Ecovac cylinder vacuum cleaners
Please read and keep these instructions
getting the best from your
new cleaner...
If your cleaner is not picking up as well as it
should, please check
• Filters
It is important that the filter is cleaned regularly to allow air through
the appliance. Shake to remove dust, the filter can also be washed
in warm water and left to air dry.
IMPORTANT - Ensure filter is totally dry before refitting into
machine.
• Blockages
Check the hose, handle and tools for blockages.
• Overheating protection
The cleaner automatically cuts off in the event of overheating
caused by blocked hoses / filters. Remove plug, clear blockage
and allow 15 minutes for the cleaner to automatically reset.
www.morphyrichards.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ecovac 70096 and is the answer not in the manual?

Questions and answers

Related Manuals for Morphy Richards Ecovac 70096

Summary of Contents for Morphy Richards Ecovac 70096

  • Page 1 Ecovac cylinder vacuum cleaners Please read and keep these instructions getting the best from your new cleaner... If your cleaner is not picking up as well as it should, please check • Filters It is important that the filter is cleaned regularly to allow air through the appliance.

  • Page 2: Important Safety Instructions

    Unprofessional repairs can be socket outlet. dangerous for users. • Use only genuine Morphy Richards Should the fuse in the 13 amp plug spare parts and accessories. require changing a 13 amp BS1362 fuse...
  • Page 3 „ On/off foot switch Features ‰ Cable rewind foot switch  Reusable exhaust filter ⁄ Dust compartment cover Ê Carrying handle ¤ Opening for suction hose Á Tube park (not illustrated) ‹ Dust compartment lock button › Tool storage compartment cover Accessories you should have fi...

  • Page 4: Tools And Accessories

    Tools and accessories Accessories used Application Curtains and delicate fabrics Textiles and upholstery Carpets and other textile floor coverings Button position on floor brush Power settings for heavy dirt and smooth floors Operation Button position on Suction hose floor brush Snap the 360°...
  • Page 5 Switching on Pull out the supply cable to its maximum length and plug the appliance into the mains supply. Push the on/off foot switch to start the motor. Controlling suction power The suction power can be varied to suit the surface being cleaned, by using the electronic suction power regulator.
  • Page 6 Switching off Switch off the appliance. Remove the plug from the mains supply and rewind the power cable using the cable rewind foot switch. CAUTION: When using the cable rewind, always hold the plug as the cable will rewind quickly. Emptying the air box To maintain the performance of your vacuum cleaner the airbox must be emptied regularly...
  • Page 7 Cleaning the airbox filter IT IS IMPORTANT TO CLEAN THE FILTER TO MAINTAIN PERFORMANCE, EVERY TIME THE AIRBOX IS EMPTIED. • After emptying the dust, twist the filter anti- clockwise to remove as shown. • Tap the filter over a dustbin to remove excess dust.

  • Page 8: Cleaning The Motor Protection Filter

    Cleaning the motor protection filter The motor protection filter is accessible from the dust compartment only when the airbox has been removed first. WARNING: NEVER USE THE APPLIANCE WITHOUT THE MOTOR PROTECTION FILTER INSTALLED, OTHERWISE DAMAGE TO THE MOTOR MAY OCCUR WHICH WOULD NOT BE COVERED BY THE GUARANTEE.

  • Page 9: Cleaning The Exhaust Air Filter

    Cleaning the exhaust air filter The exhaust air filter cleans the air before it exits the vacuum cleaner. Recommendation The exhaust air filter should be cleaned when you have emptied the airbox 5 times. Exhaust filter 1 The exhaust filter is located between the hinged section of the dust compartment cover.

  • Page 10: Cleaning And Maintenance

    Cleaning and Helpline maintenance If you have any difficulty with your appliance do not hesitate to call us. We Unplug from the mains before cleaning. are likely to be more help than the The dust compartment and all accessories store from where it was bought. can be cleaned using a damp cloth or a non- Please have the following information abrasive domestic cleaner and wiped dry.
  • Page 11 Helpline number quoting products. Model number and Serial number on the 3 Repairs have been attempted by persons product, or write to Morphy Richards at the other than our service staff (or authorised address shown. You will be asked to return dealer).
