Cooper Lighting Metalux Indoor Lighting Accessories Specification Sheet

COOPER LIGHTING - METALUX
PARABOLIC, RECESSED AND SURFACE ACCESSORIES
A C C E S S O R Y
T-Bar Safety Clips
Suspension Sets
SCF SCS SCA
CCA CCA CCA
PFC PFS NPF
Plaster Frames
Side Filler Panel
Spacer
End Fillers
End Support Brackets
CR Wall Mounting Kit
Items listed are the major accessories available on Metalux Recessed (Parabolic and Recessed) and Surface Fixtures. Additional options and accessories are available.
Consult Pre-Sales Technical Support for additional information.
470
COOPER LIGHTING
D E S I G N AT I O N
EQ-Clip-U
(U.L. Listed 912Y)
T3A End EQ Bracket Parts Bag
(Includes (4) Screws and (4) Brackets
Stem Sets SCF-XX-B
SCS-XX-B
(Deep canopy, 3/8" stem, 5/8"
outside diameter)
XX= Length 6, 8, 12, 24, 36, 48, 60, 72
SCA-48-B
Used with all surface fixtures as stem sets. SCS stems have 45° swivel, one direction. One set consists of
one stem assembly. Minimum of two sets required per fixture. NOTE: Coupler, 3/8" IPS Pipe Coupler to
join lengths. Coupler is standard baked white enamel or special order of black.
Cable Sets CCA-XX-PFC-U
CCA-XX-PFS-U
CCA-XX-NPF-U
CCF-XX-PFC
CCF-XX-PFS
CCF-XX-NPF
95-PF-14 (1x4)
95-PF-22 (2x2)
95-PF-24 (2x4)
95-PF-44 (4x4)
SFP-4FT-B
A-1-B/Spacer-U
12-EFS-B (1x2, 1x4)
20-EFS-B (20x48, 20x24)
ESS-B
CR-WALLKIT
®
D E S C R I P T I O N
(U.L. Listed E61165)
U.L. approved safety clips used to secure recessed
troffers to T-bar. EQ clips used on fixture sides and
EQ end brackets for use on fixture ends.
Use four per fixture
Fixed Stem Set
Swivel Stem Set
Adjustable Stem Set (1/4" IPS Stem, 1/2" O.D.)
CCA=Adjustable Cable (XX=48" or 120")
CCF=Fixed Cable (XX=12", 15", 18", 21", 24" or 27")
PFC=Power Feed, coil power cord
PFS=Power Feed, straight power cord
NPF=Non Power Feed
Heavy Gauge Metal Construction. Used with
Flanged Recessed Fixtures. (Intended to serve as
a plaster stop only, not to fit into an opening).
Heavy gauge side filler panels for 20" x 48" fixture
for use in a 2' x 4' ceiling installation. (Baked white
finish/2 per set)
Spaces fixture 1 1/2" to 2 1/2" from ceiling
6" Heavy gauge end fillers use 2 per fixture. End
fillers lay on T-bars and are held in place by fixtures
24-EFS-B (2x2, 2x4) but are not attached
Heavy gauge end support brackets. Four per
fixture are required when fixtures are supported
from ends. Must be used with fixture that has a
modified end plate (MEP).
Kit including clips to install the CR Surface Corridor
fixture for wall mount applications.
(ORDER SEPARATELY)
