Page 1
RT2300-rev.1-quickstart 7/27/99 7:01 PM Page 1 do not output the film on this page please turn next page...
Page 2
RT2300-rev.1-quickstart 7/27/99 7:01 PM Page 2 POWER/STANDBY D I G I TA L VCR 1 VCR 2 TAPE PHONES i g i t a l Audio Video o u n d Integrated Receiver r o c e s s o r...
RT2300-rev.1-quickstart 7/27/99 7:01 PM Page 4 Quick Connect Guide Dolby Digital equipped for the RT-2300 / RT-2400 can reproduce realistic sound in your listening room. Now start setting up your brand-new receiver. Connect the components Connect the speakers, TV and video component equipped with Dolby Digital decoder, for example, DVD player with Dolby Digital.
RT2300-rev.1-quickstart 7/27/99 7:01 PM Page 5 Quick Connect Guide POWER/STANDBY VCR 1 TAPE PHONES Turn on the Power Plug the AC power cord into a standard household 120V AC outlet. Right after you plugged in the power, a demo message will be appeared in display.
Page 6
Press Test Tone / Setup repeatedly until one of the following shows on the display: Speaker Arrangement Control Note: You can skip this part if you purchase the home theater system with speakers and subwoofer as the receiver has been already calibrated. Display...
Page 7
RT2300-rev.1-quickstart 7/27/99 7:02 PM Page 7 Quick Connect Guide POWER/STANDBY VCR 1 TAPE PHONES Set Speaker Output Levels Press Test Tone / Setup on receiver or INFO•RDS button on receiver momentarily. A test tone will be generated in each of the speakers.
