SETTING THE PLANT ETHERNET AND VIEW-R CONNECTIONS:
The cable connection originates at the EtherNet connector at
the back of the View-R unit. This cable connects to the EtherNet
switch on the plant EtherNet. The laptop or computer terminal
that will be used to access and program the View-R should also
be connected to the plant EtherNet.
CABLE REQUIREMENTS:
WTC recommends using Cat5E or Cat6E cable of 100 m max.
length to connect to the Plant EtherNet.
85-250V Power Cable, 50/60 Hz, 1.5 Amps should be used to
connect to the power supply.
