FCC Information

EN
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
In accordance with FCC requirements, changes or modifications not expressly approved by Thomson multimedia Inc.
could void the user's authority to operate this product.
This device generates and uses radio frequency (RF) energy, and if not installed and used properly, this equipment
may cause interference to radio and television reception.
If this equipment does cause interference to radio or television reception (which you can determine by unplugging
the unit), try to correct the interference by one or more of the following measures:
• Re-orient the receiving antenna (that is, the antenna for the radio or television that is "receiving" the
interference).
• Move the unit away from the equipment that is receiving interference.
• Plug the unit into a different wall outlet so that the unit and the equipment receiving interference are on
different branch circuits.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television
technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet,
"How To Identify and Resolve Radio TV Interference Problems." This booklet is available from the U.S. Government
Printing Office, Washington, DC 20402. Please specify stock number 004-000-00345-4 when ordering copies.
This product complies with DHHS Rules 21 CFR Subchapter J. Applicable at the date of manufacture.

For Your Safety

The AC power plug is polarized (one blade is wider than the other) and only fits into AC power
outlets one way. If the plug won't go into the outlet completely, turn the plug over and try to insert
it the other way. If it still won't fit, contact a qualified electrician to change the outlet, or use a
different one. Do not attempt to bypass this safety feature.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.

For Your Records

In the event that service should be required, you may need both the model number and the serial number. In the space
below, record the date and place of purchase, and the serial number:
Model No. RP8070
Remote Control No.
Date of Purchase
Place of Purchase
Serial No.
Service Information
This product should be serviced only by those specially trained in appropriate servicing techniques. For instructions on
how to obtain service, refer to the warranty included in this Guide
RP8070 IB rev3
WARNING : TO PREVENT
FIRE OR ELECTRICAL
SHOCK HAZARD, DO NOT
EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THE LIGHTNING FLASH
CAUTION: TO REDUCE THE RISK OF
THE EXCLAMATION POINT
AND ARROW HEAD WITHIN
ELECTRIC SHOCK, DO NOT REMOVE
WITHIN THE TRIANGLE IS A
T H E T R I A N G L E I S A
C O V E R
( O R
B A C K ) .
N O
U S E R
WARNING SIGN ALERTING
WARNING SIGN ALERTING
SERVICEABLE PARTS INSIDE. REFER
Y O U
O F
I M P O R T A N T
YOU OF "DANGEROUS
SERVICING TO QUALIFIED SERVICE
I N S T R U C T I O N S
VOLTAGE" INSIDE THE
PERSONNEL.
A C C O M P A N Y I N G
PRODUCT.
PRODUCT.
SEE MARKING ON BOTTOM/BACK OF PRODUCT
8/14/01, 4:57 PM
T H E
