- Page 3 All rights reserved. Nothing in this publication may be reproduced, stored in a computerised data file or made public in any form or in any way either electronically, mechanically, by way of photocopying, recording or in any other manner without prior written permission from Johannus Orgelbouw b.v.
-
Page 4: Table Of Contents
Switch on ........................7 Transport and storage ....................7 DESCRIPTION OF THE ORGAN ..................8 Overview of the main components ................. 8 Overview of controls ....................... 9 Symphonica 35 ......................9 3.2.1 Symphonica 45 ......................10 3.2.2 Symphonica 55 ......................11 3.2.3... - Page 5 MAINTENANCE, TROUBLESHOOTING AND WARRANTY ..........30 Maintenance ......................... 30 5.1.1 Cabinet maintenance ....................30 5.1.2 Maintenance of the manuals ..................30 Problems ........................30 5.2.1 Reposition the pedal ....................31 Warranty ........................31 MIDI IMPLEMENTATIONS ....................32 MIDI Implementation Chart ..................32 MIDI specifications .......................
-
Page 6: Safety
Keep this user manual with the organ. Only a technician authorised by Johannus Orgelbouw b.v. may open the organ. The organ contains static-sensitive components. The warranty will become null and void if the organ is opened by a non-authorised person. -
Page 7: Installation
INSTALLATION Install and connect 1. Position the organ on a stable, horizontal surface. 2. Lean the organ slightly backward. 3. Slide the pedal (A) against the pedalboard of the organ (B). 4. Put the organ upright. 5. Place the music desk (C) using the music desk supports in both holes in the stop panel. -
Page 8: Description Of The Organ
DESCRIPTION OF THE ORGAN Overview of the main components Symphonica 35 Symphonica 45 A Tweeters B Music desk C Surround loudspeakers D Subwoofer system E Loudspeakers F General Crescendo pedal G Expression pedals H Pedal I Organ bench Symphonica 55 Not taken into production yet... -
Page 9: Overview Of Controls
Overview of controls 3.2.1 Symphonica 35 Pedal stops Orchestrals (solo) Choir stops Tremulants Great stops Main group intonations Swell stops MIDI stops Tweeters Subgroup intonations Couplers, Keyboard transfer Manual Swell All Swells to Swell Manual Great Sequence -, Sequence +... -
Page 10: Symphonica 45
3.2.2 Symphonica 45 Pedal stops Subgroup intonations Choir stops Manual Swell Great stops Manual Great Swell stops All Swells to Swell Tweeters On/off key switch Couplers, Keyboard transfer Manual Choir Sequence -, Sequence + 0 and reset button Orchestrals (key) MENU Volume control organ General Crescendo... - Page 11 3.2.3 Symphonica 55 Not taken into production yet Pedal stops Orchestrals (solo) Choir stops Tremulants Great stops Main group intonations Swell stops MIDI stops Tweeters Subgroup intonations Couplers, Keyboard transfer Manual Swell All Swells to Swell Manual Great Sequence -, Sequence + Manual Choir Orchestrals (key) On/off key switch...
-
Page 12: Connect And Switch On The Peripherals
MIDI MOD.: This is a programmable MIDI output for connecting a module or expander, for example. MIDI SEQ.: This is a non-programmable MIDI output for connecting a sequencer or PC (with the optional Johannus Intonat program), for example. - Page 13 MIDI MOD. of the instrument. AUX OUT: This is an output for connecting an external (stereo) amplifier. EXT. REV.: This is an output for connecting Johannus external acoustics. This system imitates the spatial effect of a concert hall or cathedral.
-
Page 14: Operation
St. Salvius church, Limbricht 2.5 s Zuidervermaning, Westzaan 2.5 s Frogner Kirke, Oslo 3.5 s Feike Asma hall, Johannus Ede 3.5 s Plantage church, Zwolle 4.5 s St. Jozef, Utrecht 4.5 s Old Church, Ede ... -
Page 15: Intonations
Connect a PC to the organ. Use the MIDI SEQ. output. See §3.4. 2. Save the intonation settings on the PC using the Johannus intonation program. Restore the factory intonation settings The current intonation settings will be lost if the settings are not saved on a PC. -
Page 16: Orchestrals
Orchestrals Orchestrals are high-quality, classical instrument voices especially for playing key instruments and/or solos. Possible options are: Keyboard instruments: : strings Str. : harpsichord Harps. : piano Piano : gospel organ Gos.O. : lesley effect Lesley Solo instruments: : flute... -
Page 17: Couplers
Couplers Manual couplers: Swell – Choir: Fully couples all keys of the Swell to the Choir. Swell – Great: Fully couples all keys of the Swell to the Great. Choir – Great: Fully couples all keys of the Choir to the Great. ... -
Page 18: Change The Registration
4.10 Change the registration The 0 button cancels registrations at two levels: Briefly press the 0 button: This cancels only the last change. Press the 0 button for a long time: All registrations are cancelled. 4.11 Pre-programmed memory locations Pre-programmed memory locations are available through the operating buttons PP to T. -
Page 19: Capture Memory
4.12 Capture memory Using the capture memory, a registration can be activated with one button. The capture memory consists of eight levels. Each level has eight memory locations. These levels are shown on the display (Mem:..). The 256 capture memory locations are initially empty and for the user to be programmed. -
Page 20: General Crescendo
Programme the transposer 1. Press the TRANS. button. 2. Set the pitch using the - and + buttons. 3. Press the SET button. The pitch change is stored in memory. When the organ is switched on again, the programmed pitch will be active. 4.14 General Crescendo The General Crescendo pedal can be used to activate different... -
Page 21: Easy Menu
4.15 Easy Menu The Easy Menu is an operating system the settings of which can be read on the display. The Easy Menu is operated with the - and + buttons and the SET and the MENU buttons. The Easy Menu consists of the following modes: Orchestrals ... -
Page 22: Midi Config
The piano must not be set to ‘Extended’ when playing piano MIDI files. 7. Press the SET button. The selected setting is saved in the memory and you automatically return to the menu. 8. Press the MENU button to return to the main menu. 9. -
Page 23: Temperaments
Programme Tuning 1. Press the MENU button. 2. Use the - and + buttons to select the Tuning mode on the display. 3. Press the SET button. The display shows the current tuning setting (Tune: ...Hz). 4. Use the - and + buttons to select the required pitch. 5. -
Page 24: Keyboard Config
6. Press the SET button after having changed one or more keys. The set own temperament is saved in the memory and you automatically return to the main menu. The changes you make on the central keyboard of the great stops are automatically implemented on the entire organ. -
Page 25: Datadump
Preset default: Resets the factory settings of the fixed combinations. Crescendo default: Resets the factory settings of the General Crescendo pedal. Reverb Program: Resets the factory settings of the acoustics. 5. Press the SET button. The display shows a prompt for confirmation. 6. -
Page 26: Startup Settings
4.15.10 Startup Settings The Startup Settings mode saves the required default intonation in the memory. Intonation: 1. Press the MENU button. 2. Use the - and + buttons to select the Startup Settings mode. 3. Press the SET button. The display shows the set intonation. 4. -
Page 27: Reverb
9. Use the - and + buttons to select the required tweeters volume. Press the SET button. 10. All selected settings are saved in the memory and you automatically return to the main menu. 11. Press the MENU button to exit the Easy Menu. When exiting the Startup Settings (press the MENU button) between times, all Startup Settings changed until that moment are stored in the memory. - Page 28 12. The display shows a prompt for confirmation. Use the - and + buttons to select Yes or No. 13. Press the SET button to confirm. 14. Press the MENU button to return to the main menu. 15. If the change has not been saved, the display will show Discard changes?.
-
Page 29: Tracker Action
4.15.13 Tracker Action The Tracker Action mode is for setting the volume of the key mechanism. 1. Press the MENU button. 2. Use the - and + buttons to select the Tracker Action mode. 3. Press the SET button. The display shows the current manual setting of one of the manuals. -
Page 30: Maintenance, Troubleshooting And Warranty
MAINTENANCE, TROUBLESHOOTING AND WARRANTY Maintenance Overview Component Maintenance Frequency Cabinet Clean. See § 5.1.1. As required Manuals Clean and remove scratches. See § As required 5.1.2. 5.1.1 Cabinet maintenance The cabinet is made of solid wood and wood veneer. Do not use furniture polish or teak oil to clean the organ ... -
Page 31: 5.2.1 Reposition The Pedal
6. Contact your dealer if the pedalboard does not work properly. Warranty The stipulations are specified in the warranty certificate. The warranty will become null and void if changes or repairs are made to the organ by persons or organisations that are not authorised by Johannus Orgelbouw b.v. -
Page 32: Midi Implementations
MIDI IMPLEMENTATIONS MIDI Implementation Chart JOHANNUS Organs Date: December 2009 Version 1.00 MIDI Implementation card Functions Transmitted Recognized Remarks Default See MIDI Specs See MIDI Specs Basic See MIDI Specs Changes See MIDI Specs Channel Default Mode 3 Mode 3... -
Page 33: Midi Specifications
7 bytes and the last byte are always the same. Only the value of the 8th byte varies. This is the ‘sys ex message’ that Johannus generally uses: F0 00 4A 4F 48 41 53 XX F7 (hexadecimal). The ‘sys ex messages’... - Page 34 (for example PP = 00 P = 01) through the MIDI MOD. output. These sys ex codes are only important when the Johannus sound module CSM 128 has been connected to the instrument. Other MIDI codes (transmitted) Press the 0 button to transmit the sys ex code, ‘all stops off’...
