Cooper Lighting Metalux DIVM Specification Sheet

D I M E N S I O N S
NOMINAL LENGTH A
4', 8' 13 1/2" (343mm)
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : D I V M - 2 3 2 - 1 2 0 V - E B 8 1 - U
Number
Tandem
of Lamps
Blank=4' Length
2 Lamps
8T=8' Length
(Not included)
Series
Wattage (Length)
DIVM=Apertured
40=34/40W T12 (48")
Reflector
32=32W T8 (48")
DCIVM=Closed Top
48=40W T12 (48") SL
Reflector
48HO=60W T12 (48") HO
48HO=44W T8 (48") HO
48VHO=110W (48") VHO
96=60/75W T12 (72") SL
96=59W T8 (96") SL
96HO=95/110W T12 (96") HO
96HO=86W T8 (96") HO
96VHO=185/215W (96") VHO
96PG=185/215W (96") PG
(1)
Voltage
120V=120 Volt
277V=277 Volt
347V=347 Volt
UNV=Universal Voltage 120-277
Options
GL=Single Element Fuse
GM=Double Element Fuse
Emergency - for EM installed, see
EM options table
(1)
NOTES: Products also available in non-US voltages and frequencies for international markets.
(3)
Silver lining not available on fixtures with HO, VHO or PG.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
COOPER LIGHTING - METALUX
B
6 5/8" (168mm)
(1)
Ballast Type
Blank=Standard Magnetic Ballast
LE3=T12 Magnetic Energy Saving
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
No. of
Harmonic Distortion < 20%
Ballast
1, 2 or 3
ER8 = T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
EB2 =T12 Electronic Rapid Start.
No. of Ballast
1 or 2
(For complete details on generic or to specify
manufacturer's ballast see pg. 469)
(2)
(2)
Not available when specifying emergencies, voltage must be specific.
D E S C R I P T I O N
The DIVM Series is an energy
efficient family of industrials that
features premium performance
and durability. The DIVM
incorporates heavy duty,
embossed, reflectors that
precisely direct and effectively
control light. The special deep
center "V" reflector provides 30°
crosswise lamp shielding to
minimize glare. The versatile
DIVM can be installed using
various mounting methods and
numerous options and
accessories are available. The
DIVM Series can be utilized in
simple task and area lighting to
the most demanding industrial
applications.
Packaging
Options
(See Options U=Unit Pack
Section)
4B=4 Bulk
®
DIVM SERIES
4 ' o r 8 ' I n d u s t r i a l
2 L a m p s
H E AV Y D U T Y
C E N T E R " V " I N D U S T R I A L
• Equipped with energy
saving ballasts/complies
with federal energy
efficiency standards
• Die formed channels
• Heavy duty apertured,
(DIVM) or closed top,
(DCIVM) reflector with
Center "V"
• Deep draw full width
reflector ribs add rigidity
• Center "V" provides 30°
crosswise shielding/
reduces glare
• Metal clad lampholders
with spring loaded sockets
• Baked white enamel finish
• Apertured reflector (DIVM)
standard with 20% uplight
• Porlux and Silverlining
finishes available
(3)
• Wire guards, gym guards,
lens frames, and metal
louvers available for
special applications
• Also available in tandem 8'
lengths
• UL/CUL Listed. Suitable for
damp locations.
COOPER LIGHTING
455
