Summary of Contents for ICON Health & Fitness NORDICTRACK COMMERCIAL 2950
Page 1
www.nordictrack.com Model No. NTL22115.1 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.nordictrackservice.com/ registration. CUSTOMER CARE For service at any time, go to www.nordictrackservice.com.
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
Page 4
19. Always stand on the foot rails when starting 26. Do not change the incline of the treadmill by or stopping the walking belt. Always hold the placing objects under the treadmill. handrails while using the treadmill. 27. Never insert any object into any opening on 20.
BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK COMMERCIAL 2950 treadmill. manual. To help us assist you, please note the product ® The COMMERCIAL 2950 treadmill offers an impres- model number and serial number before contacting us.
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 8. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing materials until you fi nish all assembly steps. the included hex key •...
Page 10
3. Insert the fan wire (A) into the left Upright (84). 88, 8 Next, slide the Left Base Cover (89) onto the left Upright (84), and slide the Right Base Cover (90) onto the right Upright. Tip: You may need to use a standard screwdriver to pull the Left Base Cover away from the left Upright so that the Left Base Cover will slide over the welded...
Page 11
5. Attach the Tray (79) to the left and right Tray Brackets (76) with four #8 x 3/4" Truss Head Screws (24); start all four Screws, and then tighten them. Make sure that no wires are pinched. Front View 6. Connect the two fan wires (C). The connectors should slide together easily and snap into place.
Page 12
8. Set the console assembly (E) face down on a soft surface to avoid scratching the console assembly. Remove and discard the four indicated screws (F). Then, remove the Pulse Crossbar (80). 9. IMPORTANT: To avoid damaging the Pulse Crossbar (80), do not use power tools, and do not overtighten the #10 x 3/4"...
Page 13
10. With the help of a second person, hold the con- sole assembly (E) near the Handrails (74). See the inset drawing. Connect the Upright Wire (83) to the console wire (G). The connec- tors should slide together easily and snap into place.
Page 14
12. Start four #8 x 3/4" Truss Head Screws (24) into the Pulse Crossbar (80), and then tighten them; do not overtighten the Screws. 13. Set the Left Handrail Top Cover (73) on the left Handrail (74). Start four #8 x 3/4" Truss Head Screws (24) into the Left Handrail Bottom Cover (75), the left Handrail, and the Left Handrail Top Cover.
Page 15
14. Raise the Frame (52) to the position shown. Have a second person hold the Frame until step 15 is completed. Remove the 5/16" Nut (9) and the 5/16" x 1 3/4" Bolt (3) from the bracket on the Uprights (84). Next, orient the Storage Latch (56) as shown.
Page 16
16. Press the two tabs on the Tablet Holder (16) into the slots (J) in the console assembly (E). Attach the Tablet Holder (16) to the console assembly (E) with four #8 x 5/8" Machine Screws Start First (108). Note: Start the two top Machine Screws fi...
THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Store the heart rate monitor in a warm, dry place. Do not store the heart rate monitor in a plastic bag or If the heart rate monitor looks like the one shown other container that may trap moisture.
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD more amps. To avoid overloading the circuit, do not plug other electrical devices, except for low- Use a Surge Suppressor power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same Your treadmill, like other electronic equipment, can be circuit.
HOW TO UPGRADE THE CONSOLE The treadmill console has been preconfi gured to operate with a digital TV (see the drawings below). To learn about the features of the console, see page 20. To learn about the features of the digital TV, see the user’s manual included with the digital TV.
Page 20
CONSOLE DIAGRAM MAKE YOUR FITNESS GOALS A REALITY WITH FEATURES OF THE CONSOLE IFIT.COM The advanced treadmill console offers an array of fea- With your new iFit-compatible fitness equipment, you tures designed to make your workouts more effective can use an array of features on iFit.com to make your and enjoyable.
Page 21
HOW TO TURN ON THE POWER Note: The console can display speed and distance in either miles or kilometers. To find which unit of mea- IMPORTANT: If the treadmill has been exposed to surement is selected, see step 4 on page 28. For cold temperatures, allow it to warm to room tem- simplicity, all instructions in this section refer to miles.
Page 22
HOW TO SET UP THE CONSOLE To use the equipment settings mode, see page 28. To use the sound system, see page 29. To use Before using the treadmill for the first time, set up the the Internet browser, see page 30. To use the console.
Page 23
The walking belt will begin to move at 1 mph. As As you walk or run on the treadmill, the screen can you exercise, change the speed of the walking belt show the following workout information: as desired by pressing the Speed increase and decrease buttons.
Page 24
To measure your heart rate, stand on the foot HOW TO USE AN ONBOARD WORKOUT rails and hold the contacts with your palms for approximately ten seconds; avoid moving your 1. Insert the key into the console. hands. When your pulse is detected, your heart rate will be shown.
Page 25
The workout will continue in this way until the last 7. When you are finished exercising, remove the segment ends. The walking belt will then slow to key from the console. a stop and a workout summary will appear on the screen.
Page 26
The workout will continue until you reach the goal HOW TO USE AN IFIT WORKOUT that you set. The walking belt will then slow to a stop, and a workout summary will appear on the Note: To use an iFit workout, you must have access screen.
Page 27
To compete in a race that you have previously 6. Monitor your progress with the displays. scheduled, touch the Compete button. To view your Workout History, touch the Track button. To use a See step 5 on page 23. The screen may also set-a-goal workout, touch the Set A Goal button show a map of the trail you are walking or running.
Page 28
HOW TO USE THE EQUIPMENT SETTINGS MODE 6. Select an update time. 1. Select the settings main menu. To select a time for automatic firmware updates, touch the Update Time button and select the Insert the key into the console desired time.
Page 29
9. Enable or disable the street view. To set the amount of time the console will wait before it automatically resets, touch the Safety During some workouts, the screen may show a Screen Timeout button to view a list of times. Then, map.
Page 30
HOW TO USE THE INTERNET BROWSER 3. Update the console firmware. Note: To use the browser, you must have access to a For the best results, regularly check for firm- wireless network including an 802.11b/g/n router with ware updates. SSID broadcast enabled (hidden networks are not supported).
Page 31
IMPORTANT: Keep pets, feet, and other objects 3. Enable Wi-Fi. away from the treadmill while the incline sys- tem is calibrating. In an emergency, pull the key Make sure that the Wi-Fi checkbox is marked with from the console to stop the incline calibration. a green checkmark.
Page 32
To disconnect from a wireless network, select the HOW TO ADJUST THE CUSHIONING SYSTEM wireless network and then touch the Forget button. The treadmill features a cushioning system that If you are having problems connecting to an reduces the impact as you walk or run on the treadmill. encrypted network, make sure that your password is correct.
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal perfor- as shown, the switch has tripped. To reset the mance and to reduce wear. Inspect and properly tighten power switch, wait for fi...
Page 35
SYMPTOM: The incline of the treadmill does not c. Your treadmill features a walking belt coated with change correctly high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to a. Calibrate the incline system (see step 4 on the walking belt or the walking platform unless instructed to do so by an authorized service page 30).
Page 36
b. If the walking belt slips when walked on, fi rst SYMPTOM: The tablet holder does not stay in place remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. Rotate the tablet holder backwards. Then, tighten screws clockwise, 1/4 of a turn.
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
PART LIST Model No. NTL22115.1 R0716A Key No. Qty. Description Key No. Qty. Description 5/16" x 3/4" Screw Drive Roller/Pulley 5/16" x 2" Screw Frame 5/16" x 1 3/4" Bolt 5/16" x 2 1/4" Bolt Drive Motor #8 x 3/4" Screw Motor Belt #10 x 3/4"...
Page 39
Key No. Qty. Description Key No. Qty. Description Right Tray Right Rear Cap 1/2" Thrust Washer Cushion Wheel Stop Controller Clamp Tray Fan Key/Clip Tray Fan Cover Console Frame Cap 2.5A Power Supply Console Frame Standoff Wire Tie Power Supply Plate #8 x 5/8"...
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
