ETi 250® HIGH EFFICIENCY POOL HEATER
INSTALLATION AND USER'S GUIDE
If you do not follow these instructions exactly, a fire or explosion may result, causing property damage, personal
injury or loss of life. For additional free copies of this manual; call USA (800) 831-7133
FOR YOUR SAFETY - This product must be installed and serviced by authorized personnel, qualified
in pool/spa heater installation. Improper installation and/or operation can create carbon monoxide gas,
fire or explosion, and flue gases which can cause serious injury, property damage, or death. For indoor
installations, as an additional measure of safety, Pentair strongly recommends installation of suitable
Carbon Monoxide detectors in the vicinity of this appliance and in any adjacent occupied spaces.
Improper installation and/or operation will void the warranty.
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, personal injury
or death. Installation and service must be performed by
a qualified installer, service agency or the gas supplier.
120 / 240 VAC NATURAL GAS / PROPANE GAS
Model
ETi 250 NA - ASME
FOR
YOUR
SAFETY
1620 Hawkins Ave., Sanford, NC 27330
10951 W. Los Angeles Ave., Moorpark, CA 93021
FOR YOUR SAFETY - READ BEFORE OPERATING
Natural
461112
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of
this or other appliances.
Pentair Water Pool and Spa, Inc.
(800) 831-7133 or (919) 566-8000
•
(800) 831-7133 or (805) 553-5000
•
OWNER:
Retain For
Future
Reference
