Advanced Airport Lighting System
Elevated Runway Edge Light (Type II)
EBL-RE-Ⅱ (PBL-620)
Operation Manual
Please read this manual carefully before construction, installation and operation of the product.
Please keep this manual properly for further reference.
This manual is subject to change without prior notice.
Airsafe Airport Equipment Co., Ltd.
Advertisement
Table of Contents
Related Manuals for Airsafe EBL-RE-II
Summary of Contents for Airsafe EBL-RE-II
- Page 1 Elevated Runway Edge Light (Type II) EBL-RE-Ⅱ (PBL-620) Operation Manual Please read this manual carefully before construction, installation and operation of the product. Please keep this manual properly for further reference. This manual is subject to change without prior notice. Airsafe Airport Equipment Co., Ltd.
- Page 2 Advanced Airport Lighting System Revision Description Version Revised Approved Description Date First release V1.0 C.SY W.GL Nov. 20, 2008 Design changed V2.0 C.SY Aug. 2, 2016...
-
Page 3: Table Of Contents
Advanced Airport Lighting System Table of Content 1.0 Foreword ................................1 1.1 Illustrations and Meanings ........................... 1 1.2 Safety Rules and Notices ..........................2 1.3 Quality Assurance and Responsibility ......................3 2.0 Introduction ................................4 2.1 Technical Specifications ..........................5 2.2 Application Environment ..........................5 2.3 Application Scope ............................ -
Page 4: Foreword
Advanced Airport Lighting System 1.0 Foreword ICAO Airport Service Manual Part 9 “Airport Maintenance Practices” and FAA AC150/5345-26 Maintenance of Airport Visual Aid Facilities are the highest criterions for site installation and maintenance of such lighting fixtures. This manual was compiled with considerable reference to these two criterions. -
Page 5: Safety Rules And Notices
Advanced Airport Lighting System 1.2 Safety Rules and Notices Using the light fixtures outside of airport is strictly prohibited. ※ Inadequate maintenance or casual touch will cause light faults. Using power supply other than CCR is strictly prohibited. ※... -
Page 6: Quality Assurance And Responsibility
Advanced Airport Lighting System 1.3 Quality Assurance and Responsibility Any defect in design, material or workmanship, which may occur during proper and normal use over a period of one year from date of installation but less than 15 months from date of shipment, or within the warranty period of the tender, will be repaired or preplaced by manufacturer free of charge. -
Page 7: Introduction
Advanced Airport Lighting System 2.0 Introduction This manual involves the following series lighting fixtures: EBL-RE-II-------------------------------Elevated Runway Edge Light Type of Elevated Runway Edge Light (EBL-RE-II): Type EBL-RE -II= Elevated runway edge light Power Beam color Window 2 Window 1 Window 1... -
Page 8: Technical Specifications
Using the lighting fixtures beyond the specified scope is strictly prohibited. ※ Application beyond the specified scope will cause damage or risk to any component. 2.4 Technical Parameters Description Type Rated Power Life of Light Source at 6.6A ≥1,500h Runway edge light EBL-RE-II-150-XX 150W... -
Page 9: Technical Features
Advanced Airport Lighting System 2.5 Technical Features ○ Optical cover made of the high borosilicate glass makes good optical performance and heat resistance; ○ The filter employs advanced coating technology, with high light transmittance, firm coating and good thermostability; ○ International standard PK30D preset focus lamp has accurate positioning and high light distribution accuracy;... -
Page 10: Structure
Advanced Airport Lighting System 2.6 Structure 1. Optical cover 2. Color filter lens 3. Optical cover 4. Optical cover gasket 5. Optical cover holder 6. Lamp 7. Hinge 8. Body gasket 9. Fixed base of terminal 10. Light body 11. Waterproof Gland 12. -
Page 11: Installation
Advanced Airport Lighting System 3.0 Installation Requirements for installation should be learned thoroughly before installation including installation tools and site requirement, etc., to avoid malfunction of the light due to incorrect installation. 3.1 Installation Methods ○ Mounted on L- 867 deep base (Figure 3-1). ○... -
Page 12: Installation Tools
Advanced Airport Lighting System 3.2 Installation Tools Choosing right tools not only can ensure the correct and reliable installation of the lighting fixtures, but also can reduce unnecessary safety accidents. Special Tools listed in the table may be purchased from the manufacturer or any distributor. Universal tools are available on local hardware market. -
Page 13: Direction Installation Of Flange
Advanced Airport Lighting System 3.4 Direction Installation of Flange ○ Install the flange onto the base, with its dimension shown in Figure above; ○ After the flange is installed (see Figure 3-4), connect the secondary cable according to the construction requirements and screw the frangible pole of the lighting fixture into the threaded hole of its chassis (see Figure 3-5). -
Page 14: Operation And Control
Advanced Airport Lighting System 4.0 Operation and Control The lighting fixtures are applicable to CCR power supply 6.6A circuit special for airports, which forms a secondary circuit with the lighting fixtures through secondary outgoing line of isolation transformer connected on primary circuit. Due to the use of isolation transformer, the damage of lamp of single lighting fixture will not affect whole series circuit. -
Page 15: Replacement Of Components Of Lighting Fixtures
Advanced Airport Lighting System 5.0 Replacement of Components of Lighting Fixtures When any damage or failure occurs to any consumable or other component of the lighting fixtures, it is required to timely dismantle the lighting fixtures for replacement of the component. Replacement of components needs to dismount the lighting fixtures, so any minor error will cause adverse consequences. -
Page 16: How To Replace Optical Cover
Advanced Airport Lighting System 5.1 How to Replace Optical Cover ○ Unscrew the M4×10 screws with a cross screwdriver to remove the pressing bracket and take out the outer cover (see Figure 5-1). ○ Loosen the steel wire fixing the inner cover to take out the inner cover (see Figure 5-2). ○... -
Page 17: How To Replace Lamp
Advanced Airport Lighting System 5.2 How to Replace Lamp ○ Open the hinge in the direction indicated by the arrow, remove the optical cover holder and pull the lamp pin out of the ceramic wire holder (Figure 5-4). ○ Push the lamp in the arrow direction to make it leave the neck on the other end, overturn it downwards and take it down (see Figure 5-5). -
Page 18: How To Replace Frangible Pole
Advanced Airport Lighting System 5.3 How to Replace Frangible Pole ○ Separate the lighting fixture from the base with a nut wrench of the elevated light, pull out the lighting fixture and separate the secondary connector (see Figure 5-7). ○ Unscrew the set screw on the light body with a socket head wrench and pull out the frangible pole (see Figure 5-8). -
Page 19: Maintenance Of Lighting Fixtures
Advanced Airport Lighting System 6.0 Maintenance of Lighting Fixtures Suggestions for daily maintenance provided in this section are only for reference. Airports may formulate their own daily maintenance guidelines with reference to other provisions or maintenance experience of airport staff; the manufacturer does not provide any hard-and-fast rules. Maintenance of the lighting fixtures for airports shall be conducted by professionals as stated in 1.0 Foreword. -
Page 20: Regular Spot Check And Troubleshooting
Advanced Airport Lighting System 6.2 Regular Spot Check and Troubleshooting Serial No. Failure Phenomenon Possible Reasons Countermeasures Replace LED lamp assy or LED aging or other LED lamp assy failure send lighting fixtures back to unknown failure factory for repair. The lighting fixtures is There are some stains on Clean up stains on optical... -
Page 21: List Of Components And Ordering Of Spare Articles And Accessories
Advanced Airport Lighting System 7.0 List of Components and Ordering of Spare Articles and Accessories The table in this chapter lists the components, spare articles and accessories of this product and relevant ordering information. Spare articles and accessories of this product needs to be ordered additionally, and the manufacturer accepts the order in assembly mode and separate order of components. - Page 22 Advanced Airport Lighting System Please order the inner and outer covers from us if they are damaged. ※ They impact the luminous angle and light intensity of the lighting fixtures. If secondary plug is damaged, please order it from our company. ※...
-
Page 23: Packaging, Transportation And Storage
Advanced Airport Lighting System 8.0 Packaging, Transportation and Storage 8.1 Packaging and Weight Packaging: 4 pcs / box Gross weight: 8.75 KG / box Volume: 350*285*365 mm 8.2 Transportation Mode Well packed products may be transported in three modes- railway, highway and air according to factors such as transportation distance, quantity of lights and delivery cycle. - Page 24 Advanced Airport Lighting System The final right to interpret this manual is reserved by Airsafe Airport Equipment Co., Ltd. Thanks for your purchasing and using AIRSAFE product! Address: No. 38, Anxin Road, Xuhang Town, Jiading District, Shanghai, China Postal Code: 201800 Tel.: 021-53540453...
