Washing Machine
Model: WWT8011

Advertisement

Table of Contents
loading

Related Manuals for Westinghouse WWT8011

Summary of Contents for Westinghouse WWT8011

  • Page 1 Washing Machine Model: WWT8011...

  • Page 2: Table Of Contents

    Congratulations Congratulations on the purchase of your new washing machine. We trust you will be delighted with it. Please read this instruction book carefully. It will give you the information you need to Care for and Use your washing machine Other documents you should read supplied with your new machine include: Installation Instructions which must be followed to ensure the machine works properly and to avoid an unnecessary service call.

  • Page 3: Control Panel

    CONTROL PANEL 1 Program Selector 5 Save Favourite Button Selects the wash program see page 7. Selects the save favourite program see page 10. 2 Option Select Buttons 6 Delay - End Button Selects the wash Temperature or Spin Speed or Soak Time or Rinse Type see page 9 - 10.

  • Page 4: Important Safety Instructions

    Please read the user manual carefully and store in a Children should be supervised to ensure handy place for later reference. Pass the user that they do not play with the appliance. manual on to possible new owners of the washing If this appliance is supplied from an extension machine.

  • Page 5: Environment Concerns

    ENVIRONMENT CONCERNS Packaging Materials Ecological Hints To save water, energy and to help protect the Environmental Tip environment, we recommend that you follow these tips: The materials marked with the symbol recyclable. Normally soiled laundry may be washed without prewashing in order to save >PE<...

  • Page 6: Water Saving Technology

    Eco Rinsing BEFORE you do your first wash, we suggest you read the instructions on page 5 for Eco rinse is the preferred rinsing option. It is done adding detergent, fabric softener or bleach. by spraying water on the clothes, spinning the water out and repeating this sequence six more times.

  • Page 7: Washing Intructions

    These Washing Instructions are of a general If an out of balance occurs, the machine may stop spinning and then start spinning again to try and nature and you should get good wash results by following them. overcome the out of balance before alerting you with ‘beeping’.
  • Page 8 Load the Washing Machine Add the Detergent When loading the clothes into your washing When using the washing machine for the first machine, there are four things to remember: time, check that the dispenser is set for the type of detergent you will use. To do this, proceed as Clothes must be loaded evenly around the follows: agitator.
  • Page 9 Adding Bleach If you want to use fabric softener, see ‘Add fabric softener’. Close the drawer by pushing it backwards into add bleach the top panel of the washing machine when you have finished adding detergent. Add Fabric Softener Bleaching of clothes can help to remove stains, heavy soiling and to kill bacteria.

  • Page 10: Operating Your Washing Machine

    OPERATING YOUR WASHING MACHINE Starting Your Washing Machine You can select a new program position at any time. If you do move the Program ICON after you have Turn on the taps and turn power on at the started a wash program, the effect will be different power point.

  • Page 11: Your Program Guides

    YOUR PROGRAM GUIDES Select this program Icon Spin Speed (rpm) Wash Water Soak Temp. Times Default Max. Regular For normally soiled cotton load at rated load capacity. Deep Warm Cold Wash For mixed fabrics. Cold Cold Fast Fast Wash For a very small load of mixed fabrics. Favourite Delicates For lingerie, lace, trimmed and embroidered items.

  • Page 12: Using Your Washing Machine

    USING YOUR WASHING MACHINE Choosing the Wash Water Temp. Select the Spin Speed For each wash program your washing machine Touch the Options button ( ) to select automatically selects a suitable fill water temperature. the Spin icon, then touch the Modify Option buttons ( ) to select the spin speed that If you want to use a different wash water...
  • Page 13 Select the Rinse Option If your cold water supply pressure is low, Eco rinse might not be fully effective in rinsing suds from your clothes. If this is the case then use Deep rinse. Note that you can save this option under your Favourite button if you wish.
  • Page 14 Delay End Option To change the “beeping” selection: When the washing machine in STAND-BY- Before you start the program, this option MODE or PAUSE MODE, press and hold makes it possible to define the end of the washing “Start/Hold To Pause” button for about 3 program by 2, 4, 6 or 8 hours.

  • Page 15: Features Of Your Washing Machine

    FEATURES OF YOUR WASHING MACHINE Additional features on your washing machine are described in this section. Models with Digital Display Information and Guidance Feature The digital display will show the time in minutes (or The washing machine will give you information by hours and minutes) to complete the wash program.

  • Page 16: Caring For Your Washing Machine

    CARING FOR YOUR WASHING MACHINE Your washing machine will give you long and Turn the bag inside out and remove the lint. trouble-free service, if you follow the instructions Wash the filter bag and dispenser cup in hot in this section. These instructions show you how water.
  • Page 17 Cleaning Your Washing Machine How To Clean the Stainless Steel Wash Bowl To clean the inside and outside of your washing machine you should: Wipe with a cleaning product which is marked suitable for stainless steel. Wipe the surface with a mild dishwashing detergent and warm water.

  • Page 18: Helpful Hints In Dealing With Washing Problems

    HELPFUL HINTS IN DEALING WITH WASHING PROBLEMS Stained Clothes - Hints for Removing Stains Residues on Washed Items The guide to stain removal on page 17 may assist Some detergents have ingredients which do not you in stain removal. fully dissolve and as a consequence, may leave white residue or particles evident on the surface of Treat all stains as soon as possible.
  • Page 19 Yellowing or Greying Clothes Problem Possible causes What to do Incorrect wash times and using insufficient ONLY use low sudsing, front load detergent which can cause redepositing of washer detergent in this machine, such detergent on clothes. as Cold Power for Front Loaders and High Efficiency Top Loaders or detergent Using incorrect type or too much detergent labelled “Matic”.

  • Page 20: A Guide To Stain Removal

    Ball point pen ink Same as for whites - use oxygen type bleach. Beetroot Rinse as soon as possible under cold water. Same as for whites - use oxygen type bleach. Cover area with meat tenderiser (msg). Apply warm water to Same as for whites but select water temperature make a paste.

  • Page 21: Troubleshooting

    Do not call for service until you have checked the points listed below. If you call for service and there is nothing wrong with your washing machine, you will have to pay for the service call. You will have to pay even when your washing machine is under warranty. Before you call for service, check the points in the table below.
  • Page 22 Other Diagnostic Help and A Guide for When You Should Call for Service If you are having a problem with your washing machine, make sure you have followed ALL of the instructions on this page and the previous page before calling for service. Display Code Description Customer action (Summary)
