RSA Lighting Flexible LED Neon Alternative Specifications

DESCRIPTION
Flexible linear 24V DC LED light strip with continuous even illumination.
Suitable as an alterna†ive to neon lighting systems.
SPECIFICATION FEATURES
A ...Strip:
A totally flexible, sealed 24V DC LED
strip for indoor and outdoor use as an
alternative to neon. 40' maximum single
run with 96 watt maximum load.
B ...LED:
Super bright LEDs with close 1/2" o/c
spacing for uniform illumination. 2.16W/ft
output in red, yellow and amber colors.
2.4W/ft output in blue, green & white
colors.
C ...Mounting:
Two inch mounting clips (P9) for freeform
flexed installation or six foot mounting
channels (P9CH) for rigid linear installa-
tion are available with through holes for
screw mounting.
D ...Driver:
Requires remote Class II 24V DC LED
driver.
E ...Field Cuttable:
May be cut to size in the field. Cut
location indicators are on the bottom of
the strip and must be adhered to. Cut m
arkers are located every 4" on red, yellow
and amber strips and every 3" on green,
blue and white strips.
www.cooperlighting.com
Catalog #
Project
Type
Closely spaced diodes
provide a uniform
illumination with neon-like
brightness.
0.50"
2" or 6'
1.00"
0.83"
0.72"
ORDERING INFORMATION
LEDEON
Fixture
Flexible LEDEON LED System
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Flexible to a radius of 0.15"
3' standard leads for connection to remote
24V LED driver.
(driver sold separately)
Diode Color
R = Red
B = Blue
A = Amber
G = Green
W = White (6500K)
Comments
Prepared By
Date
Flexible LED
Neon Alternative
Red / Yellow / Amber
Suitable for interior and
exterior installations.
Strip Length
Specify quantity
in feet
LED
LEDEON
2.16W/Ft
2.4W/Ft
Blue / Green /
6500K White
40' Max.
rev. 021207
