- Page 1 DV-HMSW4K-44AUD 4x4 HDMI 2.0 Matrix Operating Instructions 244 Bergen Blvd Woodland Park NJ 07424 www.fsrinc.com 973-998-2300 43465 LIT1884...
- Page 2 Operating Instructions Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
Operating Instructions Table of Contents 1. Features....................4 2. Package Contents ................4 3. Specifications ..................4 4. Panel Descriptions ................5 4.1 Front panel ..................5 4.2 Rare panel ..................6 5. Connecting and Operating ..............6 6. Application Diagrams ................ 7 7. -
Page 4: Features
Operating Instructions Dear Customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating, or adjusting this product. Please keep this manual for future reference. 1 . Features • HDMI 2 . 0 version ( Supports 4 K@ 6 0 Hz YUV4 : 4 : 4 ) •... -
Page 5: Panel Descriptions
Operating Instructions 4. Panel Descriptions `4.1 Front panel 1. IR receive window. 2. Output 1-4: short press will select one output, press again to cancel; long press will select all outputs, long press again to cancel. 3. Input 1-4: short press will select one input if an output is already selected; a long press will select one input for all output. -
Page 6: Rare Panel
Operating Instructions 4.2 Rear panel: 1. Analog audio out 2. S/PDIF audio out 3. RS232 for control 4. IR-Ext 5. Ethernet port 6. DC12V/2A input. 7. HDMI output port. 8. HDMI input port. 5. Connecting and Operating 1. Connect source devices to input ports of the matrix 2. -
Page 7: Application Diagrams
Operating Instructions 6. Application Diagram 7. Remote Control Description 1. Power on/Standby. 2. M: Turn off the HDMI output audio 3. W: Lock remote control 4. Output 1-4 5. All outputs select INPUT-Y: a. Press the ALL button. b. Press INPUT-Y button (Y means 1 to 4 of the inputs),then INPUT-Y switched to ALL OUTPUTS. -
Page 8: Panel Control Description
Operating Instructions Note: All buttons use short button presses. Power on/standby: in standby the LCD screen will show “System Shutdown”, 5V • on the HDMI output will be disconnected and the display with have no image. Video switch: output + input (e.g., output1+input2, switches output1 to input1) •... -
Page 9: Video Control
Operating Instructions 8.2 Video control: There are 2 sub-menus in video interface: 1. Switching; 2. On/Off 8.2.1 Video switching Operation: 1. Select “Video” in the main menu, press the “ENTER” button. 2. press “up and down” button to choose “Switching”. 3. - Page 10 Operating Instructions 8.2.2 Output switch control You can open/close any output port, or open/close all output ports. Video outputs are defaulted to open. 1. In the main menu, select “Video” and press “ENTER” button. 2. press “up and down” button to select “On/Off” 3.
-
Page 11: Audio Control Interface
Operating Instructions 8.3 Audio control interface There are 2 sub-menus in audio control interface: Line out, De-Embed (both are defaulted to open) -
Page 12: Edid Setting Interface
Operating Instructions 8.3.1 Switch output audio “Line out” mute/unmute HDMI embedded output audio on any one or all output channels. Operation： 1. select “Audio” in the main menu and press the “ENTER” button. 2. Press “up and down” button to select “Line out”, press the “ENTER” button, the bottom color of the selected turns to white. - Page 13 Operating Instructions Example: switch default1 to output1: Operation： 1. select “EDID” in main menu and press “ENTER” button 2. press “up and down” button to select “Input 1” (“All” means all input) 3. press “ENTER” button to enter the next sub-menu. 4.
-
Page 14: Preset Application
Operating Instructions 8.5 Preset application Preset interface can save the current video, audio, EDID, system setting, etc… Supports 8 different presets, can execute a preset through the web, command, panel button, and recall. Preset control interface has three sub-menus: Call scene Save scene Clear scene Operation：... -
Page 15: Setup Interface
Operating Instructions 8.6 Setup Interface The setup interface can set serial port baud rate, DHCP switch, device reboot and factory reset. 8.6.1 Baud rate setting The options for the baud rate setting are: 9600,19200, 57600, 115200. The default serial port is 115200. Below example is setting baud rate to 9600. - Page 16 Operating Instructions 8.6.2 DHCP Switch DHCP On: dynamic IP address; DHCP Off: static IP address (default is DHCP off) DHCP Operation: 1. select “Setup” in the main menu and press the “ENTER” button. 2. press “up and down” buttons to select “DHCP” setting. 3.
- Page 17 Operating Instructions 8.6.4 Factory Reset reinitializing the setting for the device (default is “NO”). There are two factory settings: 1. Factory Common: factory reset for video switch, EDID, audio and setting (IP address will not be factory rest) 2. Factory All: factory set for video switch, EDID, audio, setting, preset and device name.
-
Page 18: Query Information Interface
Operating Instructions 8.7 Query information interface Query IP and system information. System interface query; company name, device name and version information IP interface query device IP address, MAC address and DHCP status. Operation： 1. select “INFO” In main menu and press “ENTER” button. 2. - Page 19 Operating Instructions...
-
Page 20: Rs232 Control
Operating Instructions 9. RS232 Control 9.1 Open Comm Uart Assistant. 9.2 Comport setting: Choose correct COM port that connects to PC in parameter configuration area Baud Rate: 115200 bps (Default) Parity: None Data Bit: 8 bit Stop Bit: 1 bit 9.3 Enter Port Command in Send options. -
Page 21: Web Control
Operating Instructions 10. Web Control 10.1 Change IP address of PC Before configuring the device through the webpage, it is necessary to configure the IP address of the computer with the device (mainly to ensure that the computer and the device are set in the same network segment). 1. -
Page 22: Login By Browser
Operating Instructions 10.2 Login by Browser Default IP address for log-in:192.168.1.168 Type in user name and password (default user name: admin; default password:123456) Note: suggest the use of a newer version of Google,firefox, browser for better IE11 compatibility. 10.3 Video interface: 1. -
Page 23: Audio Interface
Operating Instructions 10.4 Audio Interface 1. Click output1-4 HDMI turn off HDMI output audio. Operation: e.g.: turn off audio of the TV which connected to HDMI output1 Click output1 HDMI, color will change and TV only with video but no audio. Re-click to turn on audio. -
Page 24: Edid Interface
Operating Instructions 10.5 EDID Interface 1. Input: 00>>Input1, 00~16: EDID number, Input1~4: HDMI input1~4 2. Output: 00~03:default EDID, 04~07: user EDID, 08~11: copy EDID, 12~15: input EDID, 16: Temp EDID, refer to below for more details: 4K60 444-LPCM: 2.0, HDR: HLG 4K60 420-LPCM: 2.0, HDR: None 4K30 444-LPCM: 2.0, HDR: None 1080P60 444-LPCM: 2.0, HDR: None... -
Page 25: Network Interface
Operating Instructions 10.6 Network Interface MAC address cannot be modified, for display only. Static IP: Click DHCP switch(DHCP Off),you can modify IP address, then click “Apply” button, it will countdown. If device IP address same as client re-login web interface. IP, will If unable to refresh automatically, then need to resubmit form manually. -
Page 26: System Setting Interface
Operating Instructions 10.7. System Setting Interface: System Setting： Reboot: Click to reboot device Factory common: Click to reset device for partial function. Factory all: Click to reset device totally. “Reboot” will not clear user parameter; “Factory common” will not clear Network and Preset parameter;... -
Page 27: Firmware Update
FSR factory or Authorized Repair Stations. This warranty shall be cancelable by FSR at its sole discretion if the unit has been subjected to physical abuse or has been modified in any way without written authorization from FSR. -
Page 28: Web Upgrade
Operating Instructions CONTACT INFORMATION: FSR INC. 244 Bergen Blvd. Woodland Park, NJ 07424 Phone: (973) 998-2300 Order Desk Fax: (973) 785-4207 E-mail: sales@fsrinc.com Web: http://www.fsrinc.com...
