- Page 1 Installation manual PV Solar MODULE Please read this manual carefully before operating your set and retain it for future reference. N-TYPE MODELS P-TYPE MODELS LGXXXN1C(W,K)-A5 LGXXXS1C(W)-A5 LGXXXN2C(W,K)-A5 LGXXXS2W-A5 www.lgsolarusa.com MFL69654302 (Rev 01)
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY ..............03 BEFORE & AFTER INSTALLATION ......05 Before Installation ................05 After Installation ...................05 ELECTRICAL INSTALLATION .......06 Danger ....................06 Electrical Connections .................06 Diodes ....................06 Series Connection ................06 Parallel Connection ................07 General Wiring..................07 Earth Grounding ..................07 MECHANICAL INSTALLATION ......08 Module Mounting .................08 Site Consideration ................08 Mounting Methods ................08... -
Page 3: Safety
SafETY The instructions related to safety and use indicated No electrical parts like cables are in the this installation manual are intended for the located after installation between prevention of unexpected danger, damage, or failure. laminate and mounting structure. DaNgEr WarNINg CaUTION Non-compliance with the instructions may cause product... - Page 4 Do not touch the glass surface or Module frame of the solar module after Module Installing structure installation of the module. It may (Stralght type) Installing structure (bent type) result in injury or death. Heavy objects must be kept off of the solar module.
-
Page 5: Before & After Installation
bEfOrE & afTEr INSTaLLaTION before Installation after Installation Please carefully read this manual before installation. • Plug in the connector tightly and ensure that the wiring properly works. • Solar module installation and maintenance must be performed by qualified and authorized installer. •... -
Page 6: Electrical Installation
ELECTrICaL INSTaLLaTION Danger Diodes • Avoid all electrical hazards when installing, wiring, • All LG modules are equipped with factory installed operating and maintaining all panels. bypass diodes. The factory-installed diodes provide proper circuit protection for the systems within the •... -
Page 7: Parallel Connection
Installations, Canadian Electrical Code, Part 1. Module frame General Wiring Bolt • LG Electronics recommends that all wiring be double Flat washer insulated with a minimum rating of 90°C (194°F). Star washer •... -
Page 8: Mechanical Installation
Excluded Operating Environments cause a safety hazard. • The solar modules from LG Electronics can not be • Clearance between the solar module frames and operated in a location where they could come in direct structures such as roofs or ground is required to contact with salt water or ammonia. - Page 9 Nut. • The solar module may be mounted by using the Module frame following methods: (*Torque:8~12N∙m) • LG modules (Fire performance : Type 1) shall be Spring washer Flat washer with UL1703 edition 2014 and UL2703 edition 2014. • It is recommended to check with local authorities...
-
Page 10: Disclaimer Of Liability / Disposal
Disposal • Please contact us, if you have any queries related to the disposal or recycling of solar modules from LG Electronics. TRANSPORTING AND STORAGE • Do not loosen the banding, when the module is transported by truck, ship and etc. -
Page 11: Product Specifications
PRODUCT SPECIFICATIONS P-TYPE Rated electrical characteristic except power rating within -0/+3 percent are within 5 percent of measured. Values at Standard Test Condition(STC) : Irradiance 1000W/m , Cell temp. 25 ℃ , 1.5AM Electrical Properties Mechanical Properties Max. Max. Module Pmax Power Voc at... - Page 12 N-TYPE Rated electrical characteristic except power rating within -0/+3 percent are within 5 percent of measured. Values at Standard Test Condition(STC) : Irradiance 1000W/m , Cell temp. 25 ℃ , 1.5AM Electrical Properties Mechanical Properties Max. Max. Module Pmax Power Voc at Isc at Vmpp...
-
Page 13: Dimensions Of Modules
Dimensions of Modules Unit: mm / in. 60Cell Module 72Cell Module... -
Page 14: Appendix
Front : 3200Pa(67psf) Front : 6000Pa(125psf) C : 120mm(4.7 in) 1 ± 6point(①+②) Rear : 1800Pa(37.5psf) Rear : 5400Pa(113psf) (33.2±3.9 in) a l l o i t . g i Intertek. (UL 1703, ULC 1703) It is evaluated by LG internal test. - Page 15 C : 120mm(4.7in) 1 ± 6point(①+②) Rear : 1600Pa(33psf) Rear : 4300Pa(90psf) (39.8±3.9 in) All mechanical installation method(Fig.1 to Fig.7) and bolting method in this appendix were not tested by Intertek. (UL 1703, ULC 1703) It is evaluated by LG internal test.
- Page 16 • Four M8(5/16inch) stainless steel bolts, four nuts, four spring washers, and eight flat washers are recommended per solar module. Note) All mechanical installation method(Fig.1 to Fig.7) and bolting method in this appendix were not tested by Intertek. (UL 1703, ULC 1703) It is evaluated by LG internal test.
- Page 17 These alternative grounding devices indicated on this page has been evaluated and approved by LG, not by Intertek. If such devices want to be used to meet the requirement in UL1703, some adequate tests shall be conducted in accordance with UL1703 additionally.
- Page 18 1000 Sylvan Ave, Englewood Cliffs, NJ 07632 Contact : lg.solar@lge.com http://www.lgsolarusa.com This document is subject to change without notice. LG, LG logo and Life's Good are trademarks of LG Electronics, Inc. worldwide. Trademarks and intellectual properties of LG Electronics, Inc. are protected by international copyright laws.
