WIZ108SR User Manual
Version 1.42
© 2015 WIZnet Co., Ltd. All Rights Reserved.
☞ For more information, visit our website at
http://www.wiznet.co.kr
Arrow.com.
Downloaded from

Advertisement

Table of Contents
loading

Related Manuals for Wiznet WIZ108SR

Summary of Contents for Wiznet WIZ108SR

  • Page 1 WIZ108SR User Manual Version 1.42 © 2015 WIZnet Co., Ltd. All Rights Reserved. ☞ For more information, visit our website at http://www.wiznet.co.kr Arrow.com. Downloaded from...
  • Page 2 Added “4.4 Booting Time” and “4.5 HW_TRIG Pin”. 2013-02-05 V1.30 Added attention for using serial command. < Page 25 > Added explanation about WIZ108SR-EVB revision 1.4 Added EVB Revision Notification Added “4.4 Booting Time” and “4.5 HW_TRIG Pin”. Added “Table 4. Available firmware version with hardware version”.
  • Page 3 Module Revision Notification <WIZ108SR V1.2 / V1.4 Module> WIZnet mainly revised the hardware and software of WIZ108SR with the discontinuance of the main MCU, W7100, in November 2012. We replaced the W7100 with W7100A, and upgraded several functions for better performance and convenience.
  • Page 4 WIZnet’s Online Technical Support If you have something to ask about WIZnet products, write down your question on Q&A Board in WIZWiki Forum (http://wizwiki.net/forum/). WIZnet will give an answer as soon as possible. COPYRIGHT NOTICE Copyright 2015 WIZnet Co., Ltd. All Rights Reserved.

  • Page 5: Table Of Contents

    Table of Contents 1. Introduction ....................1 1.1 Key Features ..................1 1.2 Product Contents ( WIZ108SR-EVB model ) ............. 2 1.3 Product Specification ................3 1.3.1 WIZ108SR Module Specification ............3 1.3.2 WIZ108SR Module Interface ..............4 1.3.3 Pin Header Connector Pin-Assignment ........... 5 2.
  • Page 6 Figures 1. WIZ108SR I ................. 4 IGURE NTERFACE 2. WIZ108SR C .............. 5 IGURE ONNECTOR SSIGNMENT 3. WIZ108SR C ) ......... 6 IGURE ONFIGURATION ETWORK ONFIGURATION 4. S ............7 IGURE EARCHING WITH BROADCAST METHOD 5. S ..............7 IGURE...

  • Page 7: Introduction

    RS-422/485 serial interface. In other words, WIZ108SR is a protocol converter that transmits the data sent by serial equipment as TCP/IP data type and converts back the TCP/IP data received through the network into serial data to transmit back to the equipment.

  • Page 8: Product Contents (Wiz108Sr-Evb Model)

    1.2 Product Contents (WIZ108SR-EVB model) WIZ108SR WIZ108SR WIZ108SR Interface Board 12-pin Cable ( Connect WIZ108SR with Interface Board ) Accessories LAN Cable Table 2. Product Contents ☞ If there is any missing item, contact to the shop where you purchased.

  • Page 9: Product Specification

    Ethernet are all supported and one standard Ethernet Jack is mounted in the board of WIZ108SR. One serial port is provided in WIZ108SR via 12-pin connector which features the standard RS- 422/485 specification. WIZ108SR can be powered by a DC 3.3V power supply with the 250mA current supply.

  • Page 10: Wiz108Sr Module Interface

    1.3.2 WIZ108SR Module Interface Figure 1. WIZ108SR Interface WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...

  • Page 11: Pin Header Connector Pin-Assignment

    1.3.3 Pin Header Connector Pin-Assignment WIZ108SR provides an external connector to connect it with your application board. The pin assignment and definition of the connector are introduced in Figure 2 and the specification of each pin is described in Table 3.

  • Page 12: Getting Started

    2. Getting Started 2.1 Configuration Tool 2.1.1 Network Configuration Figure 3. WIZ108SR Configuration Tool (Network Configuration Page) 1) Search The Search function is used to search all devices existing in the same LAN or in WAN. By using UDP broadcast as shown in Figure 4, all connected devices in the same subnet will be found.

  • Page 13: Figure 4. Searching With Udp Broadcast Method

    Changed value is saved in the EEPROM of the module. Thus, the value is not removed even though power is disconnected. 3) Upload Firmware will be uploaded through network WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com.

  • Page 14: Figure 6. Simple Ping Test Program

    (PPPoE mode is not supported in the WIZ108SR) - Using the follow IP Address (Static) This is option for setting WIZ108SR module’s IP with static IP address. Firstly, select MAC address which you wanted to set as static IP in the board list. Then “Device IP, Subnet, Gateway box”...
  • Page 15 UDP just processes the data communication without connection establishment. The Network mode of WIZ108SR can be divided into TCP Server, TCP Client and Mixed mode according to the connection establishing method. At the TCP server mode, WIZ108SR operates as server on the process of connection, and waits for the connection trial from the client.
  • Page 16 As like TCP Server mode, the Mixed mode is useful for the case that the monitoring center tries to connect to the serial device (in which WIZ108SR is used) to check device status. In addition to this, if any emergency occurs in the serial device, the module will change to Client mode to establish the connection to the server and deliver the emergency status of the device.

  • Page 17: Serial Configuration

    2) COM port Setting The parameters of COM port of WIZ108SR are listed well in this page. Users can set the COM port of WIZ108SR by selecting the value of each parameter in the drop down list. ☞ By clicking the “Setting” button, changed value can be applied.
  • Page 18 This function is for module configuration not through network with Configuration tool but through serial communication. At the default status, the serial command mode is disabled. When you want to set via serial communication, check “enable”. WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com.

  • Page 19: Option Configuration

    In order to close the connection, the ‘Close’ command should be given. This function can be used for more than two or more systems to connect to a WIZ108SR module. If one system holds the connection to the WIZ108SR, other systems cannot connect to the module.
  • Page 20 For the security issues, WIZ108SR can have its own password for searching. The password is stored in the EEPROM of WIZ108SR, and it can be modified via this configuration tool. The password can be any alphabet or number. Its length can be variable and its maximum length is 8 bytes.

  • Page 21: Firmware Upload

    4) When the window as shown below Figure is displayed, select file for upload and click “Open” button. ☞ Do not upload any other files except for WIZ108SR application firmware file. If you uploaded other files by accident, Configuration Tool cannot search out WIZ108SR so that uploading a correct one via Ethernet is impossible.

  • Page 22: Figure 10. Firmware Uploaded Successfully

    5) When the firmware is uploaded successfully, the following message box will be shown. Figure 10. Firmware uploaded successfully WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 23: Figure 11. Error Message About Uploading Different Version Firmware

    WIZ108SR V1.2 V3.03 ~ V3.14 There is no difference in all functions and features. V1.4 or above V4.04 or above Table 5. Available firmware version with hardware version WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 24: Serial Configuration

    If WIZ108SR is in serial configuration mode, users can use the following predefined commands to configure WIZ108SR via serial interface. The format of serial command is shown in Figure Each command starts with a command name (2 characters) and ends with ‘\r\n’. If the data field is null, it means the command does a reading operation.

  • Page 25: Table 5. Serial Command List

    Connection password (Max. 8 bytes) ******** Search password (Max. 8 bytes) 1:Enable, 0:Disable Show serial input echo or not WIZ108SR is not supported this CMD. Debug log message (read only) Error message (read only) Save setting message (After command, WIZ108SR needs some...
  • Page 26 In HEX: 44 44 0D 0A In ASCII: DD0\r\n or DD1\r\n No Response With data In HEX: 44 44 31 0D 0A or … Null data In ASCII: CP\r\n CP0\r\n WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 27 In ASCII: SM\r\n SM255.255.255.0\r\n Null data In HEX: 53 4D 0D 0A In ASCII: SM255.255.255.0\r\n No Response With data In HEX: 53 4D 32 35 35 2E 32 35 35 WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 28 In HEX: 44 42 31 0D 0A In ASCII: PR\r\n PR0\r\n Null data In HEX: 50 52 0D 0A In ASCII: PR0\r\n No Response With data In HEX: 50 52 30 0D 0A WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 29 In HEX: 53 53 30 31 30 31 30 31 2B 2B 0D 0A In ASCII: NP\r\n NP110\r\n Null data In HEX: 4E 50 0D 0A With data In ASCII: NP110 \r\n No Response WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 30: Serial Command Executing Example

    WIZ108SR into serial configuration mode. And then, the user inputs command ‘MC’ with ‘Enter’ key pressed to read the MAC address of the WIZ108SR. You can find that the WIZ108SR responses with ‘MC00:08:DC:01:02:03’. In the same way, we can read the IP address of WIZ108SR.

  • Page 31: Figure 13. Serial Command Executing Example

    Refer to 1)~3), usually if you want to change the operation mode from Server mode to Client mode, you should input something like this: OP0 --->SV--->RT Please, note that the data connection will be closed firmly once the WIZ108SR goes into serial configuration mode. Figure 13. Serial command executing example Attentions: 1) The ‘SV’...

  • Page 32: Hardware Specification

    4.1 WIZ108SR Dimension 30.00 3.50 11.50 11.50 3.50 3.00 3.50 38.00 3.50 48.00 2.54 2.73 8.65 2.54 Figure 14. WIZ108SR Dimensions (unit : mm) WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 33: Wiz108Sr Signal Connection Method

    4.2 WIZ108SR Signal Connection Method 4.2.1 RS-422 Interface Connection Figure 15. RS-422 Interface Connection Method 4.2.2 RS-485 Interface Connection Figure 16. RS-485 Interface Connection Method WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 34: Wiz108Sr Interface Board Schematic

    4.3 WIZ108SR Interface Board Schematic Figure 17. WIZ108SR Interface Board Schematic WIZ108SR User Manual (WIZnet Co., Ltd.) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 35: Booting Time

    Rev 1.4 V4.03 ~ 70ms Table 7. WIZ108SR’s Booting Time 4.5 HW_TRIG PIN The way of detection connect status is monitoring the HW_TRIG Pin. When the connection is established, HW_TRIG pin goes Low. And, it will go HIGH when connection is closed. Actually, this pin works both direction, like Input and Output.

  • Page 36: Warranty

    WIZnet warrants our products and its parts against defects in materials and workmanship under normal use for period of standard ONE(1) YEAR for the WIZ108SR board and labor warranty after the date of original retail purchase. During this period, WIZnet will repair or replace a defective products or part free of charge.
