- Page 1 Installation manual PV Solar MODULE Please read this manual carefully before operating your set and retain it for future reference. N-TYPE MODELS LGXXXN2T-J5 www.lgsolarusa.com MFL70700908...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY ..............03 BEFORE & AFTER INSTALLATION ......05 Before Installation ................05 After Installation ...................05 ELECTRICAL INSTALLATION .......06 Danger ....................06 Electrical Connections .................06 Diodes ....................06 Series Connection ................06 Parallel Connection ................07 General Wiring..................07 Earth Grounding ..................07 MECHANICAL INSTALLATION ......08 Module Mounting .................08 Site Consideration ................08 Mounting Methods ................08... -
Page 3: Safety
SafETY The instructions related to safety and use indicated No electrical parts like cables are in the this installation manual are intended for the located after installation between prevention of unexpected danger, damage, or failure. laminate and mounting structure. DaNgEr WarNINg CaUTION Non-compliance with the instructions may cause product... - Page 4 Do not touch the glass surface or Module frame of the solar module after Module Installing structure installation of the module. It may (Stralght type) Installing structure (bent type) result in injury or death. Heavy objects must be kept off of the solar module.
-
Page 5: Before & After Installation
BEFORE & AFTER INSTALLATION Before Installation Please carefully read this manual before installation. • Partial shadowing may substantially reduce panel and system output and may be the reason for the damage • Solar module installation and maintenance must be of solar module. performed by qualified and authorized installer. -
Page 6: Electrical Installation
ELECTRICAL INSTALLATION Danger Diodes • Avoid all electrical hazards when installing, wiring, • All LG modules are equipped with factory installed operating and maintaining all panels. bypass diodes. The factory-installed diodes provide proper circuit protection for the module from • Do not connect panels that have different electrical unexpected shadows. -
Page 7: Parallel Connection
Installations, Canadian Electrical Code, Part 1. Module frame General Wiring Bolt • LG Electronics recommends that all wiring be double Flat washer insulated with a minimum rating of 90°C (194°F). Star washer •... -
Page 8: Mechanical Installation
• The solar modules from LG Electronics can not be operated in a location where they could come in direct • Clearance between the solar module frames and contact with salt water or ammonia. - Page 9 Nut. • The solar module may be mounted by using the Module frame following methods: (*Torque:8~12N∙m) • LG modules (Fire performance : Type 1 or 2) shall be Spring washer Flat washer with UL1703 edition 2014 and UL2703 edition 2014.
-
Page 10: Disclaimer Of Liability / Disposal
Disposal • Please contact us, if you have any queries related to the disposal or recycling of solar modules from LG Electronics. INSTALLATION AND ASSEMBLY INSTRUCTIONS • The fire rating of this module is valid only when mounted in the manner specified in the mechanical mounting instructions. -
Page 11: Product Specifications
PRODUCT SPECIFICATIONS N-TYPE Rated electrical characteristic except power rating within -0/+3 percent are within 5 percent of measured. o i t , Cell temp. 25℃, 1.5AM Electrical Properties Mechanical Properties Max. Max. Max. Module Pmax Power Voc at Isc at Vmpp Impp at No. -
Page 12: Dimensions Of Modules
Dimensions of Modules Unit: mm / in. 72Cell Module... -
Page 13: Appendix
Front : 3600Pa Front : 5400Pa C : 120mm 6point(①+②) 1 ± Rear : 1600Pa Rear : 3000Pa All mechanical installation methods(Fig.1 to Fig.7) and bolting method in this appendix were not tested by VDE. It is evaluated by LG internal test. - Page 14 • Follow the clamp manufacturer’s recommended applied torque to fasten the clamps. • Width Height Depth <Edge Clamp> a l l o i t . g i n i t (UL 1703, ULC 1703) It is evaluated by LG internal test.
-
Page 15: Bolting & Clamp Information
These alternative grounding devices indicated on this page has been evaluated and approved by LG, not by Intertek. If such devices want to be used to meet the requirement in UL1703, some adequate tests shall be conducted in accordance with UL1703 additionally. -
Page 16: Unloading Flow Guide
Unloading Flow Guide If you are unloading using heavy equipment such as a crane, please follow the procedure below. [ Step 1 ] [ Step 2 ] [ Step 3 ] [ Step 4 ] Step 1. Place the packaging on a flat surface. Step 2. - Page 17 2000 Millbrook Dr., Lincolnshire, IL 60069 Contact : lg.solar@lge.com http://www.lgsolarusa.com This document is subject to change without notice. LG, LG logo and Life's Good are trademarks of LG Electronics, Inc. worldwide. Trademarks and intellectual properties of LG Electronics, Inc. are protected by international copyright laws.
