RSA Lighting MLV3084 Specification

DESCRIPTION
4.3" round recessed adjustable trim for downlight, wall washing, and
accent applications. For use with 12V MR16 lamp 71W max.
SPECIFICATION FEATURES
A Trim
358˚ x 85˚ adjustable conical wall accent
trim for downlight, wall washing, and
accent applications. 4.3" o.d. trim face.
B Lamp
For use with 12V MR16 lamp 71W max.
Lamp not included.
C Socket
GU5.3 bi-pin socket for 12V MR16.
D Lens
Includes clear protective glass lens.
Can hold up to 1 optical accessory total.
E Finish
MLV3084 Powder coated white trim.
MLV3086 Powder coated black trim.
MLV3087 Industrial silver trim.
ORDERING INFORMATION
Fixture
MLV3084 White Trim
MLV3086 Black Trim
MLV3087 Industrial Silver Trim
www.cooperlighting.com
C
B
A
85º
E
D
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
3.125"
0.875"
2"
4.31" dia.
1.75" dia.
Type
Date
MICROGEM
RECESSED
MLV3084 - 3087
4.3" O.D.
Round Die Cast
Conical Wall Accent
Trim 358˚ x 85˚
Adjustability
FOR 12V MR16 71W max.
Compatible Housings:
C500 / C500-SH
C600 / C600-EL
C700
C800
C900
SH2A
rev. 102406
