Johannus Symphonica 450 Quick Reference Manual

JOHANNUS Symphonica 450

OVERVIEW OF CONTROLS

A Pedal stops
B Choir stops
C Great stops
D Swell stops
E Tremulants
F Couplers
G Display
H VOL.: general volume
I REV.: reverb volume
J SET
K KT: Keyboard Transfer
L Capture Memory locations
M Pre-Programmed Memory Locations
N 0: Recall/Cancel
O RO: Reeds Off
P CH: Chorus
Q MB: Manual Bass
R CF: Cantus Firmus
S TRANS.: Transposer
T - and + pistons
U CR: Crescendo
V MENU
W 0: Recall/Cancel
X Manual Choir
Y Manual Great
Z Manual Swell
AA Key switch
AB Solo voices
(Premium/Platinum Voice Package)
AC MIDI stops
AD Orchestral voices
(Platinum Voice Package)
AE Intonation styles
AF Intonation variations
AG S/S: All swells to Swell
AH SEQ- and SEQ+ buttons

SWITCH ON

Switch on the organ with the key switch at the right, next to the manuals. Wait several seconds. Starting the
control functions and the settings will take some time.
The lamps of the 0-pistons and the as standard set functions light up. The settings appear on the display.

ACCESSORIES

All Swells to Swell (S/S):
All Swells to Swell transforms the swell pedal for the Swell to a swell pedal for the whole organ.
If no expression pedal is configured as a swell pedal for the Swell, the S/S piston cannot be activated.
Sequence - and + (SEQ- and SEQ+):
Sequence is a function to call up capture memory locations in a sequential way.
Keyboard Transfer (KT):
Keyboard Transfer is a function to switch the manuals of the Choir and the Great.
Reeds Off (RO):
Reeds Off is a function to switch off all reeds simultaneously.
Chorus (CH):
Chorus is a function for lightly detuning the organ stops to give it a broader and livelier sound.
Manual Bass (MB):
Couples the Pedal monophonic to the Great. Only the lowest key that is played on the Great is coupled from the
Pedal to the Great.
Cantus Firmus (CF):
Couples the Swell monophonic to the Great. Only the highest key that is played on the Great is coupled from the
Swell to the Great.

Transposer (TRANS.):

The Transposer function shifts the pitch by half-tone increments (from -8 to +8). The set pitch can be read on the
display (Trans:..).
- Press the TRANS.-piston.
- Use the - and + pistons to set the pitch.

Crescendo (CR):

Crescendo is a piston to activate the crescendo pedal.
If no expression pedal is configured as a crescendo pedal, the CR piston cannot be activated.

Recall / Cancel function (0):

The 0-piston cancels registration in two ways:
- A short press on the 0 piston: Only the last change is cancelled.
- A long press on the 0 piston: All registrations are cancelled.

JOHANNUS MENU (MENU)

In the Johannus Menu several functions of the organ can be set. Press the MENU piston to activate the Johannus
Menu on the display. Navigating the menu is done with the - and + pistons. Confirmation of a choice is done with
the SET piston. Cancel or step back in the menu is done with the MENU piston.
Quick Reference Guide
