Advanced Airport Lighting System
12 Inches LED In-pavement Runway Lighting Fixtures (6mm)-
Uni-directional Passageway
In-pavement Approach Centerline Light and Cross Bar Light, In-pavement Approach
Side-row Light and In-pavement Runway Threshold Wing Bar Light
APPS-12-LED, APSS-12-LED and THWS-12-LED
Operation Manual
Please read this manual carefully before construction, installation and operation of the product.
Please keep this manual properly for further reference.
This manual is subject to change without prior notice.
Airsafe Airport Equipment Co., Ltd.
Advertisement
Table of Contents
Related Manuals for Airsafe APPS-12-LED
Summary of Contents for Airsafe APPS-12-LED
- Page 1 Uni-directional Passageway In-pavement Approach Centerline Light and Cross Bar Light, In-pavement Approach Side-row Light and In-pavement Runway Threshold Wing Bar Light APPS-12-LED, APSS-12-LED and THWS-12-LED Operation Manual Please read this manual carefully before construction, installation and operation of the product.
- Page 2 Advanced Airport Lighting System Revision Description Version Revised Approved Description Date First release V1.0 Y.MZ C.SY Aug. 10, 2016...
-
Page 3: Table Of Contents
Advanced Airport Lighting System Table of Content 1.0 Foreword ............................1 1.1 Illustrations and Meanings ..................... 2 1.2 Safety Rules and Notices ....................... 3 1.3 Quality Assurance and Responsibility ................... 4 2.0 Introduction ............................ 5 2.1 Technical Specifications ......................7 2.2 Application Environment ....................... -
Page 4: Foreword
Advanced Airport Lighting System 1.0 Foreword ICAO Airport Service Manual Part 9 “Airport Maintenance Practices” and FAA AC150/5345-26 Maintenance of Airport Visual Aid Facilities are the highest criterions for site installation and maintenance of such lighting fixtures. This manual was compiled with considerable reference to these two criterions. -
Page 5: Illustrations And Meanings
Advanced Airport Lighting System 1.1 Illustrations and Meanings ○ Following illustrations will appear in this manual where necessary to remind or warn construction or maintenance personnel. ○ Please continue reading the subsequent content of this manual after properly understanding the meanings of these illustrations. -
Page 6: Safety Rules And Notices
Advanced Airport Lighting System 1.2 Safety Rules and Notices Using the light fixtures outside of airport is strictly prohibited. ※ Inadequate maintenance or casual touch will cause light faults. Using power supply other than CCR is strictly prohibited. ※... -
Page 7: Quality Assurance And Responsibility
Advanced Airport Lighting System 1.3 Quality Assurance and Responsibility Any defect in design, material or workmanship, which may occur during proper and normal use over a period of one year from date of installation but less than 15 months from date of shipment, or within the warranty period of the tender, will be repaired or preplaced by manufacturer free of charge. -
Page 8: Introduction
APPS-12-LED---------------------------- In-pavement Approach Centerline Light and Cross Bar Light APSS-12-LED---------------------------- In-pavement Approach Side-row Light THWS-12-LED--------------------------- In-pavement Runway Threshold Wing Bar Light Type of In-pavement Approach Centerline Light and Cross Bar Light (APPS-12-LED): Type APPS-12= 12 inches 6mm in-pavement approach centerline light... - Page 9 Advanced Airport Lighting System Type APSS-12=12 inches 6mm in-pavement approach side-row light Beam direction Runway top L= left toe-in R= right Left toe-in Right toe-in toe-in Light source LED= LED lamp Beam color R=Red Optional function M= single lamp fault detection function Type of In-pavement Runway Threshold Wing Bar Light (THWS-12-LED): Type THWS-12=12 inches 6mm in-pavement...
-
Page 10: Technical Specifications
Advanced Airport Lighting System 2.1 Technical Specifications This product conforms to the provisions of the following standards or technical specifications. For dated standards or technical specifications, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. ... -
Page 11: Application Scope
Advanced Airport Lighting System 2.3 Application Scope In-pavement approach centerline light and cross bar light, in-pavement approach side-row light and in-pavement runway threshold wing bar light for Categories I, II and III airports. Using the lighting fixtures beyond the specified scope is strictly prohibited. ※... -
Page 12: Technical Features
Advanced Airport Lighting System 2.5 Technical Features ○ Long life, energy saving, maintenance free and other characteristics of LED will bring huge economic benefits to customers; ○ Proprietary prism structure and manufacturing process, making the optical efficiency excellent; ○ Strict LED color management ensures the consistency of light color; ○... - Page 13 Advanced Airport Lighting System ○ High precision components machining ensures dimensional quality and precision of the lighting fixtures. ○ The overall IP rating of the lighting fixtures reaches IP68, which may bear 138KPa internal pressure or water pressure formed by impact of the aircraft on the window; ○...
-
Page 14: Structure
Advanced Airport Lighting System 2.6 Structure 1. Upper cover 2. Prism gasket sleeve 3. Prism 4. LED lamp assy 5. Prism gasket 6. Prism pressing bracket 7. Light body gasket 8. Inner cover assy 9. Temperature control switch... -
Page 15: Fault Detection Or Lamp Bypass Functions
Advanced Airport Lighting System 2.7 Fault Detection or Lamp Bypass Functions This product complies with the requirements of FAA EB67 and GB/T 7256, and integrates single lamp fault detection function; Or, it can provide the option of lamp bypass function in accordance with the requirements of FAA AC150-5345/46. -
Page 16: Installation
Advanced Airport Lighting System 3.0 Installation Requirements for installation should be learned thoroughly before installation including installation tools and site requirement, etc., to avoid malfunction of the light due to incorrect installation 3.1 Installation Dimension ○ Directly mounted on the 12 inches deep base (Figure 3-1). ○... -
Page 17: Identification Of Different Types Of Lighting Fixtures
Advanced Airport Lighting System 3.2 Identification of Different Types of Lighting Fixtures ○ The model of each lighting fixture is attached to its bottom. ○ The colorful dot identification mark is attached to the light outlet of each lighting fixture, respectively meaning the luminous color and direction of the window where the colorful dot is located. -
Page 18: Screw And Torsion
Advanced Airport Lighting System 3.4 Screw and Torsion The torque listed in this section is only for reference by maintenance personnel. Correct fastening force of screw can ensure normal operation of the lighting fixtures. If screw is too tight, it will easily damage the lighting fixtures;... -
Page 19: Installation Process
Advanced Airport Lighting System 3.6 Installation Process The installation process of lighting fixtures includes settings of the pavement mounting hole, wiring, base pre-burial and installation of lighting fixtures. The installation of lighting fixtures will greatly impact their use and service life. The manufacturer recommends that all installers should receive the professional training. - Page 20 Advanced Airport Lighting System 3.6.2 Installation a Before installing the lighting fixtures, clean the waste in the seal groove to keep good seal. Put the O-gasket (part No.: 41115) into the working position in the seal groove. b Connect the secondary plug of the lighting fixtures with the base receptacle to keep good contact. c Load the lighting fixtures into the base, identify the direction, screw the screws into the screw holes in successive and please note the torsion when screwing them.
-
Page 21: Replacement Of Components Of Lighting Fixtures
Advanced Airport Lighting System 4.0 Replacement of Components of Lighting Fixtures When any damage or failure occurs to any consumable or other component of the lighting fixtures, it is required to timely dismantle the lighting fixtures for replacement of the component. Replacement of components needs to dismount the lighting fixtures, so any minor error will cause adverse consequences. -
Page 22: How To Dismount The Lighting Fixtures From Base
Advanced Airport Lighting System 4.1 How to Dismount the Lighting Fixtures from Base ○ Dismount M10×30 screw, washer and spring washer (see Figure 4-1); ○ Stretch into the pinch bar hole with two screwdrivers and vertically unscrew the lighting fixtures (see Figure 4-2). Screwdriver Lighting fixtures STYLE 6 plug... -
Page 23: How To Replace Light Source Components
Advanced Airport Lighting System 4.3 How to Replace Light Source Components ○ Separate the upper cover and inner cover with the method set forth in 4.2; ○ Pull out the light source component pin from the light source binding post of the circuit board of the inner cover component (Figure 4-5);... -
Page 24: How To Replace Prism And Its Gasket Sleeve
Advanced Airport Lighting System 4.4 How to Replace Prism and its Gasket Sleeve ○ Separate the upper cover and inner cover with the method set forth in 4.2; ○ With the socket head wrench, dismount M5×12 screws and take down the prism pressing bracket, prism washer, lens and lens gasket sleeve in succession (see Figures 4-8 and 4-9);... - Page 25 Advanced Airport Lighting System Figure 4-11 Figure4-12 Figure 4-13 Figure 4-14 The old rubber gasket sleeve shall not be used repeatedly. ※ Aging and damage of the rubber gasket sleeve may cause water seepage and leakage of the lighting fixtures. ...
-
Page 26: How To Replace Gasket
Advanced Airport Lighting System 4.5 How to Replace Gasket ○ Dismount the screw connecting the inner cover and upper cover to separate them (see Figure 4-15); ○ Take out the old gasket from the seal groove of the upper cover (see Figure 4-16); ○... -
Page 27: Airtight Test Of Lighting Fixtures
Advanced Airport Lighting System 4.6 Airtight Test of Lighting Fixtures ○ Unscrew the valve cap at the lighting fixture bottom (see Figure 4-20). ○ Prepare 138Kpa air source (the air pressure shall not be greater than 150Kpa) and applicable air gun (air tube), inflate the air by aiming at the valve (Figure 4-21) until the air pressure in the lighting fixture meets the requirements. -
Page 28: Operation And Control
Advanced Airport Lighting System 5.0 Operation and Control The lighting fixtures are applicable to CCR power supply 6.6A circuit special for airports, which forms a secondary circuit with the lighting fixtures through secondary outgoing line of isolation transformer connected on primary circuit. Due to the use of isolation transformer, the damage of lamp of single lighting fixture will not affect whole series circuit. -
Page 29: Maintenance Of Lighting Fixtures
Advanced Airport Lighting System 6.0 Maintenance of Lighting Fixtures Suggestions for daily maintenance provided in this section are only for reference. Airports may formulate their own daily maintenance guidelines with reference to other provisions or maintenance experience of airport staff; the manufacturer does not provide any hard-and-fast rules. Maintenance of the lighting fixtures for airports shall be conducted by professionals as stated in 1.0 Foreword. -
Page 30: Regular Spot Check And Troubleshooting
Advanced Airport Lighting System 6.2 Regular Spot Check and Troubleshooting Serial Failure Phenomenon Possible Reasons Countermeasures aging other Replace lamp unknown failure No light output or component or driver or return Power isolation flashing the lighting fixtures to the transformer of greater than manufacturer for maintenance. -
Page 31: List Of Components And Ordering Of Spare Articles And Accessories
Advanced Airport Lighting System 7.0 List of Components and Ordering of Spare Articles and Accessories The table in this chapter lists the components, spare articles and accessories of this product and relevant ordering information. Spare articles and accessories of this product needs to be ordered additionally, and the manufacturer accepts the order in assembly mode and separate order of components. - Page 32 Advanced Airport Lighting System List of supporting accessories of this product is as follows (needing additional order): Serial No. Order No. Description 927151 12 inches shallow base component (side entry) 927156 12 inches shallow base component (bottom entry) 82732X 12 inches deep base (H550) assy 70703 A7 twin-core receptacle 41115...
-
Page 33: Packaging, Transportation And Storage
Advanced Airport Lighting System 8.0 Packaging, Transportation and Storage 8.1 Packaging and Weight Packaging:1 pcs / box Gross weight: 9.7 KG / box Volume: 330*330*150mm³ Packaging: 1 pcs / box (including 12 inches shallow base) Gross weight: 14.26 KG / box Volume: 330*330*185mm³... - Page 34 Advanced Airport Lighting System The final right to interpret this manual is reserved by Airsafe Airport Equipment Co., Ltd. Thanks for your purchasing and using AIRSAFE product! Address: No. 38, Anxin Road, Xuhang Town, Jiading District, Shanghai, China Postal Code: 201800 Tel.: 021-53540453...
