaimer and warning carefully. In addition, you understand and agree to abide by the terms and conditions herein. You acknowledge that you are solely responsible for your own conduct while interacting with this product, and for any consequences thereof.
-
Page 3: Table Of Contents
· ··············· 07 How to Enable the AI Tracking · ······ 08 OLED Display · ·················· Bluetooth Connection · ················ 09 How to Use the Hohem Joy App · ····· 10 Auto Calibration & Firmware Update · · · Auto Calibration · ··················· App Guidance ·... -
Page 4: Product List
Before using this product, please carefully check that all the following items are included in the product package. In case that any item is found missing, please contact Hohem customer service or the local distributor. Fill Light with AI Vision Sensor *1... -
Page 5: Introduction
02 Introduction ⑫ Type-C Reverse ⑫ Charging Port ⑬ ⑬ Type-C Camera ① Support Mount Control Port ② Pan Axis Arm ① ⑭ ⑭ Roll Axis Arm Latch ③ Pan Axis Arm Latch ④ Pan Axis Motor ⑤ ⑥ ⑤ Roll Axis Arm ② ③ ⑥ Roll Motor ⑮ Roll Axis Motor ⑮... -
Page 6: Battery And Charging
03 Battery and Charging Please fully charge iSteady MT2 before using it for the first time. Charging Method: To charge iSteady MT2, connect a USB adapter (Not included, 5V-2A for best) to the charging port with the provided Type A-Type C charging cable. -
Page 7: Mounting And Balancing
05 Mounting and Balancing Attaching the Tripod Attach the tripod to the bottom of Unfold the tripod and place the the iSteady MT2 handle. iSteady MT2 on a flat surface. Mounting A Camera 1.Unfold iSteady MT2 ① Folded Status ② Unfolded Status... - Page 8 2.Mounting the Quick Release Plate a. Mount the camera onto the camera quick release plate, and tighten the screw. A. If you are using a long-focus lens and the camera is front-heavy, you can mount the screw with the camera at the end of the slot(as shown on the right), which makes sure more space to adjust the center of gravity for horizontal balancing.
- Page 9 3. Mounting onto the Stabilizer a. Unlock the mount latch, and install the camera with L-Bracket on the mount. b. Lock the mount latch to ensure that the camera is tightly installed on the stabilizer. *How to quick detach the camera from stabilizer Unlock the mount latch, and remove the camera and...
- Page 10 ③ Type C - TRRS (2.5mm), Type C - TRS (2.5mm), Type C - TRS (3.3mm) are camera control cables. For more supported cameras of iSteady MT2 and its tutorial, please scan the QR code above to acquire up-to-date information. 5. Portrait Mode a.Rotate the camera with L-Bracket 90°...
-
Page 11: Mounting A Phone
b. Install the L-bracket on the right side. You can attach accessories to the hot shoe facing outward. Mounting A Phone 1. Mount the Phone in Landscape Mode a. Mount the phone on the phone quick release plate in the middle. *The clamp provides multiple mounting options for various accessories. -
Page 12: Mounting An Action Camera
2.Mount the Phone in Portrait Mode ① Rotate the phone with L-Bracket 90° ② Insert the L-Bracket into the mount slot, to switch to vertical shooting mode. and lock the safety lock latch. Mounting An Action Camera 1.Mount the Action Camera in Landscape Mode ①... -
Page 13: Balancing
2.Mount the Action Camera in Portrait Mode ① Rotate the action camera with the ② Insert the L-Bracket into the mount L-Bracket 90° to switch to vertical slot, and lock the safety lock. shooting mode. Balancing *Here we take the mirrorless camera as an example. - Page 14 b. Horizontal Balancing of the Tilt Axis Make the camera lens point forward and check the center of gravity. ② Move ③ Lock the the camera quick release ① Unlock the forward and plate latch quick release back until plate latch the camera is balanced.
- Page 15 ③ Move the roll axis arm left and right until the camera remains relatively still and level with ④ Lock the the ground roll axis motor. when released. 3. Balancing the Pan Axis ③ Check the camera's center of gravity. ④...
-
Page 16: How To Use The Stabilizer
⑥ Lock the pan axis arm latch *After balancing iSteady MT2, if you need adjust the motor torque for proper using. please see the description in the chapter "How to Use the Stabilizer". 06 How to Use the Stabilizer On-board Features... - Page 17 Android 10.0 or later versions. Please ensure Bluetooth is connected.) Press three times: Front/rear camera switch (Only available in the Hohem Joy app or on the native camera app of certain standard protocol phones with Android 10.0 or later versions. Please ensure Bluetooth is connected.)
-
Page 18: How To Set Motor Torque, Motor Angle Fine-Tuning
(Please make sure that your camera is on the list of supported devices for control and that the control cable is connected. For smartphones, it's only available in the Hohem Joy app or on the native camera app of certain standard protocol phones with Android 10.0 or later versions. -
Page 19: Modes Description
(Network) → [Bluetooth] → [Bluetooth Function] → [ON] b. Bluetooth Pairing: (Network) → [Bluetooth] → [Pairing] ) 2. Long-press the M button on the iSteady MT2 handle to enter the OLED sub-menu. 3. Press the A/B button to enter the device pairing interface. -
Page 20: Manual Tilt Adjustment
07 How to Enable the AI Tracking (AI vision sensor is optional) 1.Install Magnetic Fill Light with AI Vision Sensor (Sold separately) Keep the "hohem" mark upward and camera outward, then put the fill light on the magnetic joint. 2. Enable the AI vision sensor: Switch to "ON". - Page 21 (the indicator stops flashing). How to control AI Tracker by using iSteady MT2 When tracking other human subjects, you can use iSteady MT2 to start or stop the AI tracker. Step 1 Power on the gimbal and AI tracking sensor.
-
Page 22: Oled Display
08 OLED Display Home Screen ④ ① ② ③ ⑤ ⑥ ① Working Status of Control Wheel Roll Axis Control Focus Control Fill Light: Brightness Color Temperature RGB Light: Brightness ② Working Mode Pan Follow Mode Pan&Tilt Follow Mode All Lock Mode All Follow Mode Sport Mode Inception Mode... - Page 23 Others 1. Standby: Stabilizer enters standby mode 2. Pan Axis Latch: Pan axis is locked, unlock the Latch Firmware error Gyroscope error Unbalancing/Motor Unlocking/Overloading(May be caused by external disturbance) 3. Error: [-M1] Tilt Motor Unlocking [-M2] Roll Motor Unlocking [-M3] Pan Motor Unlocking Move to the position A from the current position at a constant speed.
-
Page 24: Bluetooth Connection
1. Power on iSteady MT2. 2. Turn on Bluetooth on Mobile Phone. 3. Launch the App Hohem Joy and follow the prompts to connect iSteady MT2 device. *If the stabilizer's Bluetooth cannot be found or if it is being occupied by another phone, you can try clearing the stabilizer's Bluetooth information to reconnect it. -
Page 25: Auto Calibration & Firmware Update
App Guidance ⑤ ⑥ ① ⑦ ② ③ ④ ① Switch between front camera and rear camera. ② Smart Tracking: Auto face/framed object tracking ③ Settings: To set parameters for stabilizer and camera and to check out available firmware updates. ④ Focus/Zoom in or out ⑤ Beauty &... -
Page 26: Firmware Update
(except the joystick) to wake up the stabilizer. Then, repeat the calibration process following the steps mentioned above. Firmware Update You will be prompted in the Hohem Joy App if a new firmware update is available. Follow the on-screen instructions in the App to update firmware. 11 Specifications... -
Page 27: Warranty Terms
12 Warranty Terms ① Customers are entitled to replacement service in case of quality deficits or functional disorder found in the product within 7 days upon the purchase date. But ensure the commodity and package with no damage, and we will offer a brand new replacement after confirming the product's problem is not related to artificial damage. - Page 28 Scan the QR code to access the tutorial...
