ICON Health & Fitness NordicTrack Commercial X14i User Manual
  1. Manuals
  2. Brands
  3. ICON Health & Fitness Manuals
  4. Treadmill
  5. NordicTrack Commercial X14i
  6. User manual

ICON Health & Fitness NordicTrack Commercial X14i User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
nordictrack.com
Model No. NTL22021.2
Serial No.
Write the serial number in the space
above for reference.
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to my.nordictrack.com
CUSTOMER CARE
For service at any time, go to
support.nordictrack.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Serial
Number
Decal
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NordicTrack Commercial X14i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICON Health & Fitness NordicTrack Commercial X14i

Summary of Contents for ICON Health & Fitness NordicTrack Commercial X14i

  • Page 1 nordictrack.com USER’S MANUAL Model No. NTL22021.2 Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.nordictrack.com CUSTOMER CARE For service at any time, go to support.nordictrack.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your incline trainer before using your incline trainer. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 18. Read, understand, and test the emergency 24. Do not attempt to move the incline trainer stop procedure before using the incline until it is properly assembled. (See trainer. (See HOW TO TURN ON THE POWER ASSEMBLY on page 8, and HOW TO MOVE on page 15.) Always wear the clip while using THE INCLINE TRAINER on page 25.) You must the incline trainer.
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK ® COMMERCIAL X14i incline trainer. manual. To help us assist you, note the product model The COMMERCIAL X14i offers a selection of features number and serial number before contacting us.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 8: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing materials until you fi nish all assembly steps. the included hex keys •...
  • Page 9 2. Make sure that the power cord is unplugged. Remove the four 3/8" x 3 1/4" Screws (18) from the Base (74) (only one side is shown). Save the Screws. 3. Remove the four 3/8" x 2 3/4" Screws (22) from the Uprights (83).
  • Page 10 4. Set the Uprights (83) on the Base (74). Make sure that the hole with the Upright Wire (75) is on the right side. Attach the right Upright (83) with two of the 3/8" x 3 1/4" Screws (18) and two of the 3/8" x 2 3/4"...
  • Page 11 6. Remove the 5/16" x 1" Screws (87) and the 5/16" Star Washers (65) from the brackets (C) on the right and left handrail assemblies (D, E). With the help of a second person, position the right and left handrail assemblies (D, E) upside down as shown.
  • Page 12 8. Slide the Right Inside Upright Cover (70) against the lower end of the right Upright (83). Then, press the Right Outside Upright Cover (71) against the Right Inside Upright Cover until it snaps into place. Make sure that the wires (G) are not pinched, pulled tightly, or resting across the indicated screw (H).

  • Page 13: How To Use The Incline Trainer

    HOW TO USE THE INCLINE TRAINER HOW TO CONNECT THE POWER CORD The outlet must be on a nominal 120-volt circuit capable of carrying 15 or more amps. To avoid Use a Surge Suppressor overloading the circuit, do not plug other electrical devices, except for low-power devices such as cell Your incline trainer, like other electronic equipment, phone chargers, into the surge suppressor or into...
  • Page 14 CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode, you can change the speed and incline of the incline trainer with the touch The advanced incline trainer console offers a selec- of a button. As you exercise, the console will display tion of features designed to make your workouts more instant exercise feedback.
  • Page 15 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the incline trainer has been The console features a tablet with a full-color touch exposed to cold temperatures, allow it to warm to screen. The following information will help you become room temperature before you turn on the power.
  • Page 16 HOW TO SET UP THE CONSOLE 5. Calibrate the incline system. Before using the incline trainer for the first time, set up First, touch your name or Hello on the screen. the console. Next, select the settings main menu. Then, select the maintenance section, touch Calibrate Incline, 1.
  • Page 17 HOW TO USE THE MANUAL MODE Note: If the walking belt is moving at a high speed and you adjust the incline below 0% or 1. Insert the key into the console. above 15.5%, the speed of the walking belt may automatically decrease.
  • Page 18 7. When you are finished exercising, remove the 3. Select a map workout. key from the console. To select a map workout, touch the desired button Step onto the foot rails and press the Stop button on the screen. Note: The featured map workouts on the console or tap on the screen.
  • Page 19 HOW TO USE A DRAW YOUR OWN MAP 4. Save your workout. WORKOUT Touch Save New Workout on the screen. If desired, Note: To use a draw your own map workout, the change the title of the workout or add a description, console must be connected to a wireless network (see and then press the >...
  • Page 20 HOW TO USE A DISTANCE OR TIME WORKOUT 6. Start the workout. Note: To use a distance or time workout, the console See step 4 on page 18. Note: During a distance or must be connected to a wireless network (see HOW time workout, the display will not show a map.
  • Page 21 HOW TO CHANGE CONSOLE SETTINGS 4. View machine information. IMPORTANT: Some of the settings and features Touch Equipment Info, and then touch Machine described may not be enabled. Occasionally, a Info to view information about your incline trainer. firmware update may cause your console to function slightly differently.
  • Page 22 HOW TO CONNECT TO A WIRELESS NETWORK An information box will ask if you want to connect to the wireless network. Touch the Connect button The console is Wi-Fi enabled, allowing you to set up a to connect to the network or touch the Cancel but- wireless network connection.
  • Page 23 HOW TO USE THE SOUND SYSTEM THE OPTIONAL HEART RATE MONITOR To play music or audio books through the console Whether your sound system while you exercise, you can connect goal is to a personal audio device to the console with an audio burn fat or to cable, or you can connect wirelessly if your device is strengthen your...

  • Page 24: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 25: How To Move The Incline Trainer

    HOW TO MOVE THE INCLINE TRAINER Before moving the incline trainer, insert the key Carefully roll the incline trainer on the wheels to the into the console (A), raise the incline to the maxi- desired location, and then lower it to the level position. mum incline level, remove the key, and unplug the CAUTION: To reduce the risk of injury, use extreme power cord.

  • Page 26: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regular maintenance is important for optimal a. Check the power switch (see drawing c). If the performance and to reduce wear. Inspect and properly switch has tripped, wait for five minutes and then tighten all parts each time the incline trainer is used.
  • Page 27 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is off-center or slips when walked on a. Use only a surge suppressor that meets all of the specifications described on page 13. a. If the walking belt is off-center, first adjust the incline to 40 percent.
  • Page 28 SYMPTOM: The incline trainer will not connect to SYMPTOM: The displays of the console do not the wireless network function properly a. Make sure that the wireless settings on the console a. If the console does not boot up properly, or are correct (see page 22).

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 30 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 31 NOTES...
  • Page 32 NOTES...

  • Page 33: Part List

    PART LIST Model No. NTL22021.2 R1220A Key No. Qty. Description Key No. Qty. Description 3/8" x 5 1/2" Screw Belt #8 x 1 1/4" Screw Front Hood Cover 3/8" Star Washer Front Hood #8 x 3/4" Pan Head Tek Screw Cushion Cap #8 x 3/4"...
  • Page 34 Key No. Qty. Description Key No. Qty. Description Left Tray Right Handrail Bottom Console Base 3/8" x 3/4" Screw Console #8 x 3/4" Machine Screw Right Tray M3 x 12mm Screw #8 x 1" Screw Power Supply #8 x 3/4" Console Screw Incline Motor Controller Right Handrail Standoff...

  • Page 35: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL22021.2 R1220A...
  • Page 36 EXPLODED DRAWING B Model No. NTL22021.2 R1220A...
  • Page 37 EXPLODED DRAWING C Model No. NTL22021.2 R1220A...
  • Page 38 EXPLODED DRAWING D Model No. NTL22021.2 R1220A...
  • Page 39 EXPLODED DRAWING E Model No. NTL22021.2 R1220A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...

This manual is also suitable for:

Ntl22021.2

Table of Contents
