Operating the Radio

The receiver has a built-in tuner that allows for AM/FM
radio function.
Manual tuning
1. Connect the FM and AM antenna accordingly (see
"Connecting the Antenna" on page 5 section for details)
2. Press POWER on the main unit.
3. Press SOURCE until tuner mode is selected or press
AM/FM on the remote control.
BAND/APP SOURCE
RANDOM SURROUND
4. To select band, press the BAND/APP on the main unit or
AM/FM button on the remote again to toggle between
AM/FM mode.
When an FM station broadcast Stereo sound, ST is dis-
played.
BAND/APP SOURCE
RANDOM SURROUND
POWER
10:28 AM Page 1
BAND/A
RANDO
POWER
BASS/TREBLE
VCR ON OFF TV
AM•FM
DVD•CD TAPE SAT•CABLE
MUTE SURROUND
B
VCR ON OFF TV
DVD•CD AM•FM SAT•CABLE
TAPE
MUTE SURROUND
5. Tune the stations by pressing FAST FORWARD or FAST
REVERSE on the remote control repeatedly until the
desired station is found.
Alternatively, you can press and hold the respective buttons
for about one second to activate the automatic SEARCH
function. In this mode the receiver will automatically tune
frequencies until it finds a station.
7 8
WHO•INPUT
0
REVERSE PLAY
RECORD
STOP
SUBTITLE AUDIO ANGLE
DVD D I G I T A L
PRO.LOGIC
VCD
INTRORANDOM
CD
MP3
6. Repeat steps 5 to tune another radio station.
Select sound effect if needed by pressing SURROUND.
BAND/APP SOURCE
BASS/TREBLE PLAY M
RPT/PGM SURROUND
NOTE
1. If there is interference, modify the location
of the antenna until the optimal sound is heard.
TV and other electronic devices could be the
cause of interferences so try to position the
antenna away from them.
2. Weak signal can affect the "auto Search
function". Adjust the antenna for better recep-
tion for more efficient search.

Radio

9
ANT•FMS
FORWARD
PAUSE
ZOOM
L C R
LS LFE RS
DVD•CD TAPE AM•FM SAT•CABLE
MUTE SURROUND
