Extend Your Wired Network By Plug & Play - TP-Link PG2400P User Manual

Chapter 2
2 2 Extend Your Wired Network by Plug & Play
I want to:
Use two powerline adapters to set up a new powerline network in my house.
For example, I have a router in my house, but there are not enough LAN ports for all my
wired devices. I don't want complex and expensive cabling. People told me that I can
solve this problem with two powerline adapters.
Note: G.hn powerline devices are not compatible with Homeplug AV/AV2 powerline
devices.
How can I do that?
1 Connect one of the powerline adapters to an available LAN port of the router using
an Ethernet cable.
2 Plug the powerline adapter into a wall outlet.
3 Plug the other powerline adapter into a wall outlet on the same electrical circuit at
the place you want internet. Wait until the powerline LED
Note: If the Powerline LED does not turn solid green, refer to
4 Connect your wired device, such as a computer or game console, to the powerline
adapter via an Ethernet cable.
Router
l C
i c a
c t r
E l e
m e
S a
2
Adapter
PG2400P
1
N
L A
N
W A
Use Your Powerline Adapter
turns solid green.
FAQ-Q2 for instructions.
c t r
E l e
m e
S a
u i t
i r c
Adapter
3
PG2400P
u i t
i r c
l C
i c a
