RSA Lighting MLV3070 Specification

Cooper lighting indoor lighting specification sheet
Hide thumbs Also See for MLV3070:

Advertisement

Quick Links

DESCRIPTION
4.3" round recessed adjustable eyeball trim for downlight, wall
washing, and accent applications. For use with 12V MR16 lamp 71W
max.
SPECIFICATION FEATURES
A Trim
45˚ adjustable round eyeball trim with
black baffle for downlight and accent
applications. 4.3" o.d. trim face.
B
Lamp
For use with 12V MR16 lamp 71W max.
Lamp not included.
C
Socket
GU5.3 bi-pin socket for 12V MR16.
(Included with Microgem housing sold
separately)
D Lens
Includes clear protective glass lens.
Can hold up to 2 optical accessories total.
E
Finish
MLV3070 Powder coated white trim
with black baffle.
MLV3072 Powder coated black trim with
black baffle.
MLV3073 Powder coated industrial
silver trim with black baffle.
ORDERING INFORMATION
Fixture
MLV3070
White Trim w/ Black Baffle
MLV3072
Black Trim w/ Black Baffle
MLV3073
Industrial Silver Trim w/ Black Baffle
www.cooperlighting.com
C
B
2"
A
45˚
E
D
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
0.5"
4.31" dia.
1.54" dia.
Type
Date
MICROGEM
RECESSED
MLV3070 - 3073
4.3" O.D.
Round Die Cast
Eyeball Trim w/
Black Baffle 45˚
Adjustability
FOR 12V MR16 71W max.
Compatible Housings:
C500 / C500-SH
C600 / C600-EL
C700
C800
C900
SH2A
rev. 102406
