Summary of Contents for Lutz-Jesco EASYCON GW
- Page 1 Gas warning device EASYCON GW Operating instructions Read the operating manual! The user is responsible for installation and operation related mistakes! Dosing Original operating instructions BA-40900-02-V05 Liquids Conveying Gases © Lutz-Jesco GmbH 2023 Control Systems...
-
Page 3: Table Of Contents
Gas warning device EASYCON GW Operating instructions Table of Contents 1 Notes for the Reader ............4 10 Maintenance ..............25 1.1 General non-discrimination ............10.1 Maintenance intervals ............1.2 Explanation of the signal words ..........10.2 Renewing the sensor ............1.3 Explanation of the warning signs .......... -
Page 4: Notes For The Reader
Gas warning device EASYCON GW Operating instructions 1 Notes for the Reader 1.3 Explanation of the warning signs This operating manual contains information and behaviour rules for the safe and designated operation of the device. Warning signs represent the type and source of a danger:... -
Page 5: Safety
Gas warning device EASYCON GW Operating instructions 2 Safety 2.1 General warnings 2.2 Hazards due to non-compliance with the safety instructions The following warnings are intended to help you eliminate the dangers Failure to follow the safety instructions may endanger not only persons, that can arise while handling the device. - Page 6 Gas warning device EASYCON GW Operating instructions They are specially trained for their specific working environment and are familiar with relevant standards and provisions. They must comply with the legally binding regulations on accident pre- vention. 2.4.3 Trained persons Trained persons have received training from the operator about the tasks they are to perform and about the dangers stemming from improper be- haviour.
-
Page 7: Intended Use
Gas warning device EASYCON GW Operating instructions 3 Intended use 3.3.3 Incorrect operation 3.1 Notes on product warranty Protective equipment not functioning correctly or dismantled Any non-designated use of the device can impair its function and the pro- Unauthorised modification of the gas warning unit tection provided. -
Page 8: Product Description
Gas warning device EASYCON GW Operating instructions 4 Product description 4.1 Scope of delivery Please compare the delivery note with the scope of delivery. The follow- ing items are part of the scope of delivery: Gas warning device Up to 4 sensors... -
Page 9: Rating Plate
Part number Tab. 5: Position numbers main view with two sensors Month/year of manufacture Tab. 6: Position numbers rating plate EASYCON GW 4.2.3 Functions of the device The stationary device monitors the surrounding air using sensors which can detect various gases such as chlorine-gas, chlorine dioxide or ozone. -
Page 10: Technical Data
Battery CR1220, Ø12,5 mm, 3 V, 35 mAh Ambient temperature °C -5 to +45 Air humidity max. 95, non condensing Tab. 7: Technical data EASYCON GW 5.2 Sensors Value Specification and Unit Chlorine (Cl Chlorine dioxide (ClO Ozone (O Measuring range 0 –... -
Page 11: Dimensions
Gas warning device EASYCON GW Operating instructions 6 Dimensions All dimensions in mm 6.1 Outside dimensions Fig. 4: Outside dimensions 6.2 Drillhole dimensions Fig. 5: Drillhole dimensions Dimensions © Lutz-Jesco GmbH 2023 BA-40900-02-V05 Subject to technical changes. 230711... -
Page 12: Installation
Gas warning device EASYCON GW Operating instructions 7 Installation 7.3 Electrical installation DANGER The voltage supply to your device can now be performed via a normal Mortal danger from electric shock! Schuko plug or a control cabinet. Perform the specifications of this sec- tion for devices without a pre-fitted Schuko plug. -
Page 13: Terminal Connection
Gas warning device EASYCON GW Operating instructions 7.4 Terminal connection Input 1 Output 1 Input 2 Output 2 Input 3 Input 4 Output 3 0/4 – 20 mA Output 4 2 3 4 5 6 7 10 11121314151617181920 Ethernet Digital inputs... -
Page 14: Connecting The Sensor
These sensors are connected to the current module and supplied with 24 Electronic distortion of the measurement results. A maximum of 2 current modules can be used per EASYCON GW gas Incorrect installation of the electrical cables can distort the measure- warning device. -
Page 15: Connecting The Signal Technology
Gas warning device EASYCON GW Operating instructions 3. Connect the signal technology used either to clamps 41 and 42 (nor- Terminal Function mal closed) or 42 and 43 (normal opened). Note: You can adjust the action of the bugle relay in the output set- tings. - Page 16 BA CM Ausgangsmodul 2 Optokoppler 79832_1 Gas warning device EASYCON GW Operating instructions 4. Connect the signal device for the pre-alarm to the clamps 3 + 4. Jumper Function Clamps Connection of the relay output circuit board completed. ü Relay outputs...
-
Page 17: Digital Inputs
Gas warning device EASYCON GW Operating instructions 7.8 RC protection for relay PLEASE NOTE When connecting to the relay, note that inductive loads must be sup- Damage to the device! pressed. If this is not possible, the relay contact on the device terminal must be protected by an RC protective circuit / interference suppression element. - Page 18 Gas warning device EASYCON GW Operating instructions Installing a wired network During installation, comply with the following points: The Ethernet is cabled in a star topology. The maximum cable length is 100 m. You must route separately as a bundle the different categories of ca- bles (e.g.
-
Page 19: Commissioning
Gas warning device EASYCON GW Operating instructions 8 Commissioning 8.2.1 Input side 8.1 First steps You can connect up to four sensors for various gases and the tempera- You need to make a number of basic settings before operating the device. - Page 20 Gas warning device EASYCON GW Operating instructions 8.2.1.3 Digital 3. Action: Choose between “normal opened” (N.O., make contact) or “normal closed” (N.C., break contact). 4. Latching: On = The alarm is active, until it is manually confirmed. OFF You can use up to 8 digital inputs to evaluate switching statuses and to...
-
Page 21: Password Protection
Gas warning device EASYCON GW Operating instructions 7. Testsignal: You can test the configuration of the analogue outputs. Perform the following steps: Read the value displayed on the external device. 1. In Menu 2, navigate to the “Configuration” tab under Settings. - Page 22 Gas warning device EASYCON GW Operating instructions 3. IP address: Give the device an IP address over which it can be reached in the network. 4. Subnetmask Enter the subnetmask. 5. Gateway: Enter the gateway. 6. DNS server: Enter the DNS server.
-
Page 23: Operation
Gas warning device EASYCON GW Operating instructions 9 Operation 9.2.1 Display the files When in operation, the device will display the main view with the current values and the status row with status messages. You can display the logbook files on the device. -
Page 24: Viewing The Trend Display
Gas warning device EASYCON GW Operating instructions 9.3 Viewing the trend display You can view the trend progression of up to four measured values in the last 24 hours. Perform the following work steps: 1. In Menu 1, press “Trend”. -
Page 25: Maintenance Intervals
Gas warning device EASYCON GW Operating instructions 10 Maintenance 10.2 Renewing the sensor DANGER Precondition for action: Mortal danger from electric shock! ü The voltage supply has been disconnected. An the housing of the device is open, you are risk of getting an electric ü... -
Page 26: Keeping Logfiles
You can find the current firmware version on our homepage 10.5.2 Replace the battery www.Lutz-Jesco.com. Copy this *.BIN file onto the USB flash drive of the gas warning device. The file must be saved in the You must remove the two input circuit boards to be able to replace the root directory of the USB flashdrive and may not be stored in a battery (see Fig. -
Page 27: Replacing The Fuse
Gas warning device EASYCON GW Operating instructions 10.6 Replacing the fuse 3. Confirm with “Yes”. The configuration will be deleted. You must proceed with the follow- ing section. Your device is fitted with an electrical fuse to protect against short circuits or over-voltage. - Page 28 Gas warning device EASYCON GW Operating instructions 11 Troubleshooting See below for information about how to rectify faults on the device or the system. If you cannot eliminate the fault, please consult with the manufacturer on further measures or return the device for repair.
- Page 29 Gas warning device EASYCON GW Operating instructions 12 Modbus addresses With a DOUBLE-WORD, the HIGH-WORD is transferred first! Hexadecimal display is shown by a leading “0x”. Address Description Meaning Data that are not channel-related. 0x0550 + (number of channels -1)
- Page 30 Gas warning device EASYCON GW Operating instructions Address Description Meaning 2024 Temperature value One position after the decimal point (215 => 21.5) 0 = °C 2025 Temperature unit 1 = °F 2026 Limit value 1 (HIGH-WORD) Two positions after decimal point (215 => 2.15)
- Page 31 Gas warning device EASYCON GW Operating instructions 13 EU Declaration of Conformity (DE) EU-Konformitätserklärung Hiermit erklären wir, dass das nachfolgend bezeichnete Gerät aufgrund seiner Konzipierung und Bauart sowie in der von uns in Verkehr gebrachten Ausführung den einschlägigen grundlegenden Sicherheits- und Gesundheitsanforderungen der aufgeführten EU-Richtlinien entspricht. Bei einer nicht mit uns abgestimmten Änderung am Gerät verliert diese Erklärung ihre Gültigkeit.
- Page 32 Gas warning device EASYCON GW Operating instructions 14 Index Battery ....................26 Network Ethernet ..................17 Modbus addresses ..............29 Network settings ................21 Commissioning ................19 Notes for the Reader ................4 Configuration ...................19 Operation ..................23 Design ....................8 Optocoupler ..................16 Dimensioned drawings ..............11 Dimensions ..................11 Drillhole dimensions ..............11...
- Page 36 Lutz-Jesco GmbH Am Bostelberge 19 D-30900 Wedemark Phone: +49 5130 5802-0 info@lutz-jesco.com www.lutz-jesco.com Operating instructions Gas warning device EASYCON GW...
